Summary of Contents for Kitvision Edge HD10
- Page 1 User manual HD10 A C T I O N C A M E R A kitvision.co.uk JB. 2957 © Kitvision ™ 2013. Christchurch, Dorset. BH23 4FL...
- Page 2 With a wide range of cameras and accessories, Kitvision is here to help you record your memories. We’re committed to developing the very latest technologies so you can capture, re-live and share your experiences in the best way possible. By remembering the past and embracing the future,...
- Page 3 Contents Main features Box contents Functions Instructions for use Troubleshooting Specifications...
- Page 4 Main features Box contents • Full HD video recording with multiple interchangeable recording modes (1080P/960P/720P) 1. Kitvision Edge HD10 action camera 2. TFT screen • 8 Megapixel photo mode 3. Waterproof case • Various photo modes: Single shot/Triple shot/Time-lapse mode/Self-timer mode 4.
- Page 5 Functions TFT display screen 22. Camera Lens 2. MENU key 23. Green indicator light 14 15 16 18 19 20 3. Up key (video recording/shooting) 4. Left key 24. HDMI output interface 5. Down key 25. USB output interface 6. Recall key 26.
- Page 6 Instructions for use Before use 1. LCD segment screen Startup Turn the power switch to the “ON” position to check the battery power. If the battery level is low, charge it using the 1. The camera can be used in two ways: supplied USB cable with a power adaptor or USB port of a PC.
- Page 7 Before use 2. Formatting the micro SD card [...continued] The following indicators can be seen on the TFT display screen: Please use a high-speed micro SD card only and format it on the camera before recording or taking a picture. If the micro SD card has been used on other devices, please format it on the camera before any operation.
- Page 8 Parameter settings 2. Bit rate Options in recording modes: 1080P (12M/6M), 960P (8M/4M), 720P (8M/4M), WVGA (8M/4M). If a high bit rate is In preview mode, press the “M” key to enter the menu interface, then press the “<” or “>” key to move the cursor left or selected, you will get a clearer picture with increased file size.
- Page 9 b. Parameter setting for photo shooting c. System parameter setting 1. Image resolution 1. Beep: Turning the key tones on or off Note: The camera will still beep when you start and stop a video recording. This cannot be turned off 8.0 MP 3200 x 2400p 2.
- Page 10 System parameter setting 3. Video recording [...continued] Manual recording: 8. Factory default: This operation restores the parameter settings to the factory default. If restoring the factory Press the “Record” key once in preview mode to start recording. The video recording duration will be displayed at default, the system will set the time to 01.01.2012 the bottom right of the TFT display screen, the “Green Indicator of Video/Voice Recording”...
- Page 11 Using the camera • Self-timer mode: Press the “M” key to enter the camera setup interface, press the “>” or “<” keys to move the [...continued] cursor to , then press the “>” or “<” keys to select the menu “Self shot” and press the “OK” 4.
- Page 12 Using the camera – Browsing photo files [...continued] 6. File recall Press the key and enter the “Capture” interface. All files will appear on the screen. Select the photo file by pressing the “>” or “<” keys and press “OK” to view. Press the “–” key to enter the thumbnail preview mode. You can view the audio files, video files and photo files on the camera.
- Page 13 Using the camera Note: The DPOF printing requires a micro SD card with preset DPOF information. It will fail if you simply select the [...continued] photos from the micro SD card and try to print them 7. Managing your files Note: Some DPOF compatible printers and digital photo developing shops may fail to print the photos based on the In recall mode, select a file and then press the “M”...
- Page 14 Using the camera 11. HDMI output connection [...continued] 9. Standby mode In preview state, connect the camera with the high-definition display device using an HDMI cable. The camera’s functions can then be operated Turn the power switch to the “ON” position. The system will start working and it will enter preview mode Note: After connecting with the HDMI display device, the TFT screen on the camera and the voice will be turned once initialization has finished.
- Page 15 File storage and play 1. USB cable You can either copy or move the recorded video files to your computer via the USB cable or you can remove the micro SD card and insert it into a card reader to read the video data. Note: Please turn off the camera before inserting or unplugging the USB cable USB port USB port on...
- Page 16 Built-in high quality microphone We hope you’ve now got all the information you need to get started, but if you’re having problems with anything, Audio please feel free to contact us at: support@kitvision.co.uk Format: WAV Storage Micro SD/micro SDHC with minimum class 6 up to 32 GB (not included) Specifications USB 2.0 (for data connection and battery charging)
- Page 17 Power supply Notices for Waterproof Casing For charging the Edge HD10, please use chargers certified by the following authorities only: The waterproof casing should be installed correctly. Please note the following when using the camera: 1. Do not disassemble and reaffix the sealing ring of the casing, keys and lens cover. Doing so can make the waterproof casing ineffective 2.
- Page 18 Cautions for using 3M double-sided foam sticker FCC Statement • Please choose a suitable curved or flat surface to ensure that the 3M double-sided foam sticker attaches The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
