TrailBlazer®
Assembly and Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrailBlazer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for diversey TrailBlazer

Summary of Contents for diversey TrailBlazer

  • Page 1 TrailBlazer® Assembly and Instruction Manual...

  • Page 2: Table Of Contents

    ................................1 Handle and Base Plate Mounting Bracket Assembly ................3-9 Base Plate, Base Plate Shaft and Cleanup Tool Assembly ............10-12 How to Finish Floors with TrailBlazer ......................13 Floor Finish BIB Preparation ........................13 Feed Line and Base Plate Preparation ....................14-15 Applying Finish with TrailBlazer ......................

  • Page 3: Assembly

    Assembly Parts Included Main Components A. Body - (1) B. Upper Handle - (1) C. Bail - (1) D. Hardware Assembly Packet - (1) E. Lower Handle - (1) F. Base Plate Support Bar - (1) G. Base Plate - (1) H.
  • Page 4 Assembly Parts Included (continued) Starter Kit T. Base plate covers - (3) U. Short feed line - (3) V. Long connector feed line - (3) W. Applicator pad - (1) X. Manifolds - (3) Cleanup Tool Y. Fame - (1) Z.

  • Page 5: Handle And Base Plate Mounting Bracket Assembly

    Assembly Handle and Base Plate Mounting Bracket Assembly Figure 1 After completing steps 1 through 24 your TrailBlazer should look like Figure 1. Place body (A) onto fl oor with wheels facing down. (See fi gure 2) Figure 2...
  • Page 6 Assembly Handle and Base Plate Mounting Bracket Assembly (continued) Insert lower handle (E) into guide holes and slide into place. (Figure 3) Figure 3 Insert base plate support bar (F) into guide holes and slide into place. (Figure 4) Make sure base plate support bar has the bracket mounting hole facing up and away from the lower handle.
  • Page 7 Assembly Handle and Base Plate Mounting Bracket Assembly (continued) Position body (A) onto its side keeping the lower handle and base plate support bar in place. (Figure 5) Figure 5 Slide washer (N), locking washer (R) onto one of the four threaded bolts of the lower handle (E) and base plate support bar (F).
  • Page 8 Assembly Handle and Base Plate Mounting Bracket Assembly (continued) Attach upper handle (B) to lower handle (E) by aligning pivot brackets and hand tightening with handle hinge screws (Q) (Figure 7). The upper handle is height adjustable for comfort. Figure 7 Insert cable into cable guide (Figure 8).
  • Page 9 Attach lower mounting bracket (J) to body (A) with lower mounting bracket bolt (L). Hand tighten with Philips head driver on hand tool (S). (Figure 10) Make sure the hanging push pin is on the closed side of the TrailBlazer body. Figure 10...
  • Page 10 Assembly Handle and Base Plate Mounting Bracket Assembly (continued) Locate the four black release knobs on the top face of the pump cartridge. Rotate each knob 90 to release pump. Flip pump cartridge over. Insert the squeeze tubing by inserting one of the barbed fi ttings back into the slot in the pump housing, making sure that the clip end of the tie-wrap on the tubing is facing towards the centerline of the pump housing.
  • Page 11 Assembly Handle and Base Plate Mounting Bracket Assembly (continued) Replace the pump cartridge assembly on the mounting plate by aligning the toothed drive gear with the roller assembly and sliding down into position. Turn the release knobs until the arrows on the knobs are parallel with the long side of the mounting plate.

  • Page 12: Base Plate, Base Plate Shaft And Cleanup Tool Assembly

    Base Plate, Base Plate Shaft & Cleanup Tool Assembly Figure 13 After completing steps 1 through 5 your TrailBlazer should resemble Figure 13. Place base plate (G) fl at on surface with bolt facing upward and eyebolts facing body of TrailBlazer. Place base plate shaft (H) onto bolt and tighten nut (O) with hand tool (S) (Figure 14).
  • Page 13 Assembly Base Plate, Base Plate Shaft & Cleanup Tool Assembly (continued) Position base plate (G) and base plate shaft (H) into upper mounting bracket (K) and lower mounting bracket (J) (Figure 15). Figure 15 While holding base plate shaft (H) in place align lower bracket guide hole and shaft slot.
  • Page 14 (Y) onto the cleanup tool handle (BB). Align the holes and insert the retaining ring. Next, tighten the nut onto the cleanup tool frame (Y). Now insert the cleanup tool clip (AA) onto the lower handle (E) and secure the cleanup tool to the TrailBlazer. (Figure 19) Figure 19...

  • Page 15: How To Finish Floors With Trailblazer

    Insert the white tap in the round opening and fold down access tab. Place BIB with the white tap facing the fl oor onto TrailBlazer with the white tap on the open side of the TrailBlazer. (See Figure 21) White Tap...

  • Page 16: Feed Line And Base Plate Preparation

    How to Finish Floors with TrailBlazer Feed Line & Base Plate Preparation Attach the long connector feed line and fi lter assembly (V) to the white tap, making sure both locking clips on the connector engage with the locking tabs on the white tap.
  • Page 17 How to Finish Floors with TrailBlazer Feed Line & Base Plate Preparation (continued) Attach one end of the short feed line (U) onto the gray male connector on the manifold (X). Slide the free end of the short feed line (U) to the pump. (Figure 25)

  • Page 18: Applying Finish With Trailblazer

    How to Finish Floors with TrailBlazer Applying Finish with TrailBlazer Only do steps 1-6 if the applicator pad has not already been saturated with fi nish* Disconnect long connector feed line (V) from the pump inlet. The pump inlet is the white male connector on the pump, located on the open side of the...
  • Page 19 About 10 feet (3m) before the end of the pass, raise the bail (C) to keep excess fi nish from being applied as the TrailBlazer is turned for the next pass. Lower the bail (C) and continue applying fi nish.
  • Page 20 How to Finish Floors with TrailBlazer Applying Finish with TrailBlazer (continued) Repeat steps 7 and 8 until the entire area is coated with fi nish. About 10 feet (3m) before the last pass is fi nished close the white tap on the BIB and keep the bail lowered to empty the feed lines and manifold.

  • Page 21: Trailblazer Cleanup

    How to Finish Floors with TrailBlazer TrailBlazer Cleanup Raise base plate (G) to give access to manifold and applicator pad. (Figure 32) Figure 32 Remove short feed line (U) from pump outlet. (Figure 33) Figure 33 Remove manifold (X) and short feed line (U) and dispose of in trash.

  • Page 22: Changing Filters

    How to Finish Floors with TrailBlazer Changing Filters Overtime the fi lter media inside the fi lter housing can become clogged. If your TrailBlazer seems to not be allowing enough fi nish out of the manifold it is possible that the fi lter is clogged.
  • Page 23 How to Finish Floors with TrailBlazer Changing Filters (continued) Insert new fi lter foam into tube. Inserting the tapered end fi rst makes insertion easier. Reattach end caps. Attach new tubing to both ends of the fi lter. Make sure that the tapered end of the fi lter foam is pointing...
  • Page 24 For further information please contact Diversey, Inc. 8310 16th Street Sturtevant, WI 53177-1964 US: 800 558 2332 Canada: 800 668 7171 www.diversey.com ©2012 Diversey, Inc., 8310 16th Street, Sturtevant, WI 53177-1964. All Rights Reserved. LIT90281 (12/074)
