- Page 1 Installation and Maintenance Manual Commercial Hydraulic Vehicular Swing Gate Operator Model HL410-11 Doc 01-20238 Rev B...
-
Page 2: Table Of Contents
Contents Contents Parts & Components ____________________________________________ 3 Specifications & Capacities _______________________________________ 4 Safety Information ______________________________________________ 6 Installer _______________________________________________________________ 6 End User _______________________________________________________________ 7 General Wiring Information ______________________________________ 8 Wiring Information _______________________________________________________ 8 Installation ___________________________________________________ 10 Gate Stops______________________________________________________ 10 Step 1: Gate Brackets ___________________________________________________ 10 Step 2:... -
Page 3: Parts & Components
Inspect the operator for possible shipping damage or shortage of parts. Check all accessories as listed below. These do not include any accessories that were ordered separately. DESCRIPTION QUANTITY Model HL410-11 Front Mounting Bracket Rear Mounting Bracket Rod Cover Rear Mounting Pin... -
Page 4: Specifications & Capacities
Specifications & Capacities Specifications & Capacities The Model HL410-11 is a light duty commercial gate operator designed to operate a typical swing gate. Because operating requirements and gate construction vary by installation, the capacities shown should be used as a guide to determine the expected performance of the unit. - Page 5 Specifications & Capacities NOTE The hydraulic locking is not intended to be a replacement for security type locks. External lock systems should be used if: High security is required for the installation. The length of the gate exceeds 12 feet. The gate has a large surface area.
-
Page 6: Safety Information
Safety Information Safety Information Automatic gate operators provide convenience and security to their users. However, because these machines can produce high levels of force, it is important that all installers and users be aware oft he potential hazards associated with improperly installed or adjusted units. -
Page 7: End User
Safety Information DURING INSTALLATION Be aware of all moving parts and avoid close proximity to any pinch points. Disconnect power at the service panel before making any high voltage power connections. Place controls far enough from the gate so that a user can see but cannot touch the gate while operating the controls. -
Page 8: General Wiring Information
General Wiring Information General Wiring Information DRIVE UNIT, SLAVE OPTION DRIVE UNIT JUNCTION BOX, CONTROLLER SLAVE OPTION 01-20238F2 CONDUIT, CONTROL CONDUIT FOR SLAVE (4 WIRES) (as required) Suggest 10-gauge stranded wire CONDUIT, POWER (3 WIRES) Figure 2 NOTE Other wire runs may be required, depending on your application. Wiring Information The distance shown on charts is the total length of wire, measured in feet from the control panel to the power source. - Page 9 General Wiring Information POWER WIRING Maximum Distance Wire Gauge Single Unit Dual Unit 200 ft 100 ft 310 ft 155 ft 500 ft 250 ft CONTROL WIRING 200 ft 400 ft Table 4 Doc 01-20238 Rev B...
-
Page 10: Installation
It is very important that they be in-line with each other! The operator must be level. FOR MODEL HL410-11 The two brackets should be welded to the gate and the post as shown. They can be Dimension A... -
Page 11: Step 3: Optional Mounting
Installation Optional Mounting Step 3: OUTWARD SWING WARNING Do not install outward swing gates in applications where gates will swing into public area. Serious injury could result from someone being hit by the gate. Use outward swing gates only in applications where the gate will open into secure area and where the person operating the gate has control of traffic in the path of the gate. -
Page 12: Step 4: Mounting
Installation Mounting Step 4: Manually open the gate and attach the unit to the two (2) mounting brackets (see Figure 5). Manually open and close the gate a few times to ensure the mounting brackets and gate stops are positioned properly with no interference (the unit is shipped in the disconnect position to allow for this). -
Page 13: Control Panel Layout
Installation Control Panel Layout REF. DESCRIPTION PART # REF. DESCRIPTION PART # MAIN CIRCUIT BD. MG3101959 CONTROL RELAY “CLOSE” MG3101963 “OPTION” SLAVE DELAY MICRO CIRCUIT BD. MG3101960 MG3101963 RELAY “OPTION” AUTO. CLOSE MG3101961 FUSE (.38 A.) MG3101974 CIRCUIT BD. PIN CONNECTOR TRANSFORMER CAPACITOR MG3101962... -
Page 14: Step 5: Primary Voltage Wiring
Installation Primary Voltage Wiring Step 5: WARNING Make sure power is disconnected at main power supply and at power disconnect switch on operator before continuing. Connect 120 vac., single phase power, L1 and L2 to power wiring terminal strip, and ground to green ground lead wire (see Figure 7). Connect the control cord from the unit to the power wiring terminal strip. -
Page 15: Step 6: Control Wiring
Installation Control Wiring Step 6: All controls that are to be added must be connected to the control wiring terminal strip. Refer to the electrical diagram attached to the inside of the controller door for accessory wiring. Please install all safety devices necessary to make this installation as safe as possible. -
Page 16: Step 7: Hydraulic Adjustments
Installation Hydraulic Adjustments Step 7: Locate the by-pass valve. Using the hex key supplied, re-engage the by-pass valve by turning it clockwise as far as possible. Turn power on at main power supply and at power disconnect switch. The controller has a 7 second delay form power-up until a signal can be received. With gate open, activate the unit to close. -
Page 17: Step 8: Electrical Adjustments
Installation Plastic Cover Disconnect Key “Top View” By-Pass Valve Close Pressure Valve Open Pressure Valve “Bottom View” 01-20230F11 Figure 9 Electrical Adjustments Step 8: Locate the cycle timer “pot” on the control panel. This pot determines the length of time the unit will run. Adjust it so the unit will fully open and close the gate properly. -
Page 18: Step 9: Rod Cover
Installation 01-20230F12 Figure 10 Rod Cover Step 9: Install the rod cover over the piston rod, as shown. IMPORTANT NOTE: The cover must be installed to keep the piston rod clean and nick-free. Doc 01-20238 Rev B... - Page 19 Installation 01-20230F13 Figure 11 Doc 01-20238 Rev B...
-
Page 20: System Check-Out
Double check the manual operation features and pressure valves of the system. NOTE: If a problem should arise, see the Model HL410-11 Troubleshooting Guide. AND FINALLY... Install the gate caution on both the inside and outside of the gate where they can be easily seen. -
Page 21: Parts List
Parts List Parts List Mounting Pin Kit MG49142 Mounting Clip Disconnect MG5100816 End Cap Hex Key MG49139 MG5100812 Drive Unit Rod Cover MG 5100835 C-Clip Kit MG49142 Rear Mounting Bracket MG5100815 Front Mounting Bracket MG5100814 Capacitor Power Cord Kit MG3101980 MG24719 Main Circuit Board Micro Circuit Board... -
Page 22: Required Maintenance Services
Required Maintenance Services Required Maintenance Services Maintenance Service Required Every ΖΖ ΖΖ ΖΖ ΖΖ Month Months Months " Gate Inspect for wear and/or damage " Manual Operation Check & adjust if required " Close Pressure Check & adjust if required "... - Page 23 COPYRIGHT 2001 ALL RIGHTS RESERVED This document is protected by copyright and may not be copied or adapted without the prior written consent of LiftMaster. This documentation contains information proprietary to LiftMaster and such information may not be distributed without the prior written consent of LiftMaster. The software and firmware included in the LiftMaster product as they relate to this documentation are also protected by copyright and contain information proprietary to LiftMaster.
