WARNINGS AND CAUTIONS DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. WARNING: Improper installation, adjustment, alteration, services or maintenance can cause injury, death or property damage.
Page 4
WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES WARNING: The installation must conform with local codes Any guard or other protective device or, in the absence of local codes, with the removed for servicing the heater must be National Fuel Gas Code, ANSI Z223.1/NFPA 54, replaced prior to operating the heater.
Page 5
WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
PACKAGE CONTENTS Part Description Quantity Part Description Quantity Pole decorative cap Decorative cap 1set Base assembly Reflector 1set 1set Burner head assembly 1set Regulator Pole Cylinder chain...
ASSEMBLY INSTRUCTIONS WARNING : ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT Fig. 1 1. Fix the bottom of the pole(D) onto the base assembly(F) with six M5x10 bolts(GG) and six Ø5 washers(FF). Fig.1 Hardware Used FF ø5 washer GG M5x10 Bolt Fig.
ASSEMBLY INSTRUCTIONS Fig. 3 Insert regulator (G) into the pole (D) and the base assembly (F), then place the burner head assembly (C) onto the top of the pole (D) using four M5x10 bolts(GG) and four Ø5 washers (FF). Fig.3 Hardware Used ø5 washer GG M5x10 Bolt...
Page 11
ASSEMBLY INSTRUCTIONS Fig. 5 5. Place the reflector (B) on top of the burner head assembly (C) using three M6 x 70 double pointed bolts (EE), six ø6 washers (DD), and three M6 nuts (CC). Attach decorative reflector cap (A) to the reflector with one M6 x 38 double pointed bolt (BB) and one M6 decorative nut (AA).
Page 12
ASSEMBLY INSTRUCTIONS Fig. 6 6. Open the base door, place gas cylinder inside the base assembly (F), and fix it with cylinder chain (H). Fig. 6. Gas cylinder 7. Attach the regulator to the cylinder. Fig. 7 Turn clockwise to tighten it securely. Fig.
SAFETY CHECK Check for leaks Your patio heater has been checked at all factory connections for leakage. To check the connection at the gas hose / regulator / cylinder: 1) Make leakage solution by mixing 1 part liquid dish soap and 3 parts water. hose connection 2) Spoon or brush several drops (or use squirt bottle) of the solution onto the...
SAFETY CHECK PRECAUTIONS PRECAUTIONS WARNING : ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. THE INSTALLER IS RESPONSIBLE FOR PROPER ASSEMBLY. Annual check operation: a. Unscrew the bolts on the observation window panel, and remove the panel. observation window b.
OPERATION INSTRUCTIONS WARNING: DO NOT attempt to operate heater until you have read and understood all precautions. Failure to do so can result in serious personal injury, death or property damage. Before Turning Gas Supply ON Your heater was designed and approved for OUTDOOR USE ONLY. DO NOT use it inside a building, or any other enclosed area.
Page 16
OPERATION INSTRUCTIONS Flame Characteristic The flame pattern at the emitter screen should be visually checked whenever heater is operated. Normally the burner flame is blue, but a little yellow flame is acceptable. If flames extend beyond surface of the emitter grid, or the phenomena of flame off burner or light back, or black spot is accumulating on the emitter grid or reflector, turn the heater off immediately.
Page 17
OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY: If at any time you are unable to light burner and smell gas, wait 5 minutes to allow gas to dissipate before attempting to light heater. WARNING FOR YOUR SAFETY: Do NOT touch or move heater for at least 45 minutes after use. Allow emitter and dome to cool before touching.
LOCATING HEATER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS CEILING/OVERHANG ARE LEFT ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE. THEY WILL BE SUBJECT TO RADIANT 36-in. HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of outdoor 24-in.
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your Visually Check heater make sure you perform the following maintenance Emitter Screen activities on a regular basis: Keep exterior surfaces clean. Yellow Tip Use warm soapy water for cleaning. Never use Primarily Blue flammable of corrosive cleaning agents.
Page 20
MAINTENANCE/STORAGE Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed air may help clear away smaller particles. Carbon deposits may create a fire hazard. Clean dome and engine with warm soapy water if any carbon deposits develop.
TROUBLESHOOTING PROBLEM PROBABLE CAUSE SOLUTION Pilot will not light Gas valve may be OFF Turn the gas valve ON Tank fuel empty Refill LP gas tank Air in supply system Purge air from lines Loose connection Check all fittings Debris around pilot Clean dirty area Pilot will not stay on Loose connection...
