SERVICE MANUAL

DVD COLOR TELEVISION
• This Service Manual is the "Revision Publishing" and replaces "Simple
Manual" (S/M Code No. 09-008-437-0T1).
• If requiring information about DVD mechanism, see Service Manual of
AZG-D, (S/M Code No. 09-00A-350-6N4)
VX-F20DV1
S/M Code No. 09-009-437-0R1
BASIC DVD MECHANISM : AZG-D ZDADM
U
