Boiler Design

This boiler is designed for use as part of a sealed water
central heating system with fully pumped circulation. The
pump, expansion vessel and associated safety devices are all
fitted within the boiler. The integral programmer is designed
for both simple operation and maximum control. Once the
controls are set the boiler will operate automatically.
Condensate Drain
A plastic drain pipe must be fitted to allow discharge of
condensate to a drain.
Electrical Supply Failure
The boiler will not work without an electrical supply.
Normal operation of the boiler should resume when the
electrical supply is restored.
Reset any external controls, to resume normal operation of
the central heating.
If the boiler does not resume normal operation press the
reset button. If the boiler does not resume normal operation
after this call your Installation/Servicing company or Glow-
worm service.
Overheating Safety
The boiler software is designed to recognise the potential for
an overheat lockout and will shutdown before this happens.
To restart the boiler, press the reset button on the controls
fascia.
If the boiler fails to resume normal operation and all external
controls are calling for heat, then call your Installation/
Servicing company or Glow-worm service.
Safety Discharge Valve
A safety discharge valve and discharge pipe are fitted to
the boiler. This valve must not be touched. Should there
be any discharge from the pipe, isolate the boiler electrical
supply and call your installer or Glow-worm's own service
organisation using the telephone number on the inside front
cover of this booklet.
Servicing, Maintenance
Servicing and Maintenance
To ensure the continued efficient and safe operation of the
boiler it is recommended that it is checked and serviced as
necessary at regular intervals. The frequency of servicing will
depend upon the particular installation conditions and usage.
If this appliance is installed in a rented property there is a duty
of care imposed on the owner of the property by the current
issue of the Gas Safety (Installation and Use) Regulations,
Section 35.
Servicing/maintenance should be carried out by a competent
person in accordance with the rules in force in the countries
of destination.
To obtain service, please call your installer or Glow-worm's
own service organisation using the telephone number on the
inside front cover of this literature.
Supplied By www.heating spares.co Tel. 0161 620 6677
Boiler Design
Condensate should, if possible, be discharged into the
internal household draining system. If this is not practical,
discharge can be made externally into the household
drainage system or a purpose designed soak away, see
section 9 for more details.
Pluming from flue terminal
Like all condensing boilers this appliance will produce a
plume of condensation from the flue terminal in cool weather.
This is due to the high efficiency and hence low flue gas
temperature of the boiler.
This is normal and not an indication of a fault.

Safety Devices

Frost protection
The appliance has a built in frost protection device that
protects the boiler from freezing. With the gas and electric
supplies ON and irrespective of any room thermostat setting,
the frost protection device will operate the pump when the
temperature of the boiler water falls below 8
A timer is used so that the temperature can be checked
periodically. After 10 minutes the pump will be stopped if the
temperature is higher than 10
The burner will activate if the boiler temperature does not
reach 10
O
drops to 5
The burner will switch off when the temperature reaches
35 O C.
Condensate Drain Blockage
As a safety feature the
condensate drain becomes blocked. During freezing
conditions this may be due to the forming of ice in the
condense drain external to the house. Release an ice
blockage by the use of warm cloths on the pipe, the boiler
should then restart.
and Spare Parts
"Benchmark" scheme
Glow-worm support the Benchmark initiative. It is very
important that the Installation, Commissioning and Service
Record is completed by the installation engineer and handed
over to the user.
Spare Parts
Remember, when replacing a part on this appliance, use
only spare parts that you can be assured conform to the
safety and performance specification that we require. Do not
use reconditioned or copy parts that have not been clearly
authorised by Glow-worm.
If a part is required contact Glow-worm's own service
organisation.
Please quote the name of the
on the name badge on the front of the appliance.
If in doubt seek advice from the local gas company or Glow-
worm's own service organisation using the telephone number
on the inside front cover of this booklet.
6
C or has already reached 35
O
C after 30 minutes or at any time if the temperature
C.
O
boiler will stop working if the
appliance,
C.
O
C.
O
this infomation will be
