DMX-Mode

The device has nine different DMX channel modes. The Control Board allows you, as described above, to
assign the DMX channel mode.
Addressing
Press the MODE-button until the display shows d (1-512). You can now set the desired address via the UP
or DOWN buttons. Press ENTER to confirm. The Control Board allows you to assign the DMX fixture
address, which is defined as the first channel from which the FUTURELIGHT POS-12 LED TCL Powerstick
will respond to the controller.
Please, be sure that you don't have any overlapping channels in order to control each FUTURELIGHT POS-
12 LED TCL Powerstick correctly and independently from any other fixture on the DMX-chain.
If several POS-12 LED TCL Powerstick are addressed similarly, they will work synchronically.
Controlling:
After having addressed the POS-12 LED TCL Powerstick, you may now start operating it via your lighting
controller.
Note:
After switching on, the device will automatically detect whether DMX 512 data is received or not. If the data
is received, the display will show "d.001" with the actually set address. If there is no data received at the
DMX-input, the display will show "d001" with the actually set address.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the device.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last device in the link in order to
ensure proper transmission on the DMX data link.

DMX-protocol

7 channel mode

Control-channel 1 - Red
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 2 - Green
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 3 - Blue
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 4 - Color Presets
Decimal Hexad. Percentage
0 15 00 0F 0% 6%
16 255 10 FF 6% 100%
Control-channel 5 - Speed
This channel is only active if channel 6 is set to 32 - 223.
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
S/F
F Red (0=off, 255=100% red)
S/F
F Green (0=off, 255=100% green)
S/F
F Blue (0=off, 255=100% blue)
S/F
S No function
F Color Presets
S/F
F Speed with increasing speed
33/40
Feature
Feature
Feature
Feature
Feature
00069076, Version 1.1
