General Boiler Information - Alpha InTec2 26CE Installation And Servicing Instructions

HORIZONTAL FLUE OPTIONS - Lmax - 12 metres
12 m
A
L = A + B + (90° bend = 1.3 metre)
VERTICAL FLUE OPTIONS
H
Hmax = 14 m
10
Alpha InTec² 26E, 30CE and 35CE - General Boiler Information
B
Fig. 3.1
Not less than
300 mm
Fig. 3.2
B
L = A + B = 12m max.
L = A + (2 x 45° bends = 1.8 metre)
H
Hmax = 12.2 m (14 m - 1.8 m)
A
A
Not less than
300 mm
