Integrated color tv /video cassette recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL

INTEGRATED COLOR TV /VIDEO
CASSETTE RECORDER
POWER REQUIREMENTS ............
POWER CONSUMPTION ..............
WEIGHT .........................................
DIMENSIONS .................................
PICTURE TUBE .............................
TUNER SYSTEM ...........................
CHANNEL COVERAGE .................
TV SYSTEM ...................................
HORIZONTAL RESOLUTION .......
OPERATING TEMPERATURE ......
VIDEO RECORDING SYSTEM .....
VIDEO SIGNAL SYSTEM ..............
VIDEO HEAD .................................
USABLE CASSETTES ...................
SPECIFICATIONS
230V AC, 50Hz
60W
Standby 5W
Approx.25.5 kg (56.1 lbs.)
574 mm (W) x 488.5 mm (D) x
514.5 mm (H)
(22 5/8 x 19 1/4 x 20 3/8 in.)
21 in. (50.8 cm "V"), 90 degree
deflection
Frequency synthesized tuners
UHF: 21 to 69
I
240 lines
5°C to 40°C
Rotary 2 head helical scanning system
PAL colour signal, 625 lines, 50 fields
Azimuth 2 heads
VHS video cassettes
S/M Code No. 09-028-362-4N1
VX-D2150
BASIC TAPE MECHANISM : OVD-7
TAPE SPEED ...................................
RECORDING/PLAYBACK TIME .....
VIDEO INPUT ...................................
VIDEO OUTPUT ..............................
VIDEO S/N .......................................
AUDIO INPUT ..................................
AUDIO OUTPUT ..............................
AUDIO TRACK .................................
•
Design and specifications are subject to change without
notice.
K(S)
PAL
SP: 23.39 mm/sec.
LP: 11.69 mm/sec.
NTSC (playback SP only)
33.35 mm/sec.
PAL
SP: 5 hours max. with E-300 tape
LP: 10 hours max. with E-300 tape
NTSC (playback SP only)
3 hours 30 minutes max. with T-210
tape
1.0Vp-p, 75 ohm, unbalanced
1.0Vp-p, 75 ohm, unbalanced
53dB (nominal)
SCART: –3.8 dBs, 50K ohm
RCA: –3.8 dBs, 50K ohm
SCART: –3.8 dBs less than 1K ohm
1 track (mono)
