- Page 1 OVERHEAD PATIO HEATER YEAR UP TO 8 HRS RUN TIME WEIGHTED BASE AUTOMATIC ELECTRONIC IGNITION TILT SWITCH AUTO-SHUTOFF OWNER'S MANUAL PROPANE POWERED WWW.LAVAHEAT.COM...
-
Page 2: For Outdoor Use Only
This appliance must be installed in accordance with such regulations as are in force. MODEL: SORRENTO Owner’s Manual Questions, problems, missing / replacement parts? Before returning to your retailer, call our customer service department at 1.888.779.5282, Monday-Friday 9 a.m.-6:00 p.m. -
Page 3: Warnings And Cautions
WARNINGS AND CAUTIONS DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. - Page 4 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: The installation must conform with local codes Any guard or other protective device or, in the absence of local codes, with the removed for servicing the heater must be ...
- Page 5 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
- Page 6 WARNINGS AND CAUTIONS PRECAUTIONS PRECAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This heater is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection.
-
Page 7: Exploded View
EXPLODED VIEW Please check the contents of the packaging as to whether anything is missing! -
Page 8: Parts List
PARTS LIST Part # Description Cover Head assembly Cover fixed plate Transom control assembly Transom mounting plate Pole Decorative cover Base assembly Wheel kit Cylinder fixing hook 1.5V D size battery 2(Not included) HARDWARE Part # Description Picture M4 x 10 bolt 4mm washer M6 x 14 bolt M6 nut... - Page 9 ASSEMBLY INSTRUCTIONS STEP 1 Attach wheel kit (9) to base assembly (8) with 2pcs M6 x 20 bolts with 6mm washers and 6mm spring washers (EE). Hardware Used M 6 x 20 bolt with 6mm washer and 6mm spring washer STEP 2 Open the door of base assembly (8).
- Page 10 ASSEMBLY INSTRUCTIONS STEP 3 Attach cover fixed plate (3) to transom control assembly (4) with 2pcs M4 x 10 bolts (AA). Hardware Used 2pcs M4 x 10 bolt STEP 4 Attach head assembly (2) to transom control assembly (4) with 4pcs M6 x 14 bolts (CC) at sides first, next 2pcs M6 x 14 bolts (CC) on the top.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 5 Connect the terminals of wires to the terminals of thermocouple, and connect the electrode pin wire to electrode pin as illustration. Caution: no terminal loose after connection. Female terminal Electrode pin wire Male terminal Thermocouple cables Electrode pin female terminals Thermocouple cables...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 7 Unscrew and take out 1pc M8 x 85 bolt and 1pc M8 cap nut on transom assembly (4) as illustration. M8 x 85 bolt M8 cap nut STEP 8 Half-loosen other 3pcs M8 cap nuts on transom assembly (4).
- Page 13 ASSEMBLY INSTRUCTIONS STEP 9 Make sure the reflector is at the same side as wheels. Insert the hose and regulator through the pole (6) and place the transom assembly (4) on the pole (6). Insert M8 x 85 bolt through the holes of transom assembly (4) and pole (6) and secure them with M8 cap nut. Finally tighten other 3pcs M8 cap nuts.
- Page 14 ASSEMBLY INSTRUCTIONS STEP 11 Insert cylinder fixing hook (10) into holes on base assembly (8). Place the gas cylinder (not included) into the base assembly (8) and fix it with cylinder fixing hook (10). Attach the regulator to the cylinder and turn clockwise to securely tighten the valve. Close and latch the door. Note: Make sure to check for leaks after attaching the cylinder.
-
Page 16: Safety Check
SAFETY CHECK WARNING: ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. battery compartment cover 4pcs M4 x 10 bolts. inlet pipe fitting and metal hose fitting. Battery compartment cover e. If no bubbles appear, the connection is safe. f. If bubbles appear, there is a leak. Shut off the LP gas cylinder valve, loosen and then re-tighten this connection. - Page 17 1) Turn LP Cylinder gas valve to fully open position and press “ ” button on the control panel. If the sparks stop and burner does not stay lit, press the button “ ” again to ignite after 10 seconds. 2) When the burner is lit, press “...
- Page 19 press the control knob to the “ ” press...
-
Page 20: Locating Header For Use
LOCATING HEADER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas. -
Page 21: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : WARNING: To enjoy years of outstanding performance from your FOR YOUR SAFETY ; heater make sure you perform the following maintenance DO NOT touch or move heater for activities on a regular basis: at least 45 minutes after use. Allow all burner elements to cool before Keep exterior surfaces clean. - Page 22 MAINTENANCE/STORAGE Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it NOTE: unsafe for use. Clean burner holes by using a heavy-duty wait until heater is cool before pipe cleaner. Compressed air may help clear away covering.
-
Page 24: Five-Year Limited Warranty
When You Receive Your Product: If Your Product is.. Please contact the manufacturer: LAVA HEAT ITALIA 888.779.5282 or LAVA HEAT ITALIA Toll free No.: 1.888.779.LAVA 1.888.779.5282 Addr.: 5999 Malburg Way, Vernon, CA, 90058... - Page 25 LAVA 2G LAVA LITE LAVA LITE KD OPUS EMBER WALL-E LAVA LITE MINI SORRENTO PUB TABLE ALTO QUATTRO DIABLO...
- Page 27 YEAR...
