  • Page 1 REALITY 8200 TCR+ R9001430 OWNER'S MANUAL...
  • Page 3 BARCO PROJECTION SYSTEMS REALITY 8200 TCR+ R9001430 OWNER'S MANUAL Date : Art. No. : 010998 R5975928...
  • Page 4 The use of shielded cables is required to comply within the limits of Part15 of FCC rules and EN55022. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...

  • Page 5: Table Of Contents

    Table of Contents TABLE OF CONTENTS ................................... i-1 UNPACKING AND DIMENSIONS ................................1-1 Unpacking ..................................... 1-1 Projector dimensions ..................................1-1 Battery installation in the RCU..............................1-2 INSTALLATION GUIDELINES ................................2-1 Environment ....................................2-1 What about ambient light ? ................................2-1 Which screen type? ..................................

  • Page 6: Table Of Contents

    Change Baudrate PC .................................. 10-4 Reset Lamp Runtime .................................. 10-4 Lamp Run Time History ................................10-5 Lamp Control ....................................10-5 BARCO logo ....................................10-5 Panel Adjustments ..................................10-6 Preset Input Balance ................................... 10-6 I2C diagnosis....................................10-6 Appendix A : Standard Source Set Up Files ............................A-1 Appendix B : Lenses ....................................

  • Page 7: Unpacking And Dimensions

    Unpacking and Dimensions UNPACKING AND DIMENSIONS Unpacking Pull To open Warning : To prevent overheating of the projector as table mounted, always remove the wooden board and turn in the 3 supporting feet to allow air circulation via the built-in dust filter at the bottom. 3 7 9 Projector Dimensions 1023,4...

  • Page 8: Battery Installation In The Rcu

    Unpacking and Dimensions Battery Installation in the RCU. Note : projector address has to be programmed on the RCU before using the RCU (see chapter 'Controlling'). 3 1 0 a .D R W...

  • Page 9: Installation Guidelines

    Installation Guidelines INSTALLATION GUIDELINES Installation guidelines * Environment * What about ambient light ? * Which screen type? T p…rr Ðvq ‡u For more information about screens, contact your local screen supplier. * What image size? How big should the image be?

  • Page 10: Where To Install The Projector

    Installation Guidelines * Where to install the projector? Inputs and computer video format input compatibility : Definitions of the Abbreviation on drawings Lens type selection. Ceiling SIDE VIEW Optical axis projection lens Screen CD = B - A Projector Projector Screen CD = B - A Optical axis projection lens...

  • Page 11: Location And Functions Of Control

    Location and Functions of Control LOCATION AND FUNCTIONS OF CONTROL Front Panel Terminology ÃÃ!"ÃW T h i s d e v i c e co m p l i e s w i t h P a rt 1 5 o f t h e F C C r u l e s . O p e r a t i o n i s s u b j e c t t o fo ll o w i n g t w o c o n d it i o n s : ÃÃ(ÃÃÃÃÃ#Ã6 ( 1 ) T h is d e v i c e m a y n o t c a u s e h a r m f u l i n t e r f e r e n ce...
  • Page 12 Location and Functions of Control b. Remote control (;,7 (17(5 67%< 3$86( 7(;7 )5((= +(/3 3+$6( 6+$531(66 EXIT STANDBY 7,17 ENTER &2/25 TEXT PAUSE %5,*+71(66 SHARPN TINT BRIGHTN &2175$67 &2175$67 PHASE COLOR 3 2 a Terminology Back Light Key FREEZ ENTER ADJ.

  • Page 13: Installation Set Up

    Installation Set Up INSTALLATION SET UP 5 HDU& HLOLQJ ) URQW& HLOLQJ 5 HDU7 DE OH )URQW7DEOH ADJUST ENTER ENTER ADJUSTMENT MODE ENTER INSTALLATION EXIT or ADJUST ENTER INSTALLATION ENTER EXIT CONFIGURATION ADJUST CONFIGURATION ENTER FRONT/TABLE ENTER EXIT ADJUST...
  • Page 14 Installation Set Up...

  • Page 15: Connections

    Connections CONNECTIONS AC Power (mains) cord connection 90 to 250 VAC T h i s d e vic e co m p lie s w it h P a r t 1 5 o f th e F C C r u le s . O p e ra t io n is s u b je c t to fo ll o w in g t w o c o n d itio n s : ( 1 ) T h is d e vi ce m a y n o t c a u se h a r m f u l in te r fe r e n c e Fuses...

  • Page 16: Switching To Stand-By

    Connections Lamp Run Time Lamp run time Lamp run time is 1000 hours. Operating the lamp longer than 1000 hours may damage 980 h the projector. Please replace the lamp. WARNING Warning : Using a lamp for more than 1000 hours is dangerous as the lamp could explode.

  • Page 17: Fixed Rgb Analog Input (Slot 1)

    Connections Fixed RGB analog input (slot 1) P R OJ EC T OR M OD E : DIAGNOSTICS GRE E N - O P ERA TIO N CODE IR-RECEIVER IR-ACKNOWLEDGED C O M MU NICAT IO N PO RT RE D - S TAN DBY RS232 OUT RS 232 IN (800-PER IPH ER ALS)

  • Page 18: Fixed 5-Input Slot (Slot 2)

    Connections Fixed 5-Input Slot (slot 2) P RO JEC TO R M O D E : G REE N - O PE RA TIO N DIAGNOSTICS CODE C OM M UN ICA TION PORT IR-ACKNOWLEDGED RE D - S TA ND BY RS 232 IN RS232 OUT (800-PERIPH ERALS )

  • Page 19: Video/S-Video Input Module

    Connections Video/S-video Input Module S -VID E O V ID E O A U D IO W D9 @ P T W D9 @ P ÃDI Q V U PR OJE CT OR M ODE : DIAGNOSTICS G REEN - OPERAT ION CODE IR-RECEIVER C OM MU N IC ATION POR T...

  • Page 20: Rgb Analog Input Module

    Connections RGB Analog Input Module. P R OJ EC TO R M O D E : DIAGNOSTICS GRE E N - O PE RA TIO N CODE IR-RECEIVER IR-ACKNOWLEDGED C O MM UN IC ATIO N PO RT RE D - S TANDB Y RS232 OUT R S 232 IN (800-PERIPHE RALS)

  • Page 21: Component Input Module

    Connections Installation ENTER ADJUSTMENT MODE INSTALLATION Input Slots ENTER INSTALLATION Input Slots INPUT SLOTS ENTER INPUT SLOTS RGB-SS [CV] RGB-SS [CS or HS&VS] RGB-SOG Component Input Module. R -Y 8 P H QP I @I UÃWD9@ P ÃDI Q V U PR OJEC T O R M O DE : G REEN - O P ER ATIO N DIAGNOSTICS...

  • Page 22: Rgb3S/Rg3Sb Input Module

    Connections Straps on module level : Ay‚h‡vtÂ…Á ‚Ãsy‚h‡v tÃvƒˆ ‡ Non-Floating Floating T’pÆryrp‡v‚ T r ƒ h …h ‡r Æ ’  p T ’  p   Ã` U …vyr‰ryÃT’p I ‚ … € h yÃT ’  p RGB3S / RG3sB Input Module.

  • Page 23: Serial Digital Input

    Connections Straps on Module Level : E ' ÃT ’  p Æ r yr p ‡v‚  T rƒ h …h‡ rÆ ’ p T ’ p   Ãt …r r Non-Floating Floating Ay‚h‡vtÂ…Á‚Ãsy‚h‡vtÃvƒˆ‡ Serial Digital Input (slot 5) PR O JEC T O R M O D E : GR EEN - OPER ATION DIAGNOSTICS...

  • Page 24: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs 232 Input Of The Projector

    Connections Connecting a Computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS 232 input of the projector. P RO JE CTO R M O DE : DIAGNOSTICS G REEN - O PERAT IO N CODE IR-RECEIVER C O M M UN ICAT IO N PO RT R ED - STANDBY IR-ACKNOWLEDGED RS 232 IN...

  • Page 25: Controlling

    Controlling CONTROLLING IR sensor IR sensor How to Use the RCU? ÃÃ ! "Ã W T hi s d ev i c e c om pl i es w i t h P ar t 1 5 of t he F C C r ul es . O per a t i on i s s ub j e c t t o f ol l o w i ng t w o c on di t i on s : Ã...

  • Page 26: How To Display A Projector Address

    Controlling How to Display a Projector Address? ADDRESS PROJECTOR ADDRESS How to Program an Address into the RCU? ADDRESS Picture Controls with Direct Access. Brightness Control BRIGHTNESS 'brightness' Contrast Control Color Saturation Tint Control Sharpness Control. Phase Control...

  • Page 27: Start Up Of The Adjustment Mode

    Start up of the Adjustment Mode START UP OF THE ADJUSTMENT MODE Adjustment Mode ADJUST ENTER ADJUSTMENT MODE ENTER EXIT ADJUST Installation Random Access Service PASSWORD ENTER PASSWORD Error EXIT 0 0 0 0...
  • Page 28 Start up of the Adjustment Mode...

  • Page 29: Random Access Adjustment Mode

    Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Starting up the Random Access Adjustment Mode ADJUSTMENT MODE ENTER File Service...

  • Page 30: Load File

    Random Access Adjustment Mode File Service ENTER RANDOM ACCESS ADJUSTMENT MODE ENTER EXIT ADJUST FILE SERVICE Load File FILE SERVICE ENTER LOAD FILE ENTER ENTER CONFIRM LOAD FILE ENTER ENTER EXIT Edit File FILE SERVICE EDIT ENTER ENTER EDIT FILE...
  • Page 31 Random Access Adjustment Mode EDIT FILE xga.s30 ENTER ENTER ENTER How to find the correct values for the displayed item? "Horizontal Total Pixels" "Active Pixels" "Horizontal Start "Horizontal Period" "Vertical Total Lines" "Active Lines" Vertical start Interlaced [On] or [Off] Read AMDS...
  • Page 32 Random Access Adjustment Mode Options Source Number EDIT FILE OPTIONS Clamp Position ENTER Clamp Delay Exam ple for clam p position [trailing] Clamp Width Field Polarity Sync pulse ENTER Clamp pulse Field Select Clamp width Clamp delay ENTER Vertical Refresh [sync/async] Vertical Sync Polarity ENTER EXIT...

  • Page 33: Rename

    Random Access Adjustment Mode Rename ENTER FILE SERVICE ENTER RENAME FILE RENAME FILE ENTER EXIT Copy FILE SERVICE ENTER ENTER COPY FILE COPY FILE ENTER EXIT...

  • Page 34: Delete

    Random Access Adjustment Mode Delete FILE SERVICE ENTER ENTER DELETE FILE ENTER CONFIRM EXIT DELETE FILE File Options ENTER FILE SERVICE FILE OPTIONS Picture Tuning ENTER RANDOM ACCESS ADJUSTMENT MODE PICTURE TUNING...

  • Page 35: Cti On/Off

    Random Access Adjustment Mode CTI ON/OFF PICTURE TUNING CTI [ON] ENTER Still Video PICTURE TUNING STILL VIDEO [ON] The default is Still Video ON for all interlaced video sources. Color Temperature PICTURE TUNING ENTER COLOR TEMPARATURE COLOR TEMPERATURE CUSTOM COLOR BALANCE GAIN RED...

  • Page 36: Gamma

    Random Access Adjustment Mode Gamma PICTURE TUNING GAMMA ENTER GAMMA = 2.2 Decoding EBU/IRE PICTURE TUNING DECODING [EBU] ENTER Dynamic Color Depth PICTURE TUNING ENTER DYNAMIC COLOR DEPTH DYNAMIC COLOR DEPTH MED MAX Noise Reduction PICTURE TUNING ENTER NOISE REDUCTION NOISE REDUCTION AUTO...

  • Page 37: Edge Enhancement

    Random Access Adjustment Mode Edge Enhancement PICTURE TUNING ENTER EDGE ENHANCEMENT EDGE ENHANCEMENT Geometry ENTER RANDOM ACCESS ADJUSTMENT MODE GEOMETRY ENTER ENTER Shift ENTER GEOMETRY...

  • Page 38: Size

    Random Access Adjustment Mode Size GEOMETRY ENTER Fixed sides Horizontal size adjustment Vertical size adjustment Example for table mount configuration Side Keystone GEOMETRY...

  • Page 39: Blanking

    Random Access Adjustment Mode Blanking GEOMETRY BLANKING Top blanking Right blanking Left blanking Bottom blanking Adjustment of the blanking on the top of the image BLANKING Adjustment of the blanking on the bottom of the image Correct by pushing the control disc up or down Adjustment of the blanking on the left side Adjustment of the blanking on the right side Correct by pushing the control disc to the right or to the left...
  • Page 40 Random Access Adjustment Mode...

  • Page 41: Installation Mode

    Installation Mode INSTALLATION MODE Starting up the Installation Mode ADJUSTMENT MODE Select a path from below : ENTER RANDOM ACCESS ENTER INSTALLATION EXIT SERVICE Source 01 INSTALLATION INPUT SLOTS 800 PERIPHERAL CONVERGENCE CONFIGURATION OSD COLOR NO SIGNAL [BLACK] INTERNAL PATTERNS Select with then <ENTER>...

  • Page 42: 800 Peripheral

    Installation Mode 800 Peripheral INSTALLATION INPUT SLOTS 800 PERIPHERAL CONVERGENCE CONFIGURATION OSD COLOR NO SIGNAL [BLACK] "800 Peripheral" INTERNAL PATTERNS ENTER Select with then <ENTER> <EXIT> to return. 800 PERIPHERAL Select with ENTER then <ENTER> <EXIT> to return. OUTPUT MODULE [STANDARD] Convergence "Convergence"...
  • Page 43 Installation Mode Green to Midposition CONVERGENCE GREEN TO MIDPOSITION GREEN BLUE ON GREEN RED ON GREEN HATCH ABOUT MOCA GREEN TO MIDPOSITION Are you sure to set the green motorized convergence adjustment to midposition ? This adjustment cannot be undone afterwards ! <ENTER>...
  • Page 44 Installation Mode Red on Green convergence CONVERGENCE GREEN TO MIDPOSITION GREEN BLUE ON GREEN RED ON GREEN HATCH ABOUT MOCA Select with then <ENTER> <EXIT> to return. Hatch CONVERGENCE GREEN TO MIDPOSITION ENTER GREEN BLUE ON GREEN EXIT RED ON GREEN HATCH ADJUST ABOUT MOCA...

  • Page 45: Configuration

    Installation Mode Configuration ENTER INSTALLATION INPUT SLOTS For more information, see Projector configuration in chapter 4 : 800 PERIPHERALS CONVERGENCE 'Installation Set Up'. CONFIGURATION OSD COLOR NO SIGNAL [BLACK] INTERNAL PATTERNS Select with then <ENTER> <EXIT> to return. OSD color (On-Screen Display) INSTALLATION ENTER INPUT SLOTS...
  • Page 46 Installation Mode 5975928 BARCOREALITY 8200TCR+ 010998...

  • Page 47: Service Mode

    SERVICE MODE Starting up the Service Mode ADJUSTMENT MODE ENTER SERVICE ENTER ENTER EXIT SERVICE SERVICE BARCO CHANGE PASSWORD CHANGE LANGUAGE REALITY 8200TCR+ SERVICE CHANGE PROJ. ADDRESS CHANGE BAUDRATE PC RESET LAMP RUN TIME LAMP RUNTIME HISTORY LAMP DRIVE MODE...

  • Page 48: Identification

    Service Mode SERVICE PANEL ADJUSTMENT PRESET INPUT BALANCE BARCO LOGO SERVICE I2C DIAGNOSIS Identification Identification ENTER Identifica- SERVICE tion type software version Proj. Address Installation Baud rate Projector Run Time Projector Serial number...

  • Page 49: Change Password

    Service Mode Change Password How to enable or disable the password function ? T h is d e v ic e c o m p l ie s w it h P a r t 1 5 o f th e F C C r u le s . O p e r a t io n is s u b je c t t o fo llo w i n g t w o c o n d i ti o n s : ( 1 ) T h is d e v ic e m a y n o t c a u s e h a r m fu l i n te rf e r e n c e...

  • Page 50: Change Language

    Service Mode SERVICE Change Projector Address Change Language SERVICE CHANGE LANGUAGE CHANGE PROJ. ADDRESS Change Baudrate PC SERVICE ENTER ENTER Reset Lamp Runtime SERVICE ENTER WARNING EXIT ----------------------------------------------------- RISK OF ELECTRICAL SHOCK _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...

  • Page 51: Lamp Run Time History

    Service Mode Lamp Run Time History SERVICE ENTER EXIT LAMP RUNTIME HISTORY Lamp Drive Mode SERVICE LAMP DRIVE MODE LAMP DRIVE MODE BARCO logo SERVICE BARCO LOGO ENTER BARCO LOGO...

  • Page 52: Panel Adjustments

    Service Mode Panel Adjustments Changing these settings may seriously affect the performance SERVICE of the projector. PANEL ADJUSTMENTS ENTER WARNING Preset Input Balance Changing these settings may seriously affect the performance SERVICE of the projector. PRESET INPUT BALANCE ENTER WARNING I2C diagnosis.

  • Page 53: Appendix A : Standard Source Set Up Files

    Appendix A : Standard Source Set Up Files STANDARD SOURCE SET UP FILES Name : FVERT Hz : FHOR kHz : FPIX MHz : PTOT : PACT : LTOT : LACT :...
  • Page 54 Appendix A : Standard Source Set Up Files...

  • Page 55: Appendix B : Lenses

    Lenses LENSES Focusing the lens Lens Cleaning Procedure Cleaning procedure for HD(1.5-3:1) lens. FIRST lightly DO NOT DO NOT DO NOT use an aerosol. moisten the cloth or tissue Cleaning procedure for the other HD lens...
  • Page 56 Lenses Lenses Lens formulas to calculate the projector distance.
  • Page 57 Source Numbers 80 - 89 and 90 - 99 SOURCE NUMBERS 80 - 89 AND 90 - 99 Projector without any 800 peripheral connected. Projector with a 800 peripheral connected. Source numbers 90 - 99.
  • Page 58 Source Numbers 80 - 89 and 90 - 99 Source numbers 81 - 85...
  • Page 59 5&8 5&8 DI Q V UÃTP V S 8 @T DI Q V UÃTP V S 8@T 352-(&725 352-(&725 DIQVUÃTP V S8@T DIQVUÃTP V S8@T 5&9'6 5&9'6...
