Conceptronic C8CHIPSKIT User Manual page 47

SYSTEM
Operating System
Pentaplex
Number of Channels
INPUTS / OUTPUTS
Camera Input
Video Output (VGA)
Video Output (HDMI)
Audio Out
USB Port
DISPLAY / OPERATIONS
Live Display
Live Display Speed
OSD
System Navigation
Split Screen
Motion Area Setting
Motion Sensitivity
Digital Zoom
Privacy Mask
User Authority
Time Synchronization
Firmware Upgrade
RECORDING
Compression Type
Compression Rate
Recording Resolution
Recording Speed
Recording Quality Control
Recording Schedule
Pre Recording
Post Recording
Reliability
Linux (embedded)
Simultaneous View, Record, Playback,
Backup & Remote Monitoring
4 + 4 Channels
4Ch(PoE) + 4Ch(LAN)
Up to 1920x1080
Up to 1920x1080
RCA x2 (Left & Right)
3
Up to 8
Up to 120 fps
Yes
USB Mouse, IR Remote Controller,
Touch Monitor Control
1, 4, 9
Yes (50x37)
100 levels
Yes, 1x ~ 4x
Yes
Yes
NTP Supported
Via USB flash drive
H.264
300:1
Up to 1600x1200
Up to 120 fps
5 levels
Manual / Schedule / Event
Up to 15 Secs
Up to 10 Minutes
Auto-recovery after power resuming
PLAYBACK
Channels
Playback Speed
Search
Log Search
STORAGE & ARCHIVE
Storage
Maximum Capacity
Backup Media
Backup File Format
External HDD mode
CONNECTIVITY
Easy Connect
Supported Operating
Systems
Browsers
Email notification
Smart Phone Compatibility
DDNS
System Configuration
Network Protocol
Network Interface
GENERAL
Power Consumption
Supply Voltage
Unit Dimensions (W x D x
H)
Unit Weight
Operating temperature
Humidity
Note: NVR Viewer app for iPhone and Android phones
is available on the App store and Google Play.
For the app user manual, please visit
http://www.conceptronic.net/download.php
47
Max. 8Ch
Single Frame, Forward / Rewind
(x5, x15, x60)
By time or event
Yes (max. 8192 events)
Internal HDD x1, External USB HDD
x1
4TB
USB Flash Drive & External HDD
MOV
Capacity extending / Backup recording
UPnP Supported
Windows™ 8/7/Vista/XP
Internet Explorer & Safari & Chrome
& Firefox
Yes
iOS, Android
Yes
Full setup configuration over network
TCP/IP, PPPoE, DHCP,
DNS, DDNS, NTP, SMTP, UPnP
10/100 Mbps RJ45 x 1
Independent 10/100 M RJ45 (PoE) x 4
DC12V, 4A, 48W
100~240VAC
295 × 161.1 × 32.2mm
0.85Kg (without HDD)
5 ~ 40°C
10 ~ 75%
