4MDR52XXD Series Fan
UL Model No. : AC-552
shown with light
ALTO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 4MDR52XXD Series
Summary of Contents for Monte Carlo Fan Company 4MDR52XXD Series
- Page 1 4MDR52XXD Series Fan UL Model No. : AC-552 MonteCarloFans.com shown with light shown without light To register your fixture, please visit our website: MonteCarloFans.com NEED HELP? STOP ALTO ¿NECESITA AYUDA? AVEZ-VOUS BESOIN D’AIDE? Please do not return this product to the store.
-
Page 2: Helpful Tools
Helpful Tools Safety instructions WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 Insert downrod into the yoke on top Thread the leadwires and of fan body. Align the hole in the s a f e ty c a b l e t h r o u g h t h e P l a c e y o k e c o v e r o v e r downrod with the hole in the yoke.
- Page 4 Enhance plate Lift Conopy allowing the 2 studs to Insert blade into the slot on flywheel and install blade screws, fiber washers protrude through the canopy. and enhance plate aligning each of the holes as shown. Repeat this process for Install knurled nuts and tighten the remaining blades.
- Page 5 Attach glass onto light pan, aligning Install scroll by aligning the set Install 18W CFL medium base bulb. Bulb included. WARNING: USE MAXIMU 18 the holes on its top metal ring with screw and pop it onto the top ring WATTS MEDIUM BASE LISTED SBCFL(SELF- the screw holes on the side of ligt on the glass with the light pan.
- Page 6 Remote Control Transmitter Features: MEDIUM SPEED LED LIGHT LOW SPEED HIGH SPEED LIGHT ON/OFF SETTING (Press to turn on/off light) F A N O F F S E T T I N G (Turns fan off only) FAN SPEED Depress “1 dot” for low speed, “2 dots” for medium or “3 dots”...
-
Page 7: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 8 June.2011...
