Summary of Contents for Kia 2011 RIO

  • Page 2 T115/70D15 : 60 psi Automatic Transaxle Fluid Diamond ATF SP-III, SK ATF SP-III or other brands meeting the SP-III speci- fication approved by Kia Motors Corp. Capacity : 6.5 qts. (6.1 liters) Brake Fluid FMVSS116 DOT-3 or DOT-4 Power Steering Fluid...
  • Page 3 It is a company that has thousands of employees focused on building high-quality vehicles at affordable prices. The first syllable, Ki, in the word “Kia” means “to arise from to the world” or “to come up out of to the world.” The second syllable, a, means “Asia.”...
  • Page 4 Thank you for choosing a Kia vehicle. The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the right to When you require service, remember that your Kia dealer discontinue or change specifications or design at any time knows your vehicle best.
  • Page 5: Table Of Contents

    Introduction Your vehicle at a glance Knowing your vehicle Driving your vehicle Driving tips table of contents In case of an emergency Maintenance Specifications Consumer assistance, Reporting safety defects Index...
  • Page 6: Introduction

    Introduction How to use this manual / 1-2 Vehicle break-in process / 1-2 Proposition 65 warning / 1-3 Vehicle data collection and event data recorders / 1-4...
  • Page 7: Introduction

    Introduction VEHICLE BREAK-IN PROCESS HOW TO USE THIS MANUAL We want to help you get the greatest You’ll find various WARNING’s, No special break-in period is needed. By possible driving pleasure from your vehi- CAUTION’s, and NOTICE’s in this manu- following a few simple precautions for the cle.
  • Page 8: Proposition 65 Warning

    Introduction PROPOSITION 65 WARNING Items contained in motor vehicles or emitted from them are known to the State of California to cause cancer and birth defects or reproductive harm. These include: • Gasoline and its vapors • Engine exhaust • Used engine oil •...
  • Page 9: Vehicle Data Collection And Event Data Recorders

    Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an event These data can help provide a better Your rights with respect to the infor- data recorder (EDR).The main purpose understanding of the circumstances in mation discussed above may vary of an EDR is to record, in certain crash which crashes and injuries occur.
  • Page 10: Your Vehicle At A Glance

    Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...
  • Page 11: Your Vehicle At A Glance

    Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button.....3- 8 2. Outside rearview mirror control switch* ..........3-75 3. Power window switches* ....3-12 4. Master power door lock control* ..3- 7 5. Master power window control lock*...3-14 6. Inside rearview mirror .......3-76 7.
  • Page 12 Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Driver’s air bag ........3-50 2. Light control / Turn signals ....4-31 3. Instrument cluster ......4-20 4. Wiper/Washer........4-35 5. Ignition switch........4- 2 6. Hazard..........4-39 7. Rear window defroster ......4-39 8. Climate control system......4-40 9.
  • Page 13 Your vehicle at a glance ENGINE COMPARTMENT 1. Engine coolant reservoir ....7-14 2. Engine oil filler cap......7-13 3. Brake fluid reservoir ......7-16 4. Air cleaner.........7-20 5. Fuse box ...........6-12 6. Negative battery terminal ..6-10/7-25 7. Positive battery terminal ...6-10/7-25 8. Auto transaxle oil dipstick* ....7-18 9.
  • Page 14: Knowing Your Vehicle

    Keys / 3-2 Remote keyless entry / 3-3 Theft-alarm system / 3-5 Door locks / 3-7 Window / 3-12 Seat / 3-15 Knowing your vehicle Safety belts / 3-25 Air bags-advanced supplemental restraint system / 3-46 Trunk / 3-68 Hood / 3-70 Fuel filler lid / 3-71 Mirrors / 3-74 Interior lights / 3-77...
  • Page 15: Knowing Your Vehicle

    Used to start the engine, lock and CAUTION an authorized Kia dealer to duplicate the unlock the doors, and open the trunk Use only Kia original parts for the keys easily. Remove the plate and store it (if equipped).
  • Page 16: Remote Keyless Entry /

    If you have a problem pressing the lock button and unlock with the transmitter, contact an author- button at the same time for more than ized Kia Dealer. 4 seconds. After pressing this button, the ✽ ✽ NOTICE...
  • Page 17 When replacement is necessary, use the following procedure. For replacement transmitters, see an 1. Insert a slim tool into the slot and gen- WARNING Authorized Kia Dealer for reprogram- tly pry open the transmitter center ming. Changes modifications cover (1).
  • Page 18: Theft-Alarm System /

    Knowing your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Alarm stage When the ignition switch is in the “LOCK” The alarm will activate (horn will sound position, and key is not in the ignition, the and lights flash) when: system will be armed and the hazard •...
  • Page 19 Also, if any of the doors or hood is serviced by an authorized Kia deal- Without immobilizer system: opened while the trunk lid is open and 1. Unlock and open the door with the alarm armed, the alarm will sound.
  • Page 20: Door Locks /

    Knowing your vehicle DOOR LOCKS • If your vehicle is equipped with a remote keyless entry system, all vehi- cle doors will unlock automatically when you unlock the front passenger’s door with a key (if equipped). Unlock • Doors can also be locked and Lock unlocked with the transmitter (if equipped).
  • Page 21 Knowing your vehicle • Front doors cannot be locked if the ignition key is in the ignition switch and door is open. • If you lock the front passenger’s door Unlock Lock with door lock button, all vehicle doors will lock automatically. WARNING - Door lock mal- function...
  • Page 22 Knowing your vehicle Impact sensing door unlock sys- CAUTION - Doors WARNING - Unlocked vehi- tem (if equipped) • The doors should always be fully cles All doors will be automatically unlocked closed and locked while the vehi- Leaving your vehicle unlocked can when the impact is delivered to impact cle is in motion to prevent acci- invite theft or possible harm to you...
  • Page 23 Knowing your vehicle 1. Open the rear door. 2. Push the child safety lock located on the rear edge of the door to the “lock” Lock Unlock position. When the child safety lock is in the “lock ( )” position, rear door will not open when the inner door han- dle is pulled inside the vehicle.
  • Page 24 Knowing your vehicle CAUTION - Rear hatch The rear hatch swings upward. Make sure no objects or people are near the rear of the vehicle when opening the rear hatch. WARNING Exhaust fumes If you drive with the rear hatch open, you will draw dangerous 1JBA3520 exhaust fumes into your vehicle...
  • Page 25: Window /

    Knowing your vehicle WINDOWS Power windows (if equipped) (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch* (4) Rear door (right) power window switch* (5) Window opening and closing (6) Automatic power window down* (Driver’s window) (7) Power window lock switch*...
  • Page 26 Knowing your vehicle ✽ ✽ NOTICE Automatic power window down (driver’s window, if equipped) While driving with the rear windows Depressing the power window switch down or with the sunroof (if equipped) momentarily to the second detent posi- in an open(or partially open) position, tion (6) completely lowers the driver’s your vehicle may demonstrate a wind window even when the switch is...
  • Page 27 Knowing your vehicle CAUTION - Windows • Always double-check to make sure all arms, hands, heads and other obstructions are safely out of the way before closing a win- dow. Serious injury could occur. • Do not allow children to play with the power windows.
  • Page 28 Knowing your vehicle SEAT Driver’s seat (1) Seat adjustment, forward / backward (2) Seatback recliner (3) Seat height adjustment (4) Headrest adjustment Front passenger seat (5) Seat adjustment, forward / backward (6) Seatback recliner (7) Headrest adjustment Rear seat (8) Split folding rear seat* (9) Armrest* (10) Headrest adjustment* * ;...
  • Page 29 Knowing your vehicle WARNING WARNING - Loose objects - Driver’s seat Loose objects in the driver’s foot • Never attempt to adjust seat while area could interfere with the opera- the vehicle is moving. This could tion of the foot pedals, possibly result in loss of control, and an causing an accident.
  • Page 30 Knowing your vehicle WARNING - Driver respon- sibility for front seat pas- senger Driving or riding in a vehicle with a front seatback reclined could lead to serious or fatal injury in an acci- dent. If a front seat is reclined dur- ing an accident, the occupant’s hips may slide under the lap portion of the safety belt applying great force...
  • Page 31 Knowing your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 32 Knowing your vehicle OJB020022 HNF2041-1 1JBA3094 Removal Active headrest (if equipped) Armrest (if equipped) To remove the headrest, raise it as far as The active headrest is designed to move To use the armrest, pull it forward from it can go then press the release button forward and upward during a rear impact.
  • Page 33 Knowing your vehicle Rear seat Split folding rear seat (if equipped) The rear seatbacks fold forward to pro- vide additional cargo space and to pro- vide access to the cargo area. • To fold the rear seatback(s) down, pull the lock release lever, then fold the seatback forward and down.
  • Page 34 Knowing your vehicle (if equipped) 1JBA3027 1JBE3053 1JBA3215 ✽ ✽ NOTICE ✽ ✽ NOTICE - Damaging rear safe- - Rear safety belts ty buckles Routing the safety belt webbing through the rear safety belt guides will help keep When you fold the rear seatback or put the belts from being trapped behind or luggage on the rear seat cushion, insert under the seats.
  • Page 35 Knowing your vehicle CAUTION CAUTION • Make sure the engine is off, the • When returning the rear seat- transaxle is in P and the parking backs to the upright position, brake is applied whenever load- remember to return the rear ing or unloading cargo.
  • Page 36 Knowing your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 37 Knowing your vehicle WARNING Make sure the headrest locks in position after adjusting it to proper- ly protects the occupants. OJB020045 OJB020046 Adjusting the height up and down Removal (if equipped) (if equipped) To remove the headrest, raise it as far as To raise the headrest, pull it up to the it can go then press the release button desired position (1).
  • Page 38: Safety Belts /

    Knowing your vehicle SAFETY BELTS CAUTION The pre-tensioner seat belt is installed at the front seats, and the sensor is equipped inside the buck- le, where presence of passenger is sensed by the fastening of the seat belts. Therefore, pre-tensioner will not activate if the passenger is not fastened with the seat belts.
  • Page 39 • The safety belt must be adjusted while the vehicle is being driven, after they have been worn during to the correct position. please have an authorized Kia deal- a collision. er inspect the pre-tensioner and air • Do not attempt to replace the pre- bag system as soon as possible.
  • Page 40 Knowing your vehicle Safety belt restraint system We strongly recommend that the driver WARNING passengers properly - Child restraint restrained at all times by using the safety in front seat WARNING - Safety belts belts provided with the vehicle. Proper Never install a child restraint sys- To minimize the risk of serious or use of the safety belts decreases the risk...
  • Page 41 Kia dealer • Never swing the safety belt any collision. All belts, retractors, service it immediately. Never drive around your neck to fit over the...
  • Page 42 Knowing your vehicle (Continued) CAUTION WARNING - Safety belt • Never wear the shoulder portion Never close the doors on any part care of the safety belt across the neck of the lap or shoulder belt. It can • A damaged belt may not give you or face.
  • Page 43 Knowing your vehicle If the driver's lap/shoulder belt is not fas- tened when the key is turned ON or if it is disconnected after the key is turned ON, the safety belt warning chime will sound for approximately 6 seconds. (if equipped) If the driver’s lap/shoulder belt is not fas- tened within 30 seconds after the engine is started, the safety belt warning light...
  • Page 44 Knowing your vehicle 1JBH2263 1JBH2264 1JBA3036 3. Insert the tongue plate (1) into the 4. Position the lap portion (1) of the belt 5. Adjust the shoulder anchor position to open end of the buckle (2) until an across your lap as LOW ON THE HIPS your size.
  • Page 45 • Never drive or ride with a twisted or jammed safety belt. If you can- not untwist or unjam the safety belt, see the nearest Kia dealer immediately. • Never use a single belt to restrain more than one person at a time.
  • Page 46 Knowing your vehicle 1JBH2263 1JBH2264 4GQB0338 Rear lap/shoulder belt 4. Position the lap portion (1) of the belt To unfasten: across your lap as LOW ON THE HIPS Press the release button on the buckle To fasten the rear lap/shoulder belt: as possible to reduce the risk of sliding and allow the belt to slowly retract.
  • Page 47 When returning the rear seatbacks to not untwist or unjam the safety the upright position, remember to To fasten the rear center belt belt, see the nearest Kia dealer return the rear shoulder belts to their 1. Insert the tongue plate (A) into the immediately.
  • Page 48 Knowing your vehicle There will be an audible “click” when the tab locks in the buckle. The seat belt automatically adjusts to the proper length only after the lap belt is adjusted manu- ally so that it fits snugly around your hips, if you lean forward in a slow, easy motion, the belt will extend and let you move around.
  • Page 49 Knowing your vehicle WARNING • When using the rear center belt, you must lock all tongue plates and buckles prior to use. If any tongue plate or buckle is not locked, it will increase the chance of injury or death in the event of collision.
  • Page 50 Knowing your vehicle Proper use and care of the safety Restraint of pregnant women Restraint of infants and small belt system children Pregnant women should wear lap/shoul- der belt assemblies whenever possible To ensure that the safety belts provide To increase their safety, infants and the maximum protection, please follow according to specific recommendations young...
  • Page 51 Knowing your vehicle Restraint of larger children WARNING WARNING - Children on - Infants and As children grow, they may need to use laps young children new child-restraint systems, including Never hold a child on your lap or in • Infants and young children are at larger child seats or booster seats, which your arms in a moving vehicle.
  • Page 52 Knowing your vehicle Child restraint system (Continued) For small children and babies, the use of • Since a safety belt or child a child seat or infant seat is strongly rec- restraint system can become very ommended and is required by law in hot if it is in a closed vehicle, be almost all states.
  • Page 53 It will not provide ade- Since all passenger safety belts move by your authorized Kia dealer. quate protection in an accident. freely under normal conditions and only • Failure to observe this manual's •...
  • Page 54 Knowing your vehicle Placing a passenger safety belt into the auto lock mode The auto lock mode will help prevent the normal movement of the child in the vehi- cle from causing the safety belt to loosen and compromise the child restraint sys- tem.
  • Page 55 Knowing your vehicle "Click" MMSA3028 MMSA3029 MMSA3030 3. Pull the shoulder portion of the safety 4. Slowly allow the shoulder portion of 5. Remove as much slack from the belt belt all the way out. When the shoulder the safety belt to retract and listen for as possible by pushing down on the portion of the safety belt is fully an audible “clicking”...
  • Page 56 Knowing your vehicle 4 Door WARNING - Auto lock mode The lap/shoulder belt automatically returns to the “emergency lock mode” whenever the belt is allowed to retract fully. Therefore, the pre- ceding seven steps must be fol- lowed each time a child restraint is installed.
  • Page 57 Knowing your vehicle WARNING - Child restraint check Check that the child restraint sys- Lower Anchor tem is secured by pushing and Position Indicator pulling it in different directions. Incorrectly fitted child restraints may swing, twist, tip or come away causing death or injury.
  • Page 58 Knowing your vehicle Once you have installed the LATCH child WARNING restraint, assure that the seat is properly attached to the LATCH and tether When using the vehicle's "LATCH" anchors. Also, test the child restraint seat system to install a child restraint before you place the child in it.
  • Page 59: Air Bags-Advanced Supplemental Restraint System /

    Knowing your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side impact air bag* (4) Curtain air bag* * : if equipped WARNING Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and...
  • Page 60 Knowing your vehicle What your air bag system does The importance of using Your vehicle’s Supplemental Restraint System Control Module is equipped safety belts Driver’s air bag and front passenger’s air with a recording device that may bag are designed to supplement the pro- There are four very important reasons to record the use or status of the safety tection offered by the safety belt in cer-...
  • Page 61 5. Retractor pre-tensioner assemblies* vehicle towed to an authorized safety belts are fastened, and the severi- 6. Air bag warning light Kia dealer for inspection and nec- ty of the impact. essary repairs. 7. SRS control module (SRSCM) Disregarding this precaution may 8.
  • Page 62 ( ) on the instrument panel will illuminate because the air • Have your car checked by a Kia bag warning light is connected with dealer as soon as possible if the the seat position sensor. If the air SRS warning light comes on.
  • Page 63: Passenger's Air Bag

    Knowing your vehicle WARNING Steering wheel • You must always sit as far back from the steering wheel air bag as possible (chest at least 10 inches (250 mm) away from the steering wheel), while still maintaining a comfortable seating position for good vehicle control, in order to reduce the risk of injury or death 1JBA3056...
  • Page 64 Knowing your vehicle Main components of occupant classi- You will find the "PASSENGER AIR BAG fication system OFF" indicator on the center facia panel. This system detects the conditions 1~4 • Electronic capacity measurement sys- in the following table and activates or tem in the front passenger seat which deactivates the front passenger air bag detects major characteristics of a per-...
  • Page 65 Knowing your vehicle Proper position Condition and operation in the front passenger occupant classification system Indicator/Warning light Devices Condition detected by the "PASSENGER AIR occupant classification Front passenger BAG OFF" indicator SRS warning light system air bag light 1. Adult or child* Activated 2.
  • Page 66 Knowing your vehicle ✽ ✽ NOTICE If the "PASSENGER AIR BAG OFF" indi- WARNING cator is still on, ask the passenger to The "PASSENGER AIR BAG OFF" move to the rear seat. • Even though your vehicle is indicator illuminates for about 4 sec- equipped with the occupant clas- onds after the ignition switch is turned sification system, never install a...
  • Page 67 • Air bags can only be used once – minate and the passenger's front as a blanket or seat heater to the have an authorized KIA dealer air bag will inflate in frontal impact front passenger seat. This can replace the air bag immediately...
  • Page 68 Knowing your vehicle (Continued) (Continued) (Continued) 1KMN3661 1KMN3663 1KMN3665 - Never put a heavy load or an - Never sit with hips shifted - Never place feet on the dash- active electronic device (ex. lap- towards the front of the seat. board.
  • Page 69 • If the driver brakes the vehicle • Do not put heavy objects on the front except by an authorized Kia deal- heavily in urgent situations, occu- passenger's seat. This may cause front using...
  • Page 70 • Never allow children, pregnant 1JBA3057/1JBA3058 have the vehicle checked and women or weak persons to sit in repaired by an authorized Kia the front passenger seat. They dealer. Inform them that your may be seriously injured by the vehicle is equipped with side air...
  • Page 71 Curtain air bag (if equipped) air bag system. This should only Importantly, children should sit in be done by an authorized Kia Curtain air bags are located along both a proper child restraint system in dealer. sides of the roof rails above the front and the rear seat.
  • Page 72 Knowing your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-inflation conditions of the air bag) There are many types of accidents in which one or more of the air bags would not be expected to provide additional protection.
  • Page 73 In the event of a colli- unexpected air bag deployment, sion, have the vehicle inspected which could result in severe per- by an authorized Kia dealer. sonal injury or death. • Your vehicle has been designed • If the installation location or...
  • Page 74 Knowing your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collision, it may inflate in any collision if front impact sen- sors detect a sufficient impact. Side air bags (side and/or curtain air bags) are designed to inflate only in side impact collision, it may inflate in any collision if side impact sensors detect a sufficient...
  • Page 75 Knowing your vehicle 1JBB3520 1JBA3516 1JBA3521 • Frontal air bags are not designed to • Front air bags may not inflate in side • In a slant or angled collision, the force inflate in rear collisions, because occu- impact collision, because occupants of impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
  • Page 76 Knowing your vehicle 1JBA3517 1JBA3522 1JBA3518 • Just before impact, drivers often brake • Air bags may not inflate in rollover acci- • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the dents because air bag deployment collides with objects such as utility front portion of the vehicle causing it to would not provide proper protection to...
  • Page 77 Knowing your vehicle Air bag system operation • In order to help provide protection in a WARNING - severe collision, the air bags must Seated • Air bags only operate when the ignition inflate rapidly. The speed of air bag positioning switch is turned to the ON or START inflation is a consequence of the...
  • Page 78 Knowing your vehicle Noise and smoke WARNING Hot air bag When the air bags inflate, they make a parts loud noise and they leave smoke and When the air bags deploy, the air powder in the air inside of the vehicle. bag related parts in steering wheel This is normal.
  • Page 79 This tem as far away from the door must be done by an authorized Kia side as possible, and secure the dealer. child restraint system to be W7-147 •...
  • Page 80 • Any work on the air bag system, such as removing, installing, or repairing the steering wheel must be performed by a qualified Kia technician. Improper handling of 1JBN3519/1JBA3073/1JBN3074 the air bag system including the...
  • Page 81 Knowing your vehicle TRUNK (IF EQUIPPED) PROPOSITION 65 WARN- Engine exhaust and a wide variety of automobile components and parts, including components found in the interior furnishings in a vehi- cle, contain or emit chemicals known to the State of California to cause cancer and birth defects and reproductive harm.
  • Page 82 Knowing your vehicle WARNING No one should be allowed to occu- py the trunk of the vehicle at any time. If the trunk is partially or total- ly latched and the person is unable to get out, severe injury or death could occur due to lack of ventila- tion, exhaust fumes and rapid heat build-up, or because of exposure to...
  • Page 83 Knowing your vehicle HOOD 1JBA3078 1JBA3080 1JBA3081 Opening the hood: 2. Go to the front of the vehicle, raise the 3. Lift the hood and hold it open with the hood slightly, pull the secondary latch support rod by inserting the free end of 1.
  • Page 84: Fuel Filler Lid /

    Knowing your vehicle FUEL FILLER LID Closing the hood 4 Door - Hood CAUTION 1. Before closing the hood, check the fol- • Before closing the hood, make lowing: sure that all engine parts and • All filler caps in engine compartment tools have been removed from must be correctly installed.
  • Page 85 Knowing your vehicle (Continued) WARNING - Refueling • Before touching the fuel nozzle, If pressurized fuel sprays out, it can you should eliminate potentially cover your clothes or skin and thus dangerous static electricity dis- subject you to the risk of fire and charge by touching another metal burns.
  • Page 86 • If the fuel filler cap requires replace- cle, and immediately contact the • Do not use cellular phones while ment, use only a genuine Kia cap or manager of the gas station and refueling. Electric current and/or the equivalent specified for your vehi-...
  • Page 87: Mirrors /

    Knowing your vehicle MIRRORS Outside rearview mirror CAUTION Be sure to adjust mirror angles before • The right outside rearview mirror driving. is convex. Objects seen in the Your vehicle is equipped with both left- mirror are closer than they hand and right-hand outside rearview appear.
  • Page 88 Knowing your vehicle ✽ ✽ NOTICE • The mirrors stop moving when they reach the maximum adjusting angles, but the motor continues to operate while the switch is depressed. Do not depress the switch longer than neces- sary, the motor may be damaged. •...
  • Page 89: Inside Rearview Mirror

    Knowing your vehicle Outside rearview mirror heater Inside rearview mirror Day/Night lever (if equipped) Adjust the rearview mirror to center on The outside rearview mirror heater is the view through the rear window. Make automatically turned on when the rear this adjustment before you start driving.
  • Page 90: Interior Lights /

    Knowing your vehicle INTERIOR LIGHTS OJB029091 1JBA3091 OAM049053 Map light (if equipped) Type B Dome light (if equipped) (1) Map light Type A (1) OFF : The lights are turned ON or OFF by The lights are turned ON or OFF by : The light stays off even when a door pressing the corresponding switch.
  • Page 91: Multi Box*

    Knowing your vehicle STORAGE COMPARTMENT ✽ ✽ NOTICE ✽ ✽ NOTICE Do not use the interior lights for extend- • To avoid possible theft, do not leave ed periods when engine is not running. valuables in the storage compartment. It may cause battery discharge. •...
  • Page 92: Glove Box

    Knowing your vehicle INTERIOR FEATURES 1JBA3095 OJB028096 OJB020100 Glove box Sunglass holder (if equipped) Cup holder To open the glove box, pull the handle (1) A sunglass storage compartment is pro- Cups or small beverage cans may be and the glove box will automatically open vided on the overhead console.
  • Page 93: Power Socket

    Knowing your vehicle ✽ ✽ NOTICE • Use the power outlet when the engine is running, and remove a plug from the power outlet after using the elec- tric appliance. Using the power outlet excessively or while the engine is not running or leaving appliances plugged into the power outlet when not in use will cause battery discharge...
  • Page 94 Knowing your vehicle • HOUR: Pressing the “H” button with your fin- ger, a pencil or similar object will advance the time displayed by one hour. • MINUTE: Pressing the “M” button with your fin- ger, a pencil or similar object will advance the time displayed by one minute.
  • Page 95: Sunroof /

    Knowing your vehicle SUNROOF (IF EQUIPPED) Sliding the sunroof Autoslide open To use the autoslide feature, momentar- ily (less than 0.4 second) press the SLIDE OPEN button on the overhead console. The sunroof will slide all the way open. To stop the sunroof sliding at any point, press any sunroof control button.
  • Page 96: Luggage Net /

    Knowing your vehicle LUGGAGE NET (IF EQUIPPED) ✽ ✽ NOTICE Resetting the sunroof 4 Door • Do not press any sunroof control but- Whenever the vehicle battery is discon- ton longer than necessary. Damage to nected or discharged, you have to reset the motor or system components your sunroof system as follows: could occur.
  • Page 97: Floor Mat Anchor(S) /

    Knowing your vehicle FLOOR MAT ANCHOR(S) ANTENNA (IF EQUIPPED) ✽ ✽ NOTICE Do not put fragile, bulky or an excessive quantity of items into luggage net. They could be damaged. WARNING To avoid eye injury, DO NOT over- stretch the netting. ALWAYS keep face and body out of recoil path of the net, in case of strap.
  • Page 98: Audio Remote Control /

    Knowing your vehicle AUDIO REMOTE CONTROL (IF EQUIPPED) CDP mode VOLUME ( ) (1) It will function as the TRACK UP/DOWN • Push up the lever to increase volume. button. • Push down the lever to decrease vol- ume. CDC mode It will function as the TRACK UP/DOWN SEEK/PRESET ( ) (2)
  • Page 99: Audio System /

    Knowing your vehicle AUDIO SYSTEM - HOW CAR AUDIO WORKS ✽ ✽ NOTICE FM reception AM reception If you install an after market HID head lamp, your vehicle’s audio and electron- ic device may malfunction. JBM001 JBM002 AM and FM radio signals are broadcast This is because AM radio waves are from transmitter towers located around transmitted at low frequencies.
  • Page 100 Knowing your vehicle FM radio station JBM003 JBM004 JBM005 • Station Swapping - As a FM signal FM broadcasts are transmitted at high • Fading - As your car moves away from frequencies and do not bend to follow the the radio station, the signal will weaken weakens, another more powerful sig- earth's surface.
  • Page 101 Knowing your vehicle Satellite radio reception • If you are driving on a mountain road Using a cellular phone or a two- where is blocked by mountains. way radio You may experience problems in receiv- ing SIRIUS satellite radio signals in the When a cellular phone is used inside the following situations.
  • Page 102 Knowing your vehicle • Keep CDs in their cases after use to Care of disc (if equipped) protect them from scratches or dirt. • If the temperature inside the car is too • Depending on the type of CD-R/CD- high, open the car windows for ventila- RW CDs, certain CDs may not operate tion before using your car audio.
  • Page 103 Knowing your vehicle RADIO, SET UP, VOLUME, AUDIO CONTROL(PA910L, SIRIUS SATELLITE RADIO MODEL) (IF EQUIPPED) 1. FM/AM Selection Button 2. Automatic Channel Selection Button 3. Power ON/OFF Button & Volume Control Knob 4. Preset Button 5. Manual Channel Selection & Sound Quality Control Knob 6.
  • Page 104 Knowing your vehicle 1. FM/AM Selection Button 4. Preset Button TREBLE Control To increase the TREBLE, rotate the knob Turns to FM or AM mode, and toggles in Push [1]~[6] buttons less than 0.8 sec- ond to play the channel saved in each clockwise, while decrease...
  • Page 105 Knowing your vehicle 6. SETUP Button Press this button to access the SIRIUS option, TEXT SCROLL, and adjustment mode. If no action is taken for 5 seconds after pressing the button, it will return to the play mode.(After entering SETUP mode, move between items using the left, right and PUSH functions of the [TUNE] button.) The setup item changes from TEXT...
  • Page 106 Knowing your vehicle CDP, AUX(PA910L, SIRIUS SATELLITE RADIO MODEL) (IF EQUIPPED) 1. CD Loading Slot 2. CD Eject Button 3. CD Selection Button 4. AUX Selection Button 5. Automatic Track Selection Button 6. RANDOM Play Button 7. REPEAT Button 8. SEARCH Knob & ENTER Button 9.
  • Page 107 Knowing your vehicle 1. CD Loading Slot 5. Automatic Track Selection 7. REPEAT Button Button Please face printed side upward and gen- Press this button for less than 0.8 second tly push in. When the ignition switch is on to activate ‘RPT’ mode and more than 0.8 •...
  • Page 108 Knowing your vehicle 10. INFO Button (Continued) CAUTION IN USING Displays the information of the current • Depending on the condition of USB DEVICE CD TRACK(FILE) as indicated below the external USB device, the con- • To use an external USB device, when the button is pressed each time.
  • Page 109 Knowing your vehicle (Continued) (Continued) (Continued) • If you dismount the external USB • If USB device is divided by logical • Please avoid using USB memory device during playback in USB drives, only the music files on the products which can be used as mode, the external USB device can highest-priority drive are recog- key chains or cellular phone...
  • Page 110 Knowing your vehicle USING USB(PA910L, SIRIUS SATELLITE RADIO MODEL) (IF EQUIPPED) 1. USB Selection Button 2. TRACK Moving Button 3. RANDOM Playback Button 4. REPEAT Button 5. SEARCH Knob & ENTER Button 6. FOLDER Moving Button 7. INFO Selection Button 8.
  • Page 111 Knowing your vehicle 1. USB Selection Button 3. RANDOM Playback Button 6. FOLDER Moving Button If USB is connected, it switches to the Press this button for less than 0.8 second • Press [FOLDER ] to access the first USB mode from the other mode to play to activate 'RDM' mode and more than sub folder of the current folder and play the song files stored in the USB.
  • Page 112 Knowing your vehicle iPod ® RUNNING (PA910L, SIRIUS SATELLITE RADIO MODEL) (IF EQUIPPED) 1. iPod Selection Button 2. TRACK Moving Button 3. RANDOM Playback Button 4. REPEAT Button 5. CATEGORY Selection Button 6. SEARCH Knob & ENTER Button 7. INFO Selection Button ®...
  • Page 113 Knowing your vehicle In case the iPod exclusive cable is con- 3. RANDOM Playback Button 6. SEARCH Knob & ENTER nected to the multiple terminal inside the Button Press the button for less than 0.8 second console on the right hand side of the dri- to activate or deactivate the random play- When you turn the button clockwise, it ver's seat.
  • Page 114 Knowing your vehicle ✽ ✽ NOTICE FOR USING iPod (Continued) CAUTION IN USING • When the iPod cable is connected, DEVICE iPod DEVICE the system can be switched to the • Some iPod models might not sup- • You need the power cable exclu- AUX mode even without the iPod port the communication protocol sive for an iPod in order to oper-...
  • Page 115 Knowing your vehicle SIRIUS Satellite Radio information (if equipped) Satellite radio channels: SIRIUS Satellite Radio service: NOTE: SIRIUS Satellite Radio has over 130 chan- SIRIUS Satellite Radio is a subscription- ® Satellite Radio requires SIRIUS com- nels, including 69 channels of 100% com- based satellite radio service that broad- patible receiver and a subscription serv- mercial-free music, plus sports, news, talk...
  • Page 116 Knowing your vehicle SIRIUS SATELLITE RADIO(PA910L, SIRIUS SATELLITE RADIO MODEL) (IF EQUIPPED) 1. SATELLITE RADIO Selection Button 2. Channel Selection Button 3. Preset Selection Button 4. TUNE Knob and ENTER Button 5. CAT/FOLDER Button 6. INFO Selection Button 7. SETUP Button 8.
  • Page 117 Knowing your vehicle How to Use SIRIUS Satellite 2. Channel Selection Button 5. CAT/FOLDER Button Radio • Press [TRACK ] or [SEEK ] but- • Press [CAT ] or [FOLDER ] button ton for less than 0.8 second to select to enter the Category List Mode, it dis- Your vehicle is equipped with a 3 month previous or next channel.
  • Page 118 If no action is taken for 5 seconds after unplugged. Please consult with your pressing the button, it will return to the pre- Kia dealership. vious radio mode.(After entering SETUP mode, move between items using the 2. Acquiring Signal...
  • Page 119 Knowing your vehicle ✽ ✽ NOTICE 4. CALL button : Places and transfers BLUETOOTH PHONE OPERATION calls. • The phone must be paired to the sys- 5. END button : Ends calls or cancels ® tem before using Bluetooth features. fonctions.
  • Page 120 Knowing your vehicle NOTE: (continued) CAUTION IN USING The phone needs to be paired again • Do not place the phone near or ® BLUETOOTH CELLU- after changing system language. inside metallic objects, otherwise LAR PHONE - Avoid resting your thumb or finger ®...
  • Page 121 Knowing your vehicle ■ ■ Voice Recognition Activation • At any time if you say “help” or “what Voice Operation Tip can I say?”, the system will announce • The voice recognition engine contained To get the best performance out of the what commands are available.
  • Page 122 Knowing your vehicle <Recognization> - By Manual Operation: Note: 1) Push the TUNE knob to enter SETUP • The pairing procedure of the phone mode. varies according to each phone model. Before attempting to pair phone, please see your phone’s User’s Guide for instructions.
  • Page 123 - Select “SELECT” in PHONE menu, vehicles of the same model, i.e. both then select desired phone from the list. 8. The audio displays “searching ---- vehicles are KIA Rio, some phones ® passkey: 0000” and asks you to initiate may not handle Bluetooth pairing procedure from the phone.
  • Page 124 Knowing your vehicle ■ ® Phone Book (In-Vehicle) • Changing Priority • Adjusting Bluetooth Volume ® When several phones are paired to the Bluetooth system volume can be • Adding Entry audio system, the system attempts to adjusted separately from main volume of Phone numbers and voice tags can be connect following order when the the audio system.
  • Page 125 Knowing your vehicle ✽ ✽ NOTICE • Adding Entry by Phone • Deleting Name 1. Press button. The registered names can be deleted. • The system can recognize single digits from zero to nine. Numbers that are 2. Say "Phonebook". 1.
  • Page 126 Knowing your vehicle ■ ■ • Dialing by Number Receiving a Phone Call Talking on the Phone A phone call can be made by dialing the When receiving a phone call, a ringtone When talking on the phone, “Active Calls” spoken numbers.
  • Page 127 Knowing your vehicle ■ Using the head unit as Bluetooth NOTE: music • Not only MP3 files, all the sounds that the phone supports can be The head unit supports A2DP (Audio heard by the audio system. Advanced Distribution Profile) AVRCP (Audio Video Remote Control •...
  • Page 128: Driving Your Vehicle

    Ignition switch / 4-2 Starting the engine / 4-3 Manual transaxle / 4-4 Automatic transaxle / 4-6 Brake system / 4-9 Cruise control system / 4-14 Steering wheel / 4-18 Instrument cluster / 4-20 Driving your vehicle Gauges / 4-21 Warnings and indicators / 4-25 Lighting / 4-31 Wipers and washers / 4-35...
  • Page 129: Ignition Switch

    Driving your vehicle IGNITION SWITCH ACC (Accessory) START The steering wheel is unlocked and elec- Turn the ignition key to the START posi- trical accessories are operative. tion to start the engine. The engine will crank until you release the key; then it returns to the ON position.
  • Page 130: Starting The Engine

    Driving your vehicle STARTING THE ENGINE Whether the engine is cold or warm, it CAUTION WARNING - Ignition key should be started without depressing Always wear appropriate shoes the accelerator. • Never turn the ignition switch to when operating your vehicle.
  • Page 131: Shift Lever

    Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) Manual transaxle operation The manual transaxle has five forward gears. Press the clutch pedal down fully while shifting, then release it slowly. The gearshift lever must be returned to the neutral position before shifting into R (Reverse).
  • Page 132 Driving your vehicle ✽ ✽ NOTICE Downshifting When you must slow down in heavy traf- To avoid premature clutch wear and fic or while driving up steep hills, down- damage, do not drive with your foot shift before the engine starts to labor. resting on the clutch pedal.
  • Page 133 Driving your vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Automatic transaxle operation All normal forward driving is done with the shift lever in the D (Drive) position. To move the shift lever from the P (Park) position, the brake pedal must be depressed and the lock release button must be pressed.
  • Page 134 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE (Continued) Always come to a complete stop before • To avoid damage to your transaxle, do • Do not use the P (Park) position in shifting into or out of R (Reverse); you not accelerate the engine in R place of the parking brake.
  • Page 135 Driving your vehicle 2 (Second Gear) O/D OFF Indicator ( Use 2 (Second Gear) for more power This indicator light illuminates in the when climbing hills and for increased instrument panel when the O/D mode is braking when going down hills. This posi- cancelled.
  • Page 136: Brake System

    Driving your vehicle BRAKE SYSTEM Shift lock system Power brakes WARNING - Parking brake For your safety, the Automatic Transaxle Your vehicle has power-assisted brakes Pulling the parking brake while the has a shift lock system which prevents that adjust automatically through normal vehicle is moving at normal speeds shifting the transaxle out of P (Park) usage.
  • Page 137 Driving your vehicle ✽ ✽ NOTICE (Continued) To avoid costly brake repairs, do not • Wet brakes may result in the vehi- continue to drive with worn brake pads. cle not slowing down at the usual rate and pulling to one side when the brakes are applied.
  • Page 138 Driving your vehicle WARNING - Parking brake • To prevent unintentional move- ment when stopped and leaving the vehicle, do not use the gearshift lever in place of the parking brake. Set the parking brake make sure gearshift lever is securely posi- tioned in 1st (First) gear or R (Reverse) for manual transaxle equipped vehicles and in P (Park)
  • Page 139 Driving your vehicle Parking on curbed streets Anti-lock brake system (ABS) The ABS continuously senses the speed of the wheels. If the wheels are going to (if equipped) • When parking your vehicle on an uphill lock, the ABS repeatedly modulates the grade, park as close to the curb as hydraulic brake pressure to the wheels.
  • Page 140 ABS is nor- mal. Otherwise, you may have a prob- lem with the ABS. Contact an author- W-78 ized Kia dealer as soon as possible. ✽ ✽ NOTICE ✽ ✽ NOTICE • If the ABS warning light is on and...
  • Page 141 Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) The cruise control system allows you to (Continued) program the vehicle to maintain a con- • Pay particular attention to the stant speed without resting your foot on driving conditions whenever the accelerator pedal. using the cruise control system.
  • Page 142 Driving your vehicle ✽ ✽ NOTICE On steeper hills, with a Manual Transaxle, the cruise control may be unable to maintain the set speed. The driver should downshift as necessary. Press the "RES/+" button to resume the cruise control at the set speed in the new gear.
  • Page 143 Driving your vehicle To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
  • Page 144 Driving your vehicle Each of these actions will cancel cruise To turn cruise control off, do one control operation (the SET indicator light of the following: in the instrument cluster will go off), but it • Push the CRUISE ON-OFF button (the will not turn the system off.
  • Page 145: Steering Wheel

    RPM by depressing the accelerator until ing checked by an authorized Kia dealer. ment panel warning lights and gauges. the RPM reaches 1,500 rpm then release ✽ ✽ NOTICE or let the engine idle for two or three minutes to warm up the fluid.
  • Page 146 Driving your vehicle CAUTION - Horn • To sound the horn, press the area indicated by the horn symbol on your steering wheel (see illustra- tion). The horn will operate only when this area is pressed. • Do not strike the horn severely to operate it, or hit it with your fist.
  • Page 147: Instrument Cluster

    Driving your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Engine temperature warning light 5. Warning and indicator lights 6. Odometer / Tripmeter ■ ■ 7. Shift position indicator Type B (Automatic transaxle only) 8.
  • Page 148 Driving your vehicle GAUGES Speedometer Fuel gauge ■ Type A The speedometer indicates the forward The fuel gauge indicates the approxi- speed of the vehicle. mate amount of fuel remaining in the fuel tank. Fuel tank capacity - 11.9 gallons Tachometer (45 liters) The tachometer indicates the approxi-...
  • Page 149 Driving your vehicle ■ Type A OJB040036A OJB049009 Trip computer (if equipped) Mode Press the TRIP button for less than 1 sec- The trip computer is a microcomputer- ond to select each function as follows : controlled driver information system that OJB049009/OJB040037N displays information related to driving, AMBIENT TEMPERATURE...
  • Page 150 Driving your vehicle OJB040038N OJB040039N OJB040040N Ambient temperature Tripmeter Instant fuel consumption This mode indicates the current ambient This mode indicates the total distance This mode calculates the instant fuel temperature. The meter’s working range - traveled since the last tripmeter reset. consumption every 2 seconds from the 40°F to 176°F.
  • Page 151 Driving your vehicle ✽ ✽ NOTICE • If the vehicle is not on level ground or the battery power has been interrupt- ed, the “DISTANCE TO EMPTY” function may not operate correctly. The trip computer may not register additional fuel if less than 6 liters of fuel are added to the vehicle.
  • Page 152: Instrument Panel Illumination*

    Checking operation All warning lights are checked by turning the ignition switch ON (do not start the engine). Any light that does not illuminate should be checked by an authorized Kia dealer. ■ Type B After starting the engine, check to make sure that all warning lights are off.
  • Page 153 Have the ✽ ✽ NOTICE adding oil or if oil is not available, call an vehicle checked by an authorized Kia authorized Kia dealer. If the red engine temperature warning dealer as soon as possible.
  • Page 154 Have an authorized will blink for 6 seconds. This cycle will Kia dealer correct the problem as soon Parking brake warning repeat 11 times with an interval of 24 as possible.
  • Page 155 6 seconds each time the brakes do not operate properly. warning you turn the ignition switch to the ON Have it towed to any authorized Kia position. dealer for a brake system inspection and necessary repairs. If this indicator does not go out, or if it illu-...
  • Page 156 OFF mode by pressing the age is possible. This could result ized Kia dealer as soon as possible. TRIP button. in loss of engine power. Have the • When the instant fuel consumption...
  • Page 157 Driving your vehicle Cruise SET indicator Manual transaxle shift ECOMINDER WARNING indicator (if equipped) Don't keep watching the “ECO” ECOMINDER indicator while driv- This indicator informs you which gear is The indicator illuminates when the cruise ing. It may distract you while driv- desired while driving to save fuel.
  • Page 158 Driving your vehicle LIGHTING Safety belt warning chime Battery saver function (if equipped) (if equipped) • The purpose of this feature is to pre- If the driver's seat belt is not fastened vent the battery from being dis- when the ignition key is turned “ON” or if charged.
  • Page 159 Driving your vehicle OSA049091 OSA049092 OSA049093 High - beam operation Parking light position ( Headlight position ( When the light switch is in the parking To turn on the high beam headlights, When the light switch is in the headlight light position (1st position), the tail, posi- push the lever away from you.
  • Page 160 Driving your vehicle Lane change signals (B) To signal a lane change, move the turn signal lever slightly and hold it in position. The lever will return to the OFF position when released. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.
  • Page 161: Front Fog Light*

    Driving your vehicle 1JBA4054 Front fog light (if equipped) Fog lights are used to provide improved visibility and avoid accidents when visibili- ty is poor due to fog, rain or snow etc. The fog lights will turn on when the fog light but- ton is pressed after the headlight switch is turned on.
  • Page 162: Wiper/Washer

    Driving your vehicle WIPERS AND WASHERS A : Wiper speed control Windshield wiper/washer Rear window wiper/washer · MIST – Single wipe (if equipped) · OFF – Off · INT – Intermittent wipe · LO – Low wiper speed · HI – High wiper speed B : Intermittent wipe time adjustment C : Wash with brief wipes D : Rear wiper/washer control...
  • Page 163 Driving your vehicle ✽ ✽ NOTICE Before using the windshield wipers when there is a heavy accumulation of snow or ice on the windshield, defrost the windshield for about 10 minutes, or until the snow or ice is removed. This will help ensure proper windshield wiper operation and will prevent dam- age to the wiper blades, wiper linkage,...
  • Page 164 Driving your vehicle ✽ ✽ NOTICE • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry. • To prevent damage to the wiper blades, do not use gasoline, kerosene, paint thinner, or other solvents on or near them.
  • Page 165 Driving your vehicle ✽ ✽ NOTICE To prevent possible damage to the wash- er pump, do not operate the washer when the fluid reservoir is empty. WARNING Do not use the washer in freezing temperatures without first warming the windshield with the defrosters; the washer solution could freeze on contact with the windshield and obscure your vision.
  • Page 166: Hazard

    Driving your vehicle DEFROSTER HAZARD WARNING FLASHER (Continued) • If you want to defrost and defog on front windshield, refer “Windshield Defrosting Defogging” in this section. To activate the rear window defroster, press the rear window defroster button located in the center console switch panel.
  • Page 167: Climate Control System

    Driving your vehicle CLIMATE CONTROL SYSTEM (IF EQUIPPED) 1. Temperature control knob 2. Air conditioning button (if equipped) 3. Air intake control button 4. Mode selection knob 5. Fan speed control knob OJB040200L...
  • Page 168 Driving your vehicle OJB040201L OJB040202L OJB040203L Fan speed control knob Temperature control knob Mode selection knob Four (4) adjustable fan speeds are pro- The temperature control knob allows you The mode selection knob controls the vided which increase as the number to control the temperature of the air flow- direction of the air flow through the venti- increases.
  • Page 169 Driving your vehicle MAX/ A/C position (if equipped) When you select the MAX A/C mode while the fan is on, the following system settings will be made automatically; • the air conditioning system will be turned on. • the recirculated air position will be selected.
  • Page 170 Driving your vehicle Face - floor position Air flow is directed towards the face and the floor. The air to the floor is warmer than the air to the face (except when the temperature control is set to the extreme cold position).
  • Page 171 Driving your vehicle ✽ ✽ NOTICE Recirculated air position WARNING The indicator light on the but- It should be noted that prolonged oper- ton is illuminated when the • Continued use of the climate con- ation of the heating in recirculated air recirculated air position is trol system in the recirculated air position will cause fogging of the wind-...
  • Page 172 Driving your vehicle Air conditioning (if equipped) System operation All Kia Air Conditioning Systems are Ventilation filled with environmentally friendly 1. Set the mode to the position. R-134a refrigerant which is not damag- 2. Set the air intake control to the outside ing to the ozone layer.
  • Page 173 Driving your vehicle ✽ ✽ NOTICE Air conditioning system opera- • The air conditioning system includes a function that automatically turns the air tion tips • When using the air conditioning sys- conditioning compressor off if engine tem, monitor the temperature indica- •...
  • Page 174: Windshield Defrosting And Defogging

    CAUTION OJB040207L OJB040206L The air conditioning system should To defrost outside windshield be serviced by an authorized Kia Manual climate control system 1. Set the fan speed to the “3” or “4” posi- dealer. Improper service may cause tion. To defog inside windshield serious injury.
  • Page 175 Driving your vehicle • For maximum defrosting, set the tem- CAUTION perature control to the extreme right/hot position and the fan speed Do not use the position control to the highest speed. during cooling operation extremely humid weather. The dif- •...
  • Page 176: Driving Tips

    Fuel requirements / 5-2 Emission control system / 5-2 Before driving / 5-4 Suggestions for economical operation / 5-5 Special driving conditions / 5-6 Vehicle load limit / 5-10 Weight of the vehicle / 5-15 Trailer towing / 5-15 Label information / 5-16 Driving tips...
  • Page 177: Fuel Requirements

    The emission control system of your drivability problems occur. vehicle is covered by a written limited Your new Kia vehicle is designed to use warranty. Please see the warranty infor- Vehicle damage or driveability problems only unleaded fuel with a minimum mation contained in the Warranty &...
  • Page 178 All inspections and adjustments flammable items under your vehi- your vehicle, drive it only with all the must be made by an authorized Kia cle. Do not park, idle or drive the windows fully open. Have your vehicle dealer.
  • Page 179: Before Driving

    Driving tips BEFORE DRIVING Before entering vehicle: Before starting WARNING - Driving under • Be sure that all windows, outside mir- • Close and lock all doors. the influence of alcohol or ror(s), and outside lights are clean. • Position the seat so that all controls are drugs •...
  • Page 180: Suggestions For Economical Operation

    Keeping a vehicle in good operating con- roads. dition is important both for economy and • For longer tire life and better fuel econ- safety. Therefore, have an authorized Kia omy, always keep the tires inflated to dealer perform scheduled inspections the recommended pressures.
  • Page 181: Special Driving Conditions

    Driving tips SPECIAL DRIVING CONDITIONS Hazardous driving conditions • If stalled in snow, mud, or sand, use Rocking the vehicle second gear. Accelerate slowly to When hazardous driving conditions are If it is necessary to rock the vehicle to avoid spinning the drive wheels. encountered such as water, snow, ice, free it from snow, sand, or mud, first turn •...
  • Page 182 Driving tips Driving at night Driving in the rain Winter driving Because night driving presents more Rain and wet roads can make driving • We recommend that you carry emer- hazards than driving in the daylight, here dangerous, especially if you’re not pre- gency equipment, including tire chains, are some important tips to remember: pared for the slick pavement.
  • Page 183 Driving tips ✽ ✽ NOTICE Snow tires If you mount snow tires on your Kia, • Make sure the snow chains are the make sure they are radial tires of the correct size and type for your tires. same size and load range as the original Incorrect snow chains can cause dam- tires.
  • Page 184 Driving tips Chain installation Driving in flooded areas WARNING - Tire chains When installing chains, follow the manu- Avoid driving through flooded areas facturer's instructions and mount them as • The use of chains may adversely unless you are sure the water is no high- tightly as you can.
  • Page 185: Vehicle Load Limit

    Driving tips VEHICLE LOAD LIMIT Tire and loading information label Seating capacity: Type A The label located on the driver's door Total : 5 persons sill gives the original tire size, cold (Front seat : 2 persons, tire pressures recommended for your Rear seat : 3 persons) vehicle, the number of people that Seating capacity is the maximum...
  • Page 186 Driving tips Steps for determining correct 5. Determine the combined weight of Example 1 load limit luggage and cargo being loaded on the vehicle. That weight may 1. Locate the statement "The com- not safely exceed the available bined weight of occupants and cargo and luggage load capacity cargo should never exceed XXX calculated in Step 4.
  • Page 187 Driving tips Refer to your vehicle's tire and load- Example 2 Example 3 ing information label for specific information about your vehicle's capacity weight and seating posi- tions. The combined weight of the driver, passengers and cargo should never exceed your vehicle's capacity weight.
  • Page 188 Driving tips This label also tells you the maxi- WARNING Over loading mum weight that can be supported by the front and rear axles, called • Never exceed the GVWR for Gross Axle Weight Rating (GAWR). your vehicle, the GAWR for either the front or rear axle To find out the actual loads on your and vehicle capacity weight.
  • Page 189 Driving tips ✽ ✽ NOTICE WARNING Loose cargo • Overloading your vehicle may Items you carry inside your cause damage. Repairs would not vehicle can strike and injure be covered by your warranty. Do occupants in a sudden stop or not overload your vehicle.
  • Page 190: Weight Of The Vehicle

    Driving tips WEIGHT OF THE VEHICLE TRAILER TOWING This section will guide you in the GAW (Gross axle weight) We do not recommend using this proper loading of your vehicle and/or vehicle for trailer towing. This is the total weight placed on trailer, to keep your loaded vehicle each axle (front and rear) - including weight within its design rating capa-...
  • Page 191: Label Information

    Driving tips LABEL INFORMATION VIN (if equipped) Identification label (if equipped) Frame number OJB059004L Compliance label (if equipped) 1JBA5003 1JBA5005 The VIN is also on a plate attached to the Vehicle identification number top of the dashboard. The number on the (VIN) plate can easily be seen through the The vehicle identification number (VIN) is...
  • Page 192 Driving tips The vehicle certification label attached on the driver’s side center pillar gives the vehicle identification number (VIN). OJB059009N OJB060002 Tire specification and pressure Engine number label The engine number is stamped on the engine block as shown in the drawing. The tires supplied on your new vehicle are chosen to provide the best perform- ance for normal driving.
  • Page 193: In Case Of An Emergency

    Road warning / 6-2 In case of an emergency while driving / 6-2 Tires pressure monitoring system (TPMS) / 6-3 Overheating / 6-8 Emergency starting / 6-9 Electrical circuit protection / 6-12 Towing / 6-18 If you have a flat tire / 6-23 In case of an emergency...
  • Page 194: Road Warning

    In case of an emergency ROAD WARNING IN CASE OF AN EMERGENCY WHILE DRIVING • The hazard warning flasher operates whether your vehicle is running or not. If the engine stalls at a crossroad or crossing • The turn signals do not work when the hazard flasher is on.
  • Page 195: Tires Pressure Monitoring System (Tpms)

    3. Try to start the engine again. If your stop and check your tires as soon as vehicle will not start, contact an possible, and inflate them to the authorized KIA dealer or seek other proper pressure. Driving on a signif- qualified assistance. icantly under-inflated tire causes the...
  • Page 196 In case of an emergency Your vehicle has also been equipped Low tire pressure tell- CAUTION - Changing tem- with a TPMS malfunction indicator to tale peratures indicate when the system is not In winter or cold weather, the operating properly. The TPMS mal- When the tire pressure monitoring low tire pressure telltale may be function indicator is provided by a...
  • Page 197 TPMS malfunction indicator. starter or navigation etc., are used Have the system checked by an in the vehicle. This can interfere authorized KIA dealer as soon as pos- with normal operation of the Tire sible to determine the cause of the Pressure Monitoring problem.
  • Page 198 A cold tire means the vehicle has nate after restarting and about 20 KIA dealer as soon as possible or been sitting for 3 hours and driven for minutes of continuous driving. replace the flat tire with the tempo- less than 1 mile (1.6 km) in that 3...
  • Page 199 In case of an emergency This device complies with Part 15 WARNING WARNING TPMS - Protecting of the FCC rules. TPMS • The TPMS cannot alert you to Operation is subject to the following severe and sudden tire dam- Tampering with, modifying, or two conditions: age caused by external fac- disabling the Tire Pressure...
  • Page 200 Call and stop your vehicle; set the automat- an authorized Kia dealer for assis- ic transaxle in P (Park), or shift the tance. If you do not find a leak or other...
  • Page 201: Emergency Starting

    In case of an emergency EMERGENCY STARTING Jump starting WARNING - Battery Jump starting can be dangerous if done • Keep all flames or sparks away incorrectly. Therefore, to avoid harm to from the battery. The battery pro- yourself or damage to your vehicle or duces hydrogen gas which may battery, follow the jump starting proce- explode if exposed to flame or...
  • Page 202 In case of an emergency Connecting jumper cables Jump starting procedure 1. Make sure the booster battery is 12- Connect cables in numerical order and disconnect in reverse order. volt and that its negative terminal is grounded. 2. If the booster battery is in another vehicle, do not allow the vehicles to touch.
  • Page 203 2,000 rpm, then start the engine of the vehi- cle with the discharged battery. If the cause of your battery discharging is not apparent, you should have your vehi- cle checked by an authorized Kia dealer. 6 11...
  • Page 204: Electrical Circuit Protection

    Blown Normal the system involved and immediately proper fuse - even as a temporary 1LDA4002 consult an authorized Kia dealer. repair. It may cause extensive Fuses Two kinds of fuses are used: standard for wiring damage and possibly a lower amperage rating and main for high- A vehicle’s electrical system is protected...
  • Page 205 Spare fuses are provided in the fuse panel in engine compartment. 6. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer. 6 13...
  • Page 206: Fuse Box

    4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. 4. Reinstall in the reverse order of removal. If it fits loosely, consult an authorized Kia dealer. ✽ ✽ NOTICE If the MAIN fuse is blown, consult an...
  • Page 207 In case of an emergency Fuse/Relay panel description Engine compartment Inside the fuse/relay box covers, you can find the fuse/relay Description Fuse rating Protected component label describing fuse/relay name and capacity. BATT_1 Alternator, Battery ECU A Engine control unit Engine compartment Radiator fan COND Condenser fan...
  • Page 208 In case of an emergency Description Fuse rating Protected component Driver-side knee bolster FUEL PUMP Fuel pump relay RAD FAN Radiator fan relay COND FAN2 Condenser fan relay FUEL HTR Fuel filter heater relay BLOWER Blower motor relay START Start motor relay COND FAN1 Condenser fan relay A/CON...
  • Page 209 In case of an emergency Driver-side knee bolster Description Fuse rating Protected component Description Fuse rating Protected component RR WIPER Rear wiper HTD GLASS Rear window defroster H/LP(LH) Headlight (left) A/BAG Air bag FR WIPER Front wiper Automatic transaxle control BLOWER Blower SNSR...
  • Page 210 If emergency towing is necessary, we recommend having it done by an author- Your vehicle is equipped with a memory ized Kia dealer or a commercial tow-truck fuse to prevent battery discharge if your service. Proper lifting and towing proce-...
  • Page 211 In case of an emergency When towing your vehicle in an emer- gency without wheel dollies : 1. Set the ignition switch in the ACC posi- tion. 2. Place the transaxle shift lever in N (Neutral). 3. Release the parking brake. ✽...
  • Page 212 In case of an emergency Tie-down hook 1JBA6028/1JBA6029 OJB060015 Tie-down hook Front towing hook (for flatbed towing) 1. Open the trunk lid or rear hatch, and remove the towing hook from the tool bag. CAUTION 2. Remove the hole cover pressing the Do not use the hooks under the front of the vehicle for towing purposes.
  • Page 213 • Using a portion of the vehicle other If towing is necessary, we recommend than the tow hooks for towing may you to have it done by an authorized Kia damage the body of your vehicle. dealer or a commercial tow truck service.
  • Page 214 • Turn the ignition switch to ACC so the the towing. Contact an authorized in contact with the surface. steering wheel isn’t locked. Kia dealer or a commercial tow truck service for assistance. • Place the transaxle shift lever in N (Neutral).
  • Page 215: If You Have A Flat Tire

    In case of an emergency IF YOU HAVE A FLAT TIRE CAUTION - Automatic transaxle • If the car is being towed with all four wheels on the ground, it can be towed only from the front. Be sure that the transaxle is in neu- tral.
  • Page 216 In case of an emergency Important - use of compact spare The compact spare should be inflat- • Avoid driving over obstacles. The tire ed to 60 psi (420 kPa). compact spare tire diameter is smaller than the diameter of a con- Your vehicle is equipped with a com- ventional tire and reduces the ✽...
  • Page 217 In case of an emergency Changing tires (Continued) Jacking instructions • The vehicle can easily roll off The jack is provided for emergency jack causing serious tire changing only. injury or death. No person Follow jacking instructions to reduce should place any portion of the possibility of personal injury.
  • Page 218 In case of an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diago- nally opposite the wheel being changed. • It is recommended that the wheels of the vehicle be chocked, and that no person should remain in a vehicle that...
  • Page 219 In case of an emergency OJB048024 1JBA6025 OJB048026 7. Loosen the wheel lug nuts coun- 8. Place the jack at the front or rear 9. Insert the jack handle into the jack terclockwise one turn each, but do jacking position closest to the tire and turn it clockwise, raising the not remove any nut until the tire you are changing.
  • Page 220 If in doubt, consult an author- specified pressure, if necessary. station. The specified tightening ized Kia dealer. Refer to Section 8, Specifications. torque is 65-79 lb•ft (9~11 kg•m, 88-107 N•m). Improperly tight- ened wheel lug nuts could cause brake pedal vibration while brak- ing.
  • Page 221 Maintenance services / 7-2 Normal maintenance / 7-3 Maintenance under severe usage conditions / 7-7 Owner maintenance / 7-8 Engine compartment / 7-11 Engine oil / 7-13 Engine cooling system / 7-14 Brake fluid / 7-16 Drive belts / 7-17 Power steering / 7-17 Automatic transaxle / 7-18 Lubricants and fluids / 7-19...
  • Page 222: Maintenance Services

    • Extensive use of brakes. have an authorized Kia dealer perform shown on the following pages. You need • Driving in areas where salt or other this work. this information to establish your compli- corrosive materials are being used.
  • Page 223: Maintenance

    Maintenance NORMAL MAINTENANCE SCHEDULE MAINTENANCE Number of Months or Miles, whichever comes first INTERVALS Months MAINTENANCE Miles x 1,000 ITEM Replace every 7,500 miles or 12 months Engine oil and filter At first, replace at 120,000 miles or 120 months; Engine coolant (1), (2) after that, replace every 30,000 miles or 24 months Fuel filter...
  • Page 224 Maintenance NORMAL MAINTENANCE SCHEDULE (CONTINUED) MAINTENANCE Number of Months or Miles, whichever comes first INTERVALS Months MAINTENANCE Miles x 1,000 ITEM Manual transaxle fluid* Inspect every 40,000 miles or 48 months (LEVEL AND CONDITION) Automatic transaxle fluid* Inspect every 40,000 miles or 48 months (LEVEL AND CONDITION) Cooling system (3) Drive shaft and boots*...
  • Page 225 Maintenance NORMAL MAINTENANCE SCHEDULE (CONTINUED) MAINTENANCE Number of Months or Miles, whichever comes first INTERVALS Months MAINTENANCE Miles x 1,000 ITEM Inspect visually the following items 1) Battery condition 2) Bake fluid / clutch* fluid 3) Brake lines, hoses and connections 4) Brake pedal and operation 5) Chassis/body nuts and bolts 6) Drum brake and linings*...
  • Page 226 Maintenance NORMAL MAINTENANCE SCHEDULE (CONTINUED) MAINTENANCE Number of Months or Miles, whichever comes first INTERVALS Months MAINTENANCE Miles x 1,000 ITEM Inspect visually the following items 13) Parking brakes 14) Steering operation and linkage 15) Suspension mounting bolts Climate control air filter Air conditioning compressor / Air conditioner refrigerant / performance* I : Inspect and if necessary, adjust, correct, clean or replace.
  • Page 227: Maintenance Under Severe Usage Conditions

    Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...
  • Page 228: Owner Maintenance

    • Check coolant level in coolant reser- inspections that should be performed by in the vehicle. voir. the owner or an authorized Kia dealer at • Check for vibrations in the steering the frequencies indicated to help ensure wheel. Notice any increased steering...
  • Page 229 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check coolant level in the coolant • Clean body and door drain holes. recovery reservoir. • Check radiator, heater and air condi- •...
  • Page 230 If you're unsure about any when you wear jewelry or loose servicing or maintenance procedure, clothing. These become have it done by an Authorized Kia entangled in moving parts and Dealer. result in injury. Always remove all loose or hanging clothing and all jewelry before working on the engine.
  • Page 231: Engine Oil Filler Cap

    Maintenance ENGINE COMPARTMENT ■ ■ Type A 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Air cleaner 5. Fuse box 6. Negative battery terminal 7. Positive battery terminal 8. Auto transaxle oil dipstick (if equipped) 9.
  • Page 232: Engine Coolant Reservoir

    Maintenance ■ ■ Type B 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Air cleaner 5. Fuse box 6. Negative battery terminal 7. Positive battery terminal 8. Auto transaxle oil dipstick (if equipped) 9. Radiator cap 10.
  • Page 233: Engine Oil

    To avoid poten- 4. Pull the dipstick out, wipe it clean, and tial engine damage, use only the speci- re-insert it fully. fied filter. Consult an authorized Kia dealer. WARNING - Radiator hose Be very careful not to touch the...
  • Page 234: Engine Cooling System

    Maintenance ENGINE COOLING SYSTEM The high-pressure cooling system has a ■ Type A (Continued) reservoir filled with year-round antifreeze • Turn the engine off and wait until coolant. The reservoir is filled at the fac- it cools down. Use extreme care tory.
  • Page 235 Bring the level to F, but do not overfill. If frequent Mixture Percentage (volume) additions are required, see an authorized Ambient Kia dealer for a cooling system inspec- Temperature tion. Coolant Water Solution Engine coolant 5°F (-15°C)
  • Page 236 A few drops of mineral-based oil, such an authorized Kia dealer. the reservoir cap thoroughly to prevent as engine oil, in your brake/clutch sys- brake fluid contamination.
  • Page 237: Drive Belts

    If the belt is too loose, have it adjusted by • The use of the non-specified fluid voir periodically. The fluid should be an authorized Kia dealer. could reduce the effectiveness of the between MAX and MIN marks on the...
  • Page 238 Maintenance AUTOMATIC TRANSAXLE (IF EQUIPPED) WARNING - Transaxle fluid The transaxle fluid level should be checked when the engine is at nor- mal operating temperature. This means that the engine, radiator, radiator hose and exhaust system etc., are very hot. Exercise great care not to burn yourself during this procedure.
  • Page 239: Lubricants And Fluids

    Do not drink and avoid contacting ✽ ✽ NOTICE windshield washer fluid. Serious Check the fluid level in the washer fluid Have an Authorized Kia dealer inspect reservoir and add fluid if necessary. Plain injury or death could occur. or change the automatic transaxle fluid...
  • Page 240 3. Replace the air cleaner element. We recommend that the air cleaner ele- This element may be air cleaned or ment be replaced with genuine Kia replaced, depending on its condition. parts. Unless it is very dirty, merely shake it to 4.
  • Page 241: Climate Control Air Filter

    (fresh) are position is selected. If this happens, have the climate control air fil- ter replaced by an Authorized Kia Dealer. 7 21...
  • Page 242 Maintenance 1JBA7014 1JBA7013 1JBA7016 Filter replacement 3. Replace the climate control air filter. 4. Reassemble in the reverse order of 1. With the glove box open, remove the disassembly. stoppers on both sides and allow the glove box to hang freely on the hinges. ✽...
  • Page 243: Wiper Blades

    Maintenance WIPER BLADES Wiper blade maintenance Windshield wiper blade replace- ment Commercial hot waxes applied by automatic car washes have been When the wipers no longer clean ade- known to make the windshield diffi- quately, the blades may be worn or cult to clean.
  • Page 244 Maintenance 1JBA7037 1JBA7047 1JBA7048 Rear window wiper blade 2. Install the new blade assembly by replacement (if equipped) inserting the center part (1) into the slot (2) in the wiper arm until it clicks 1. Raise the wiper arm and pull out the into place.
  • Page 245 Maintenance BATTERY (Continued) (Continued) WARNING - Battery • When lifting a plastic-cased bat- dangers If any electrolyte gets into tery, excessive pressure on the your eyes, flush your eyes Always read the following case may cause battery acid to with clean water for at least instructions carefully when leak, resulting in personal injury.
  • Page 246 Maintenance Battery recharging (Continued) Your vehicle has a maintenance-free, • Do not allow cigarettes, sparks, or calcium-based battery. flame near the battery. • If the battery becomes discharged in a • Watch the battery during charg- short time (because, for example, the ing, and stop or reduce the charg- headlights or interior lights were left on ing rate if the battery cells begin...
  • Page 247: Tires And Wheels

    Maintenance TIRES AND WHEELS Tire care For proper maintenance, safety, and maximum fuel economy, you must always maintain recommended tire inflation pressures and stay within the load limits and weight distribution recommended for your vehicle. Recommended cold tire inflation pressures All tire pressures (including the OJB059009N OJB050900N...
  • Page 248 How to check and potential injury. refilling, have it checked by an Use a good quality gage to check tire Authorized Kia Dealer. pressure. You can not tell if your tires • Overinflation produces a harsh are properly inflated simply by look-...
  • Page 249 Maintenance Remove the valve cap from the tire Tire rotation Without a spare tire valve stem. Press the tire gage firm- To equalize tread wear, it is recom- ly onto the valve to get a pressure mended that the tires be rotated measurement.
  • Page 250 However, if you notice unusual tire new Kia and should be mounted on wear or your vehicle pulling one way the same compact spare tire wheel. or the other, the alignment may need...
  • Page 251 ABS (Antilock equip your vehicle with any Brake System) tire/wheel combination not rec- (Electronic Stability Control) (If ommended by Kia for off road equipped) to work irregularly. driving, you should not use these tires for highway driving. (Continued) 7 31...
  • Page 252 Maintenance 2. Tire size designation Tire maintenance A tire’s sidewall is marked with a tire In addition to proper inflation, correct size designation. You will need this wheel alignment helps to decrease information when selecting replace- tire wear. If you find a tire is worn ment tires for your car.
  • Page 253 Maintenance 3. Checking tire life (TIN : Tire 86 - Load Index, a numerical code Tire speed ratings Identification Number) associated with the maximum The chart below lists many of the dif- load the tire can carry. ferent speed ratings currently being Any tires that are over 6 years, based on the manufacturing date, tire used for passenger cars.
  • Page 254 These grades are molded on the nal or bias ply construction; and the side-walls of passenger vehicle tires. letter "B" means belted-bias ply con- The tires available as standard or struction. optional equipment on Kia vehicles may vary with respect to grade.
  • Page 255 Maintenance Traction - AA, A, B & C Tire terminology and defini- WARNING - Tire The traction grades, from highest to tions temperature lowest, are AA, A, B and C. The Air Pressure: The amount of air grades represent the tires ability to The temperature grade for this inside the tire pressing outward on stop on wet pavement as measured...
  • Page 256 Maintenance Cold Tire Pressure: The amount of Intended Outboard Sidewall: The Occupant Distribution: Designated seating positions. air pressure in a tire, measured in side of an asymmetrical tire, that must always face outward when pounds per square inch (psi) or kilo- Outward Facing Sidewall: The side pascals (kPa) before a tire has built mounted on a vehicle.
  • Page 257 All season tires code assigned to a tire indicating the Tire: Load on an individual tire due to Kia specifies all season tires on curb and accessory weight plus maximum speed at which a tire can some models to provide good per- operate.
  • Page 258 Maintenance ✽ ✽ NOTICE Snow tires WARNING - Snow or ice If you equip your car with snow tires, • If you hear noise caused by chains • When driving on roads cov- they should be the same size and contacting the body, retighten the ered with snow or ice, drive at have the same load capacity as the...
  • Page 259: Bulb Replacement

    Prior to working on the lights, firm- an authorized Kia dealer. In many cases, ly apply the parking brake, ensure it is difficult to replace vehicle light that the ignition switch is turned to bulbs because other parts of the vehicle the “LOCK”...
  • Page 260 Maintenance (Continued) • If a bulb becomes damaged or cracked, replace it immediately and carefully dispose of it. • Wear eye protection when chang- ing a bulb. Allow the bulb to cool down before handling it. 1LDA7048 1JBA7022 1. Open the hood. 2.
  • Page 261 8. Install the headlight bulb cover by turn- If the light bulb is not operating, have the 1. Open the hood. ing it clockwise. vehicle checked by an authorized Kia 2. Remove the socket from the assembly dealer. turning socket...
  • Page 262 Maintenance Interior bulb replacement Front map lamp Center dome lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. CAUTION Prior to working on the Interior Lights, ensure that the “OFF” but- ton is depressed to avoid burning your fingers or receiving an electric 1JBA7040 OAM079038...
  • Page 263 Maintenance 4 Door 4 Door 1JBB6017 OJB078028 5 Door 5 Door 1JBA7026 License plate light bulb replace- ment 1. Remove the lens. 2. Remove the bulb by pulling it straight out. 3. Install a new bulb. OJB070022 1JBA7042 4. Reinstall the lens securely. Rear combination light bulb 2.
  • Page 264 Maintenance 5. Insert a new bulb by inserting it into 4 Door 4 Door the socket and rotating it until it locks into place. 6. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly.
  • Page 265 If the light bulb does not operate, have into place. the vehicle checked by an authorized KIA 5. Install the socket in the housing by dealer. aligning the tabs on the socket with the slots in the housing.
  • Page 266: Lubricant Specifications

    DIAMOND ATF SP-III, SK ATF SP-III, Temperature (°F) 100 120 or other brands meeting the SP-III Automatic transaxle 10W-30 specification approved by Kia Motors fluid Engine Oil * 5W-20, 5W-30 Corp. Power steering fluid PSF-III . For better fuel economy, it is recommended to use...
  • Page 267: Exterior Care

    Maintenance EXTERIOR CARE Exterior general caution After washing, rinse the vehicle thor- oughly with lukewarm or cold water. Do It is very important to follow the label not allow soap to dry on the finish. directions when using any chemical cleaner or polish.
  • Page 268 Maintenance Waxing Finish damage repair Underbody maintenance Wax the vehicle when water will no Deep scratches or stone chips in the Corrosive materials used for ice and longer bead on the paint. painted surface must be repaired snow removal and dust control may col- Always wash and dry the vehicle before promptly.
  • Page 269: Interior Care

    Maintenance INTERIOR CARE Interior general precautions Aluminum wheel maintenance Cleaning the upholstery and inte- Prevent caustic solutions such as per- rior trim The aluminum wheels are coated with a fume and cosmetic oil from contacting clear protective finish. Vinyl the dashboard because they may cause •...
  • Page 270: California Perchlorate Notice

    Maintenance CALIFORNIA PERCHLORATE NOTICE Cleaning the lap/shoulder belt Perchlorate Material-special handling may apply, See www.dtsc.ca.gov/haz- webbing ardouswaste/perchlorate. Clean the belt webbing with any mild Notice to California Vehicle Dismantlers: soap solution recommended for cleaning Perchlorate containing materials, such as upholstery or carpet. Follow the instruc- airbag inflators, seatbelt pretensioners tions provided with the soap.
  • Page 271: Specifications

    Specifications / 8-2 Specifications...
  • Page 272 The specifications given here are for general information only. Although this information was accurate at the time of printing, Kia reserves the right to change its vehicles or their specifications without notice. Please check with an authorized Kia dealer for more precise and more up-to-date information.
  • Page 273 Specifications Engine Weights Refer to the label describing GVWR & GAWR weights Item Gasoline Engine attached to your vehicle. BoreXStroke 3.01 in X 3.43 in (76.5 mm X 87 mm) (see page 5-16, Label information) Displacement 1599 cc (97.6 cu.in) Compression Ratio 10.0 ±...
  • Page 274 6.5 US qt. Front fog lights (if equipped) or other brands meeting the fluid (6.1 l) Front side mark light SP-III specification approved by Kia Motors Corp. Stop and tail lights 27/8 28/8 Power steering 0.8 US qt. Rear turn signal lights...
  • Page 275: Consumer Assistance, Reporting Safety Defects

    Toll free assistance / 9-2 Emergency roadside assistance / 9-2 Trip interruption / 9-3 Registering your vehicle in a foreign country / 9-3 Electrical equipment / 9-4 Reporting safety defects / 9-5 Online factory authorized manuals (U.S. only) / 9-6 Consumer assistance, Reporting safety defects...
  • Page 276 We have access to a network of over 10,000 locksmiths to help you should you become locked out of your Kia, also at KMA reserves the right to limit or deny services or other bene- no charge.
  • Page 277 3. There may not be an Authorized Kia Dealer in the area in which you plan to register your vehicle. You may additionally experience difficulty in obtaining services in a foreign country for any number of reasons.
  • Page 278 Authorized Kia Dealer, in order to ensure systems may be adversely affected. To avoid damage to your that you do not void your warranty.
  • Page 279 Consumer assistance, Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) Kia motor vehicles are designed and manufactured to meet or If you believe that your vehicle has a defect which could exceed all applicable safety standards. cause a crash or could cause injury or death, you should...
  • Page 280 Consumer assistance, Reporting safety defects ONLINE FACTORY AUTHORIZED MANUALS (U.S. ONLY) following publications available www.KiaTechInfo.com at no charge. Service Manual: This manual covers maintenance and recommended pro- cedures for repair to engine and chassis components.It is written for the Journeyman mechanic, but is simple enough for most mechanically-inclined owners to under- stand.
  • Page 281 Index...
  • Page 282 Index Battery············································································7-25 Air bags··········································································3-46 Battery saver function····················································4-31 Air bag warning label··················································3-67 Before driving ··································································5-4 Air bag warning light ··················································3-66 Bottle holders, see cup holders······································3-79 Curtain air bag ·····························································3-58 Brake system····································································4-9 Driver's air bag ····························································3-50 Anti-lock brake system (ABS) ····································4-12 Front passenger's air bag ·············································3-50 Parking brake·······························································4-10 Occupant classification system ···································3-51 Power brakes··································································4-9...
  • Page 283 Index Compact spare tire ·························································6-24 Compact spare tire replacement ····································7-30 California Perchlorate Notice ········································7-50 Consumer assistance························································9-2 Capacities (Lubricants)····················································8-4 Coolant···········································································7-14 Care Cooling fluid, see engine coolant ··································7-14 Exterior care ································································7-47 Cruise control system ····················································4-14 Interior care ·································································7-49 Cup holder ·····································································3-79 Tire care·······································································7-27 Curtain air bag ·······························································3-58 Cargo capacity ·······························································5-10 Cargo weight··································································5-15...
  • Page 284 Index Fuel filler lid ··································································3-71 Fuel gauge······································································4-21 Fuel requirements ····························································5-2 Economical operation ······················································5-5 Fuses ··············································································6-12 Emergency starting ··························································6-9 Fuse/relay panel description········································6-15 Jump starting ·································································6-9 Main fuse ·····································································6-14 Push starting ································································6-11 Memory fuse································································6-18 Emergency trunk safety release ·····································3-68 Emergency while driving·················································6-2 Emission control system··················································5-2 Engine compartment ··············································2-4, 7-11 Gauge...
  • Page 285 Index Ignition key interlock system ··········································4-9 Jack and tools·································································6-23 Indicators and warnings·················································4-25 Jump starting····································································6-9 Instrument cluster ··························································4-20 Fuel gauge ···································································4-21 Instrument panel illumination ·····································4-25 Odometer ·····································································4-21 Key positions ···································································4-2 Speedometer ································································4-21 Keys ·················································································3-2 Tachometer ··································································4-21 Trip computer ······························································4-22 Tripmeter ·····································································4-22 Warning and indicators················································4-25 Label Instrument panel illumination········································4-25...
  • Page 286 Index Lighting··········································································4-31 Battery saver function··················································4-31 Occupant classification system······································3-51 Low tire pressure telltale ·················································6-4 Odometer ·······································································4-21 Lower anchor system·····················································3-44 Oil (Engine) ···································································7-13 Lubricants and capacities·················································8-4 Outside rearview mirror·················································3-74 Luggage net (holder) ·····················································3-83 Overheats ·········································································6-8 Owner maintenance ·························································7-8 Main fuse ·······································································6-14 Maintenance Parking brake ·································································4-10 Maintenance services·····················································7-2 Passenger's front air bag ················································3-50...
  • Page 287: Spare Tire

    Index Road warning···································································6-2 Special driving conditions ···············································5-6 Rocking the vehicle ·························································5-6 Driving at night ·····························································5-7 Driving in flooded areas ················································5-9 Driving in the rain ·························································5-7 Hazardous driving conditions········································5-6 Rocking the vehicle ·······················································5-6 Safety chains··································································5-16 Speedometer···································································4-21 Scheduled maintenance service ·······································7-2 Starting the engine ···························································4-3 Normal maintenance schedule·······································7-3 Steering wheel ·······························································4-18 Maintenance under severe usage conditions ·················7-7...
  • Page 288 Index Tires pressure monitoring system (TPMS)······················6-3 Transaxle Changing a tire with TPMS···········································6-6 Automatic transaxle·······················································4-6 Low tire pressure telltale ···············································6-4 Manual transaxle ···························································4-4 TPMS (Tire pressure monitoring system) Tripmeter········································································4-22 malfunction indicator ··················································6-5 Trip computer ································································4-22 Tire specification and pressure label ·····························5-17 Trunk··············································································3-68 Tires and wheels·····················································7-27, 8-2 Emergency trunk safety release···································3-69...
  • Page 289 Index Warnings and indicators ················································4-25 Weight ············································································5-15 Base curb weight ·························································5-15 Cargo weight ·······························································5-15 GAW (Gross axle weight) ···········································5-15 GAWR (Gross axle weight rating) ······························5-15 GVW (Gross vehicle weight) ······································5-15 GVWR (Gross vehicle weight rating)·························5-15 Wheel alignment and tire balance ·································7-30 Wheel replacement ························································7-31 Windows ········································································3-12 Power window lock switch··········································3-14...

This manual is also suitable for:

Rio

Table of Contents

Save PDF
