- Page 2 Read the instructions before use. This appliance must be installed in accordance with such regulations as are in force. MODEL: PALERMO Owner’s Manual Questions, problems, missing / replacement parts? Before returning to your retailer, call our customer service department at 1.888.779.5282, 9a.m.-6:00 p.m. PST,...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents..............1 Package Contents............2-3 Safety Information.............. Assembly Instructions........... 5-11 Operation Instructions...........12-14 Care And Maintenance............15 Troubleshooting..............16 BEFORE YOU BEGIN Please read and understand this entire manual before attempting to assemble, oper- ate or install this appliance. This manual contains important information about the assembly, operation and maintenance of this patio heater. -
Page 4: Package Contents
PACKAGE CONTENTS QUANTITY Reflector Panel Reflector Plate Head Assembly Gas Hose Regulator Upper Deck Cover Lower Deck Cover Upper Wicker Cover Middle Wicker Cover Deck Cover Bracket Upper Pole Lower Pole Cylinder Housing Wheel Kit Base... - Page 5 PACKAGE CONTENTS Bolt M6 X 12 Flange Flange Screw M4 X 10 3/16 Screw Stainless steel Stainless steel Qty. 4 Bolt Bolt Qty. 4 Qty. 2 Qty. 8 Bolt Bolt Qty. 2 M8 x 14 M8 x 16 M6 x 30 M6 x 45 Qty.
-
Page 6: Safety Information
SAFETY INSTRUCTIONS DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This heater is a combustion appliance. All paper or cardboard, a safe distance away from the combustion appliances produce carbon monoxide heater as recommended by the instructions. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. Estimated Assembly Time: 60 minutes Tools Required for Assembly (not included): Phillips screwdriver w/ medium blade. - Page 8 ASSEMBLY INSTRUCTIONS 4. Assemble the upper pole. Insert the upper pole into the lower pole. Make sure the upper pole do not up side down. The up side should have four closer holes from the end. Line up the holes and secure them with 4pcs 3/16 screws. Hardware Used 3/16 Screw 5.
- Page 9 ASSEMBLY INSTRUCTIONS 7. Assemble the upper wicker cover. Put the upper wicker cover though the pole and push it to the end. 8. Put the lower deck cover through the upper wicker cover. Make sure the wider opening is facing down. Then put the upper deck cover through the upper wicker cover.
- Page 10 ASSEMBLY INSTRUCTIONS 10. Assemble the deck cover bracket. Secure the deck cover and bracket to the pole with 4pcs M6X12 bolts. This step also secures the head assembly to the pole. Hardware Used Bolt M6 X 12 11. Secure the upper deck cover. Push the upper deck cover upwards until it is flat against the head assembly.
- Page 11 ASSEMBLY INSTRUCTIONS 13. Slide two reflector panels together. Insert one screw M6 X 10. Slide one washer over threaded end of screw M6 X 10 and screw on cap nut loosel y. Hardware Used Screw M6 X 10 Cap nuts 14.
- Page 12 ASSEMBLY INSTRUCTIONS 16. Screw the regulator to the hose. Install the gas cylinder Open the door and put the gas cylinder onto the base, then secure it with gas cylinder secure belt. And then screw the regulator to the gas cylinder contector. WARNING: Use a standard 20 lb.
- Page 13 ASSEMBLY INSTRUCTIONS A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S.
-
Page 14: Operation Instructions
OPERATION INSTRUCTIONS WARNING • Perform all leak tests outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the heater until all connections have been leak tested and do not leak. Hose / Regulator connection Regulator / Cylinder connection... - Page 15 OPERATION INSTRUCTIONS DANGER • CARBON MONOXIDE HAZARD • For outdoor use only. Never use inside house, or other unventilated or enclosed areas. This heater consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. Caution: Do not attempt to operate until you have read and understand all General Safety Information in this manual and all assembly is complete and leak checks have been performed.
- Page 16 OPERATION INSTRUCTIONS 3. Push in gas Control Knob and turn counterclockwise to “IGNITER” then to “PILOT” (Figure b) to light the pilot. If needed, keep depressing and turning Control Knob counterclockwise until the pilot lights (You should hear 2 clicking sounds). 4.
-
Page 17: Care And Maintenance
CARE AND MAINTENANCE Gas odor with extreme yellow tipping of flame. Heater does NOT reach the desired temperature. Heater glow is excessively uneven. Heater makes popping noises. Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it unsafe for use. -
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Cylinder valve is closed Open valve Clean or replace orifice or Blockage in orifice or pilot tube pilot tube Open gas line and bleed it Pilot won’t light Air in gas line (pressing control knob in) for not more than 1 - 2 minutes or until you smell gas Low gas pressure with cylinder valve... - Page 20 DISCOVER MORE AT WWW.LAVAAIRE.COM AVIATOR X2 OASIS BELLA TRIO BELLAGIO AMIT FANTOM AVIATOR WM WWW.LAVAAIRE.COM...
