R
TYPE GAS
NATURAL GAS
PROPANE GAS
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
-
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
-
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use any
phone in your building.
Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire
department.
-
INSTALLATION AND SERVICE MUST BE
PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE
GAS SUPPLIER.
This is an unvented gas fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. See Pg. 4 & 5.
This unit is not approved for installation in greenhouses,or environments involving dusty, wet,
corrosive, or explosive conditions. Such conditions will invalidate the warranty and may create
unsafe conditions.
This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
VENT FREE HEATERS
INSTALLATION AND
OPERATION INSTRUCTIONS
P/N 88950 / FEBRUARY 04
MODEL NUMBERS
BFT101
BFT201
BFT102
BFT202
BLUE FLAME
BFT301
BFT302
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this
manual for future reference.
INSTALLER MUST SHOW
HOMEOWNER PROPER
LIGHTING AND OPERATION
OF HEATER. HAVE THEM
COMPLETE AND RETURN
THE WARRANTY CARD.
