Page 3: Table Of Contents
Table of Contents 1. Before You Begin..........................3 What Is Included ..........................3 Claims ..............................3 Manual Conventions ..........................3 Symbols ............................... 3 Safety Notes ............................4 Expected LED Lifespan ........................4 2. Introduction ............................5 Description ............................5 Features ............................... 5 Overview .............................. - Page 4 Art-Net™ ............................. 20 Kling-Net Mapper ..........................21 Part 1: Confirm Network Connectivity .................... 21 The Connected Devices Window ....................22 Part 2: Test Network Connectivity ....................22 Part 3: Map The Products For ArKaos ................... 23 Nexus Software Upgrade Instructions ....................24 DMX Channel Assignments And Values ...................
-
Page 5: Before You Begin
If the box or the product and included accessories appear damaged from shipping or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Safety Notes
This product contains no user-serviceable parts. Any reference to servicing in this User Manual will only apply to properly trained Chauvet certified technicians. Do not open the housing or attempt any repairs. -
Page 7: Introduction
Introduction 2. Introduction Nexus™ 4x1 is a tour-ready wash light with a pixel mappable display of four 27-watt RGB Description COB LEDs. The combination of circuit on board (COB) emitters and a clever reflector design create a soft, brilliant, light with saturated hues. The Nexus™ 4x1 operates in Standalone mode or with the Kling-Net, Art-Net™, or DMX protocols. -
Page 8: Overview
Introduction Overview Coffin Lock Holes Yoke Adjustment COB LED (x4) Knob Front View Side View -3-Pin DMX Ports 5-Pin DMX Ports Control Panel Ethernet I/O Bracket Power Ports Rear View Coffin Locks Top View Nexus™ 4x1 User Manual Rev. 3... -
Page 9: Dimensions
Introduction Dimensions Pixel Layout Nexus™ 4x1 User Manual Rev. 3... -
Page 10: Setup
Sizing Circuit Breakers from Chauvet website www.chauvetprofessional.com. · Always connect this product to a protected circuit with an appropriate electrical ground. · Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel serves only as a 0 to 100% switch. -
Page 11: Power Linking
· Up to 7 products at 208 V · Up to 8 products at 230 V. A power cord is included but power-linking cables are not included. For power-linking cables, see the Chauvet website at www.chuavetlighting.com. Power Linking Diagram Another Products... -
Page 12: Dmx Linking
Setup DMX Linking connects Nexus™ 4x1 panels through their DMX input and output ports. The DMX Linking Nexus™ 4x1 has both 3- and 5-pin DMX ports, so either 3- or 5-pin cables, or a combination of both, can be used. DMX Linking is for DMX control and for Master/Slave control. DMX Controller or Master DMX Linking Diagram... -
Page 13: Master/Slave Mode
· Master/Slave operates via DMX ports only. The etherCON® ports cannot be used for Master/Slave mode. For more information about DMX, see the CHAUVET® DMX primer, available at www.chauvetlighting.com Ethernet connections link Nexus™ 4x1 panels to routers and each other through their Ethernet etherCON®... -
Page 14: Kling-Net Mode
For more information, see Art-Net™. For more information about Art-Net™, see the Art-Net™ protocol document available on the Chauvet website at www.chauvetlighting.com. Nexus™ 4x1 panels do not work with Art-Net™ controllers sending in Broadcast mode. For information about the controller’s mode, see the controller’s User Manual... -
Page 15: Mounting
The hanging bracket can be bolted directly onto a surface, or be connected to truss with clamps. For a complete lines of CHAUVET® clamps, see the Chauvet website at www.chauvetlighting.com. Nexus™ 4x1 User Manual Rev. 3... -
Page 16: Mounting Diagram
Setup Floor Mounting Wall Mounting Mounting Diagram Align Panels Using Coffin Locks And A #5 Allen Key Pipe Or Truss Mounting Use the coffin locks only to align the Nexus™ 4x1 panels. The coffin locks are not load bearing. Do not hang the panels by the coffin locks. -14- Nexus™... -
Page 17: Operation
Operation 4. Operation Control Panel Button Function <MENU> Scrolls through the main menu or exits from the current menu or function Enables the currently displayed menu or sets the currently selected value in to <ENTER> the current function Navigates upward through the menu list or increases the numeric value when <UP>... -
Page 18: Menu Map
Operation Menu Map Main Level Programming Levels Description Auto 1–9 Selects Auto programs 0–8 and speed control Auto Show Show Speed 000–100 Fade 1–2 Selects color fades 1–2 and speed control Fixture Color Selects a preset colors Static Manual Color 000–255 Sets color levels for manual color mixing Dimmer Mode... -
Page 19: Menu Operations
Operation The menu operations set configurations for the Nexus™ 4x1, including built-in programs to Menu operate the Nexus™ 4x1 without a DMX controller. The menu operations are accessed via the Operations control panel. For more information, see Control Panel. Setting changes are not activated until the control panel display returns to the home screen. To return the control panel display to the home screen press and hold <MENU>... -
Page 20: Info
Operation Info shows information about the Nexus™ 4x1. To show information, do the following: Info 1. Select the desired program level based on the information required. 2. Press <MENU> to return to the home screen. · Fixture Hours – The amount of time the product has been in use ·... -
Page 21: White
Operation White sets the color temperature of the white produced when the DMX values of Red Green White and Blue are at 255 or 100%. To set the color temperature, do the following: 1. Go to the White main level. 2. -
Page 22: Art-Net
Operation To set the Nexus™ 4x1 to Art-Net, do the following: Art-Net™ 1. Press <MENU> and then <DOWN>. Ethernet Settings shows in the display. 2. Press <ENTER>. 3. If <Art-Net> shows in the display, go to Step 7 below to configure Art-Net™ settings. If <Kling-Net>... -
Page 23: Kling-Net Mapper
Operation Kling-Net Mapper is part of the Arkaos software package and is used to inform The ArKaos Kling-Net software about the layout of the Nexus™ 4x1 panels. This process is called mapping. Mapper Kling-Net Mapper and ArKaos software can be run simultaneously allowing the operator to see immediately the effects of the mapping on the live presentation. -
Page 24: The Connected Devices Window
Operation It can take up to 20 seconds for all the products to populate the list and the devices display in The Connected different colors for different reasons, which are as follows: Devices Window Colors and Activity Explanation There is connectivity and everything is working properly, Black with an ID number and IP address but the device is not yet mapped. -
Page 25: Part 3: Map The Products For Arkaos
Operation Part 3: Map The 10. Make sure the Nexus™ 4x1 products are all listed in the Connected Devices window and have flashed when tested. For more information, see Part 1: Confirm Network Products For Connectivity Part 2: Test Network Connectivity. -
Page 26: Nexus Software Upgrade Instructions
Operation Nexus Software Upgrade Instructions The following steps refer to the Windows® 7 operating system environment. Step 1: 1. Connect the Nexus™ 4x1 to the router. 2. Verify the computer is using the same network as the Nexus™ 4x1 product. Step 2: 1. - Page 27 Operation Step 5: 1. Select the desired network the product is connected to. If you are running a hard-wired line from the PC to your router, then select Local Area Connection. The Local Area Connection Status dialog appears. 2. Click Properties. The Local Area Connection Properties dialog appears.
- Page 28 1 min before to reset. Step 12: 1. Navigate to the Info main level. 2. Select Version. 3. Verify the product’s control panel displays the uploaded CHAUVET Lighting version. Nexus™ 4x1 v. x.xx The software upgrade is now complete. -26-...
- Page 29 Operation Step 13: Once the software upgrade is complete, the IP setting on your PC needs to be changed back to the original settings. 1. Refer to step #4 for navigation instructions on how to access Internet Protocol Version Properties (TCP/IPv4) dialog.
-
Page 30: Dmx Channel Assignments And Values
Operation DMX Channel Assignments And Values The following tables show the DMX channel function assignments and the values that trigger the functions. 17-Channel 17 CH Channel Function Value Percent/Setting Red 1 0–100% 000 ó 255 Warm White 1 When values 011-020 in CH. 17 are activated Green 1 0–100% 000 ó... -
Page 31: 12-Channel
Operation 12-Channel 12 CH Channel Function Value Percent/Setting 000 ó 255 Red 1 0–100% 000 ó 255 Green 1 0–100% 000 ó 255 Blue 1 0–100% 000 ó 255 Red 2 0–100% 000 ó 255 Green 2 0–100% 000 ó 255 Blue 2 0–100% 000 ó... -
Page 32: 5-Channel
Operation 9 Ch Channel Function Value Percent/Setting 000 ó 010 No Function 011 ó 033 Auto 1 034 ó 055 Auto 2 056 ó 077 Auto 3 078 ó 099 Auto 4 100 ó 121 Auto 5 Auto Programs 122 ó 144 Auto 6 145 ó... -
Page 33: Technical Information
Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. · Clearly label the package with an RMA number. Chauvet will refuse any product returned without an RMA number. -
Page 34: Technical Specifications
Technical Specifications 6. Technical Specifications Dimensions and Length Width Height Weight Weight 18.2 in (462 mm) 4.6 in (117 mm) 5.8 in (147 mm) 12.6 lb (5.7 kg) Dimensions in inches rounded to the nearest decimal digit. Electrical Power Supply Type Range Voltage Selection Switching (internal) -
Page 35: Contact Us
(954) 577-4455 Email: tech@chauvetlighting.com Fax: (954) 929-5560 World Wide Web Toll free: (800) 762-1084 www.chauvetlighting.com UNITED KINGDOM AND IRELAND - Chauvet Europe Ltd. General Information Technical Support Address:Unit 1C Email: uktech@chauvetlighting.com Brookhill Road Industrial Estate World Wide Web Pinxton, Nottingham, UK NG16 6NT www.chauvetlighting.co.uk...
