- Page 1 User manual HD30W A C T I O N C A M E R A kitvision.co.uk JB. 2958 © Kitvision ™ 2013. Christchurch, Dorset. BH23 4FL...
- Page 2 With a wide range of cameras and accessories, Kitvision is here to help you record your memories. We’re committed to developing the very latest technologies so you can capture, re-live and share your experiences in the best way possible. By remembering the past and embracing the future,...
-
Page 3: Table Of Contents
Contents Main features Box contents Functions Before use Instructions for use Using Wi-Fi Accessory application Troubleshooting Specifications... -
Page 4: Box Contents
Main features Box contents • Built-in Wi-Fi to control the video camera remotely with your smartphone/tablet 1. Kitvision Edge HD30W action camera 2. TFT screen • Full HD video recording with multiple interchangeable recording modes 3. Waterproof case • 8 Megapixel photo mode 4. -
Page 5: Functions
Functions... -
Page 6: Before Use
LED indicator status Before use • Ensure that the battery “lock key” at the bottom of the camera is unlocked Red indicator Green indicator Blue indicator • Push the battery into the slot completely as below Front cover (1) Front cover (1) Front cover (1) •... -
Page 7: Instructions For Use
2. You can then pull it out below of the selected item. After selection, press the “OK” button to confirm. Note: Please ensure that the date and time are correctly set. The Edge HD30W will add the time to the photo/video according to this setting. - Page 8 5. Press the < or > button to move the cursor to the language type to be modified. Turn the G-Sensor key to “ON” so that the Edge HD30W can actively sense the Then press the “OK” button to confirm change of gravity.
- Page 9 Resolution setting Visual angle The optional resolutions for video recording are listed as below: Optional visual angles: Wide, Medium, Narrow, Small PAL System NTSC System 1920 x 1080i 50f 16:9 1920 x 1080i 60f 16:9 1920 x 1080p 25f 16:9 1920 x 1080p 30f 16:9 1280 x 960p 25f 4:3 1280 x 960p 30f 4:3...
- Page 10 1. Press the “M” button to enter the camera setting menu • When this function is activated, upright video files can be obtained when using the Edge HD30W to shoot video 2. Press the – or + button to select “Exe.: audio only” mode and press the “OK” button to confirm upside down.
- Page 11 Three optional resolutions include: • Please set the photo shooting mode to “Timed shooting” before using this function • When the “Shutter” button is pressed once in recording standby mode, the Edge HD30W will start counting down 8.0 M (3200 x 2400 4:3) 5.0 M (2592 x 1944 4:3)
- Page 12 Auto standby : medium (50%) The Edge HD30W is set to automatically enter standby mode if no operation (photo shooting, video recording or button : standard (100%) operation) is carried out in a certain amount of time. If any operation is carried out in the timing process, the timer will be reset.
- Page 13 Operating procedure for playback When reviewing photos, the functions of various buttons are listed as below: 1. Press the “Playback” button to enter the playback interface 2. Press the + or – button to move the cursor to select file type icons Button Functions Button...
- Page 14 4. Move the cursor to select “delete single” or “delete all” and press the “OK” button to delete the file(s) • Use the HDMI cable to connect the Edge HD30W to the TV set: : Delete single...
- Page 15 WLAN settings interface or click the icon to enter the main interface Note: The mobile device must be used within a distance of 100 metres from the Edge HD30W in an obstacle-free area to view local files only (no other operation is supported).
- Page 16 Operating instructions for Wi-Fi control interface Video recording • Click the video recording mode icon . The icon will be displayed. Click it to start or stop video recording. • Click the icon to maximize the preview (see Fig. 3). Return to Return to main interface...
- Page 17 Fast Shot Camera storage • Click the fast shot mode icon and it will turn blue . The current state icon will display . Click it to take Mobile device storage multiple pictures within one second • Click the icon to maximize the preview (see Fig. 5). You can set how fast the camera takes pictures in the Return to Settings main interface...
- Page 18 In the large preview mode Photo files: • Click the icon to return to the thumbnail preview interface • Click the icon to share the current file to a social networking website or send it by email Select All/ Deselect All •...
- Page 19 End frame Start frame Note: If the micro SD is formatted, you need to reconnect the Edge HD30W to your camera in order to find the folder “MISC” and change the name and password. Note: If operating the camera using its buttons and using the Wi-Fi based remote control at the same time, the Edge HD30W will give priority to the operation command from the camera.
- Page 20 The Edge HD30W is fitted with a waterproof housing which can be used to record videos underwater. Waterproof housing and anti-fog inserts The Edge HD30W’s waterproof housing has a rating of up to IP68 and can protect the camera 100 meters underwater. Follow these steps to load the camera into the waterproof housing: The plug bracket can fix the waterproof housing firmly onto the mount connector clip, as shown above.
- Page 21 Using the curved and adhesive mounts The Edge HD30W comes with a curved and a flat adhesive mount for installation on different surfaces. You can easily The plug bracket can fix the Edge HD30W firmly onto the mount connector clip.
- Page 22 Specifications 175° ultra wide angle field of view USB 2.0 (for data connection and battery charging) Lens Aperture f/2.8 Connection HDMI 1080i: 1920 x 1080 pixels (16:9) 60 FPS Wi-Fi (802.11 b ) up to 100 m 1080p: 1920 x 1080 pixels (16:9) 30 FPS Detachable 1500 mAh rechargeable Lithium-ion battery Power 960p: 1280 x 960 (4:3) 30 FPS...
- Page 23 Power supply Care for your Edge HD30W For charging the Edge HD30W, please use chargers certified by the following authorities only: • Do not drop, knock or shake the video camera • Do not put the video camera close to an object that generates a strong magnetic field, such as a television set, a speaker, a motor or a magnet.
- Page 24 Tips FCC Statement 1. When the unit is in use for a long period, it is normal for the surface temperature to rise The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
