SERVICE MANUAL

COLOR TELEVISION
• This Service Manual is the "Supplement" and replaces "Simple Manual"
VX-F21DV1 (HT), (S/M Code No. 09-00A-437-0T2).
• This Service Manual contains information about the difference between
VX-F21DV1 (HT) and VX-F20DV1 (U). If requiring other information, see
Service Manual of VX-F20DV1 (U), (S/M Code No. 09-009-437-0R1).
• If requiring information about DVD mechanism, see Service Manual of
AZG-D, (S/M Code No. 09-00A-350-6N4)
VX-F21DV1
S/M Code No. 09-00B-437-0S1
BASIC DVD MECHANISM : AZG-D ZDDDM
HT

Advertisement

Table of Contents
loading

Related Manuals for Aiwa VX-F21DV1

Summary of Contents for Aiwa VX-F21DV1

  • Page 1: Service Manual

    VX-F21DV1 (HT), (S/M Code No. 09-00A-437-0T2). • This Service Manual contains information about the difference between VX-F21DV1 (HT) and VX-F20DV1 (U). If requiring other information, see Service Manual of VX-F20DV1 (U), (S/M Code No. 09-009-437-0R1). • If requiring information about DVD mechanism, see Service Manual of AZG-D, (S/M Code No.

  • Page 2: Specifications

    SPECIFICATIONS TV SECTION GENERAL Tuner System Frequency synthesized tuner Operating Voltage 110 V AC, 50/60 Hz TV System NTSC-M Power Consumption 125 W Channel Coverage VHF: 2 to 13 Phones Jack Stereo-mini jack 5 °C – 35 °C UHF: 14 to 69 Operating Temperature CATV: 5A, A-1 to A-5, A to W, Operating Humidity...

  • Page 3: Notices Before Repairing

    NOTICES BEFORE REPAIRING To make the best use of this equipment, make sure to obey the following items when repairing (or mending). 1. Do not damage or melt the tunicate of the leading Insulation resistance: 7.0 to 9.5 MΩ (500 V/s) wire on the AC1 side, including the power supply Voltage-withstand: 1.5 KV for 1 minute cord.

  • Page 4: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-A40-735-090 DIODE,ERC06-15 87-A40-001-080 ZENER,MTZJ12C 8A-JD1-649-010 IC,M37272M8-512SP 87-017-593-090 DIODE,RGP15J 87-A21-378-010 IC,S-24C04BDP-1A 87-017-654-060 DIODE,GBU6JL6131 87-A21-133-080 IC,BMR-0101D 87-A40-450-090 DIODE,RU 1P 87-001-536-010 IC,NJM78M05FA 8Z-JBJ-605-010 IC,TA1268N 87-A40-828-080 DIODE,AK 04 87-A40-911-090 DIODE,RN 2Z 87-A21-103-040...
  • Page 5 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C214 87-018-134-080 CAPACITOR,TC-U 0.01-16 C655 87-A11-354-090 CAP,E 100-160 M SMG C229 87-018-149-080 CAP,TC-U 15P-50 CH C714 87-010-221-080 CAP, ELECT 470-10V C301 87-010-403-080 CAP, ELECT 3.3-50V C720 87-015-464-080 CAP,E 4.7-16 BP C305 87-018-126-080 CAP,TC-U 390P-50 B...
  • Page 6 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION FB803 87-003-320-080 F-BEAD,FBR07HA121NB AUDIO C.B FB804 87-003-320-080 F-BEAD,FBR07HA121NB FB805 87-003-320-080 F-BEAD,FBR07HA121NB C400 87-010-402-080 CAP, E 2.2-50 M 11L SME FB806 87-003-320-080 F-BEAD,FBR07HA121NB C401 87-010-404-080 CAP, ELECT 4.7-50V FB807 87-003-320-080 F-BEAD,FBR07HA121NB C402...
  • Page 7 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C477 87-010-316-080 C-CAP,S 33P-50 CH C907 87-010-235-080 CAP,E 470-16 SME C478 87-010-316-080 C-CAP,S 33P-50 CH C908 87-018-129-080 CAP, CER 680P-50V C479 87-010-318-080 C-CAP,S 47P-50 CH C909 87-018-129-080 CAP, CER 680P-50V C480 87-010-316-080 C-CAP,S 33P-50 CH...
  • Page 8 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C112 87-012-286-080 CAP, U 0.01-25 SYSTEM C.B C113 87-010-405-080 CAP, ELECT 10-50V C114 87-010-405-080 CAP, ELECT 10-50V C301 87-012-274-080 CHIP CAP,U 1000P-50B C115 87-012-286-080 CAP, U 0.01-25 C303 87-012-286-080 CAP, U 0.01-25 C119...
  • Page 9 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION FB211 87-003-223-080 FERRITE BEAD BL02RN2 FL701 88-NF9-630-010 FL,10-BT-207GK ICF211 87-A91-337-080 PROTECTOR,IC ICP-N75 L701 87-003-147-080 COIL, 22UH ICF212 87-001-132-080 ICP-N38 S701 87-A90-164-080 SW,TACT SKQNAB(N) ICF213 87-A91-337-080 PROTECTOR,IC ICP-N75 S702 87-A90-164-080 SW,TACT SKQNAB(N) ICF214...

  • Page 10: Transistor Illustration

    TRANSISTOR ILLUSTRATION B C E 2SA933AS(R) DTA114EKA DTC114EKA – 10 –...
  • Page 11 WIRING – 1 (MAIN) – 11 –...

  • Page 12: Schematic Diagram - 1 (Main)

    SCHEMATIC DIAGRAM – 1 (MAIN) 1.25A 60V :CHECK LAND – 12 –...
  • Page 13 WIRING – 2 (AUDIO) – 13 –...

  • Page 14: Schematic Diagram - 2 (Audio)

    SCHEMATIC DIAGRAM – 2 (AUDIO) – 14 –...
  • Page 15 WIRING – 3 (NK) – 15 –...

  • Page 16: Schematic Diagram - 3 (Nk)

    SCHEMATIC DIAGRAM – 3 (NK) – 16 –...

  • Page 17: Wiring - 4 (S - Jack)

    WIRING – 4 (S – JACK) – 17 –...

  • Page 18: Schematic Diagram - 4 (S - Jack)

    SCHEMATIC DIAGRAM – 4 (S – JACK) – 18 –...

  • Page 19: Wiring - 5 (Joint)

    WIRING – 5 (JOINT) – 19 –...

  • Page 20: Schematic Diagram - 5 (Joint)

    SCHEMATIC DIAGRAM – 5 (JOINT) – 20 –...
  • Page 21 WIRING – 6 (SYSTEM) – 21 –...

  • Page 22: Schematic Diagram - 6 (System)

    SCHEMATIC DIAGRAM – 6 (SYSTEM) – 22 –...

  • Page 23: Wiring - 7 (Fr - Jack)

    WIRING – 7 (FR – JACK) – 23 –...

  • Page 24: Schematic Diagram - 7 (Fr - Jack)

    SCHEMATIC DIAGRAM – 7 (FR – JACK) – 24 –...

  • Page 25: Wiring - 8 (Fr - Key)

    WIRING – 8 (FR – KEY) – 25 –...

  • Page 26: Schematic Diagram - 8 (Fr - Key)

    SCHEMATIC DIAGRAM – 8 (FR – KEY) – 26 –...

  • Page 27: Wiring - 9 (Opt)

    WIRING – 9 (OPT) – 27 –...

  • Page 28: Schematic Diagram - 9 (Opt)

    SCHEMATIC DIAGRAM – 9 (OPT) – 28 –...
  • Page 29 WIRING – 10 (PS – 2) – 29 –...

  • Page 30: Schematic Diagram - 10 (Ps - 2)

    SCHEMATIC DIAGRAM – 10 (PS – 2) – 30 –...
  • Page 31 WIRING – 11 (PS – SW) – 31 –...

  • Page 32: Schematic Diagram - 11 (Ps - Sw)

    SCHEMATIC DIAGRAM – 11 (PS – SW) AC 110V 50/60HZ 4 . 7 M 1 / 2 W – 32 –...
  • Page 33 WIRING – 12 (FR – FL) – 33 –...

  • Page 34: Schematic Diagram - 12 (Fr - Fl)

    SCHEMATIC DIAGRAM – 12 (FR – FL) – 34 –...

  • Page 35: Electrical Adjustment

    ELECTRICAL ADJUSTMENT Method of Using the Jig Remote Controller Most of the video circuit and the deflection circuit of this set can be adjusted by using the jig remote controller. Jig remote controller: RC-AVC01 The jig remote controller RC-AVC01 has the two operating modes. One is the NORMAL mode and the other is the TEST mode. Either the NORMAL mode or the TEST mode can be selected by short-circuiting or opening the shorting land of the printed foil pattern.
  • Page 36 Aging Mode How to enter the aging mode and the contents that are displayed in the aging mode To enter the aging mode, press the TEST key. When this set enters the aging mode, the Auto Power Off function that turns off the main power when the input signal is disconnected, is disabled.
  • Page 37 How to check and set the distinction switch When the EEP ROM is going to be replaced, be sure to check and change the distinction switch before starting the EEP ROM replacement as follows. Press the TEST key to enter the aging mode. Press the DISPLAY key to let the DISTINCTION switch appear on screen.
  • Page 38 This section described the 16 types of distinction switch and the contents that are set by these distinction switches. Contents OSD1 OSD2 RFAGC MUTE QSUR WEAK Setup value Contents VMUTE VCHIP CCAP SBASS SWOOFER CHILD Setup value SW_0 "CLOCK" [Selection of the OSD reference clock] SW_5 "MTS"...
  • Page 39 SW_9 "VMUTE" [Use or not use of the video mute during SW_E "SWOOFER" [Selection of SUBWOOFER] channel selection] SWOOFER=0 SUBWOOFER is not used VMUTE=0 Used SWOOFER=1 SUBWOOFER is used VMUTE=1 Not used When SUBWOOFER = 0 is selected, the remote controller is disabled.
  • Page 40 How to enter, adjust and terminate the adjustment mode Press the TEST key while the machine is in the aging mode. The adjustment menu display appears on the screen showing the machine is in the adjustment mode. The adjustment pages can be selected by pressing the CHANNEL UP/DOWN key. Press the numeric ten key to select the desired adjustment item.
  • Page 41 Setting the IIC bus data Initial value When the EEP ROM is replaced, enter the following initial value before starting adjustment. When this set is brought in for normal repair other than the EEP ROM replacement, confirm status of the corresponding item only before starting adjustment.
  • Page 42 Pin and Barrel Adjustment Input signal: Cross-hatch signal Measuring equipment: Pattern generator Adjustment point: Pin-SFR602, Barrel-SFR603 Adjustment method: Adjust the pin and barrel distortion of picture so that the areas A and B in the following illustration become minimum at both the rightmost end and leftmost end of the cross-hatch display, using SFR602 and SFR603. Vertical Picture Position Adjustment Input signal: Monoscope signal...
  • Page 43 Vertical Linearity Adjustment Input signal: Monoscope signal Measuring equipment: SHIBASOKU TP20A1 Adjustment point: SFR501 Adjustment method: Adjust the vertical linearity so that the number of vertical position scales at the topmost end and at the bottommost end are of equal amount using SFR501. The vertical linearity adjustment and the vertical picture position adjustment must be performed together alternately.
  • Page 44 PIF VCO Adjustment Note: Be sure to perform the PIF VCO adjustment whenever the VCO coil (L205) is replaced. Measuring equipment: Spectrum analyzer, search coil The method how to manufacture the search coil Setting the spectrum analyzer Center frequency: 45.75 MHz Reference: 60 dBµV/ Should be determined by the amplitude of waveform Span:...

  • Page 45: Screen Voltage Adjustment

    SIF Adjustment Note: Be sure to perform this adjustment whenever the SIF coil (L201) is replaced. Simplified adjustment procedure Input signal: Normal off-the-air broadcast Measuring equipment: Oscilloscope Adjustment point: L201 Test point: IC301 pin-54 Adjustment method: Adjust L201 so that the center value of the audio signal waveform at IC301 pin-54 becomes 4.5±0.2 Vdc. RF AGC Adjustment Input signal: RF input...

  • Page 46: Sub Brightness Adjustment

    White Balance Adjustment Note: Allow 20 minutes or longer of warm-up time before starting the white balance adjustment. Repeat the entire steps of the white balance adjustment several times until all three channels of red, green and blue are balanced each other. Input signal: White raster Measuring equipment: Pattern generator...
  • Page 47 SUB COLOR Adjustment Input signal: Color bars (full field, white/100%) Measuring equipment: Oscilloscope, pattern generator (Leader 408NPS) Test point: CN901 pin-3 Adjustment point: Adjustment menu PAGE 3-4 Adjustment method: Connect an oscilloscope to CN901. Adjust the SUB COLOR so that the white (75%) line and the blue line are aligned to a single straight line using the jig remote controller VOLUME UP/DOWN keys.
  • Page 48 SUB TINT Adjustment Input signal: Color bars (full field, white/75%) Measuring equipment: Oscilloscope, pattern generator (Leader 408NPS) Test point: CN901 pin-3 Adjustment point: Adjustment menu PAGE 3-3 Adjustment method: Connect an oscilloscope to CN901. Adjust the SUB TINT so that the magenta line and the blue line are aligned to a single straight line using the jig remote controller VOLUME UP/DOWN keys.

  • Page 49: Stereo Separation Adjustment

    STEREO SEPARATION Adjustment Input signal: Stereo test signal from audio generators-1 and -2 Input level: 60 dBµ, P/S 7 dB Channel: 11 CH (fp = 199.25 MHz) Video: Color bars (1 Vp-p, modulation degree 87.5%) Audio: 400 Hz±25 kHz deviation Setting the audio generator-1 L-CH only 300 Hz, ±7.5 kHz deviation...

  • Page 50: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 PLATE, REAR 2 SHLD-PLATE, TOP2 PLATE, BT UL PLATE, E-FJ PLATE, REAR 1 SHLD, TOP BINDER, WIRE BINDER,WIRE BINDER, WIRE AZG-D PLATE, WINDOW SHLD-PLATE, LOW – 50 –...

  • Page 51: Mechanical Parts List

    7 8A-JD1-031-010 KEY,SCREEN MS682 42 8Z-HU1-033-010 BADGE,DVD 8 8A-JDB-001-010 CABI,FR MS104 43 8Z-JE7-607-110 CONN ASSY,1P CRT-GNP 9 8Z-JE7-008-010 BADGE,AIWA ST 52.5 44 86-LBN-625-010 COIL,DGC21 6LB-22 10 8A-JD1-034-010 KEY,STOP MS682 45 87-A91-981-010 F-BEAD, 18.8/1.1/7 HF70SH 11 8A-JD1-032-010 KEY,MAIN MS682 46 8A-JD1-226-010...
