diversey TrailBlazer Troubleshooting Manual

TrailBlazer Troubleshooting
Pump is not moving/
spinning/rotating
1. Is the bail down?
The pump will only operate when the bail is in the
down position
User should verify that the bail is in the
down position
2. Is the TrailBlazer being pulled in the proper direction?
The pump with only move with the bail in the down
position and when the TrailBlazer is pulled in the proper
direction
User should verify that the bail is in the down position
and the unit is being pulled in the proper direction.
3. Is the pump cable tight?
The pump cable (similar to a bicycle brake cable) can
become loose during shipping, installation or after
continued use.
User should tighten the pump cable by following
the proper procedures in the user manual or cable
repair video.
Pump is moving/spinning/
rotating but it is making a
clicking noise
1. Is the pump cable tight?
The pump cable (similar to a bicycle brake cable) can
become loose during shipping, installation or after
continued use.
User should tighten the pump cable by following
the proper procedures in the user manual or cable
repair video.
www.diversey.com
©2010 Diversey, Inc., 8310 16th Street, Sturtevant, WI 53177-1964
LIT30096 (10/133)
Pump is moving but no fi nish
is coming out of the manifold
1. Is the white tap on the fl oor fi nish BIB (bag-in-box)
2. Are the feed lines connected properly?
3. Is the internal pump tube stuck?
Finish is puddling/pooling
at the end of passes
1. Is the bail being moved up early enough?
2. How much of each fi nish pass being overlapped?
TrailBlazer®
turned on?
For fi nish to fl ow out of the BIB the white tap needs to be
in the on position
User should turn the white tap on the BIB to the on
position (towards the baseplate)
The feed lines need to be connected to the proper pump
inlet & outlet to allow fi nish to fl ow
User should verify that the long feed line connector
is attached to the pump inlet on the open side of the
TrailBlazer and the short feed line is connected from
the manifold to the pump outlet on the closed side
of the TrailBlazer.
The internal pump tube can get stuck during long
periods of storage.
User should remove the pump, then use fi ngers
to break any part of the white internal pump tube
that appears stuck. See instruction manual for
detailed information.
When nearing the end of each pass with the TrailBlazer
the bail should be moved to the up position to eliminate
excess fi nish from puddling/pooling up at the end of
each pass.
User should move the bail to the up position no later
than 10' before the end of each pass and as early as 15'.
User should also use the clean up tool to cleanup the
excess fi nish.
It is recommended to only overlap each pass by 3", if
more overlapping is occurring it will cause increased
fi nish on the side of the overlap potentially causing
puddling/pooling of fi nish.
User should operate the TrailBlazer only overlapping
each fi nish pass by no more than 3".
User should also use the clean up tool to cleanup the
excess fi nish.
