Specifications - General ASHB09LDC Service Manual

SPECIFICATIONS

TYPE
INDOOR UNIT
OUTDOOR UNIT
COOLING CAPACITY
HEATING CAPACITY
ELECTRICAL DATA
POWER SOURCE
FREQUENCY
COOLING
RUNNING CURRENT
HEATING
COOLING
INPUT WATTS
HEATING
COOLING
E.E.R.
HEATING
COP
MOISTURE REMOVAL
COOLING
AIR CIRCULATION
-High
HEATING
COMPRESSOR
TYPE
DISCRIMINATION
REFRIGERANT
R410A
FAN MOTOR
POWER SOURCE
HIGH2
HIGH-SPEED
INDOOR UNIT
MED-SPEED
( cool / heat )
LOW-SPEED
QUIET
HIGH2
OUTDOOR UNIT
( cool / heat )
HIGH-SPEED
" HIGH2 " means when ability measurement.
2006.02.06
COOL & HEAT INVERTER
ASHB09LDC ASHB12LDC
AOHS09LDC AOHS12LDC
2.60 kW 3.50 kW
3.60 kW 4.80 kW
230 V 230 V
50 Hz 50 Hz
2.9 A 4.3 A
3.9 A 5.5 A
0.61 kW 0.91 kW
0.81 kW 1.22 kW
4.26 kW/kW 3.85 kW/kW
4.44 kW/kW 3.93 kW/kW
1.3 L/hr 1.8 L/hr
560 m3/hr 595 m3/hr
605 m3/hr 630 m3/hr
Hermetic type, 4 pole, 3 phase,
DC inverter motor, Rotary
DA89X1C - 20FZ
950 g 1,050 g
230 V 230 V
1,340 / 1,430 r.p.m. 1,400 / 1,470 r.p.m.
1,300 / 1,390 r.p.m. 1,370 / 1,440 r.p.m.
1,120 / 1,200 r.p.m. 1,150 / 1,200 r.p.m.
950 / 1,000 r.p.m. 950 / 1,000 r.p.m.
700 / 760 r.p.m. 700 / 760 r.p.m.
820 / 760 r.p.m. 820 / 820 r.p.m.
760 / 680 r.p.m. 760 / 680 r.p.m.
DIMENSIONS
INDOOR UNIT
H x W x D
OUTDOOR UNIT
H x W x D
WEIGHT
INDOOR UNIT
Gross / Net
OUTDOOR UNIT Gross / Net
NOISE LEVEL
INDOOR UNIT
( Cool / Heat )
OUTDOOR UNIT
( Cool / Heat )
REFRIGERANT (R410A)
Pipe Length
FULL CHARGE AMOUNT
ADDITIONAL REFRIGERANT
MAXIMUM PIPING HEIGHT
1
283 x 790 x 230 mm
540 x 790 x 290 mm
12 / 9.5 kg 12 / 9.5 kg
38 / 34 kg
40 dB / 41 dB 42 dB / 42 dB
High 2
39 dB / 40 dB 41 dB / 41 dB
High 1
34 dB / 35 dB 35 dB / 35 dB
Med
29 dB / 28 dB 29 dB / 28 dB
Low
20 dB / 21 dB 20 dB / 21 dB
Quiet
High 2 48 dB / 50 dB 49 dB / 51 dB
High 1 47 dB / 48 dB 47 dB / 49 dB
950 g
15 m
1,050 g
20 m
20 g / m
15m
40 / 36 kg
1,050 g
1,150 g
20 g / m
15m
