5.3 TEST FOR GAS TIGHTNESS AND PURGE THE SUPPLY
1. With the boiler connected, pressure test the gas supply and inlet pipework connected to the boiler for tightness in
accordance with BS 6891.
2. Loosen the gas inlet pressure test point screw on the gas valve (see Fig. 5.2) and purge in accordance with BS 6891.
3. Retighten the test point screw and test for gas tightness. Close the boiler gas service cock.
5.4 CHECK THE AIR FLOW THROUGH THE HEAT EXCHANGER
The following air flow check must be carried out and the reading logged in the box provided in the table below. This figure is
then used as a reference during future servicing of the boiler to determine if the heat exchanger needs to be cleaned.
This check must be carried out with the front case fitted.
Before carrying out this check the flue must be fully installed and the condensate trap filled with water.
1. Remove the pressure test point caps at the top of the boiler and connect a digital differential pressure gauge across the
positive (F+) and negative (A-) pressure connections, see Fig. 5.3.
2. Set the boiler to stand by and press and hold the reset and stand by buttons simultaneously for 15 seconds. The
summer/winter symbol (
speed of 5500 rpm.
Note: The boiler does not fire during this operation.
3. Observe the pressure differential reading and compare it to the tables below and record the figure in the box at the
bottom of the table to be used as a reference for future servicing.
If on a future service the pressure reading has reduced by 40% or more then the heat exchanger must be cleaned.Refer to
Section 6.5.
i.e. If the measured value is less than 0.6 x the original reference value, the heat exchanger should be inspected and cleaned.
InTec² 26CE and 30CE
'F0' parameter setting
0
1
2
Recorded pressure
reading
InTec² 35CE
'F0' parameter setting
0
1
2
Recorded pressure
reading
4. If during first commissioning the readings are not within those stated in the tables above then the flue must be checked
for integrity and length. If the flue length exceeds 5 m then the 'F0' parameter should be changed to suit, see parameter
settings in Section 5.14.
Note: If the 'F0' parameter has been changed then a fast calibration is required see Section 5.13. This is indicated by
the code E72 shown on the display.
The air flow check function will operate for 15 minutes, alternatively disconnect the boiler electrical supply or press the
standby button for 8 seconds to exit the function early.
26
Alpha InTec² 26E, 30CE and 35CE - Commissioning
) and the number 55 will flash on the display indicating that the fan is running at a fixed
Pressure (mbar) Indicative flue length (m)
0 to 1.68
1.68 to 2.02
2.02 to 2.40
Pressure (mbar)
Indicative flue length (m)
0 to 1.80
1.81 to 2.30
2.31 to 2.60
From 0 to 4.5
From 4.5 to 9.0
From 9.0 to 13.0
From 0 to 4.5
From 4.5 to 9.0
From 9.0 to 13.0
