View in video image as1600*1200.
View in video image as 640*400.
Switch automatically to HD or SD resolution when viewing in shingle channel or multi channel
mode respectively.
Press this button to capture current live image.
Press this button to record image to PC.
Press this button to digital zoom in single channel.
Press this button to enlarge image to full screen, press keyboard "Esc" to return.
Press this button to expand image to fit image window size.
Press this button to hide the OSD text overlap.
Press this button for camera sequence
This show user online status, maximum allow 8 users online.
Playback
Click this button for playback mode.
Playback mode by Date/Time
Playback model by event
Click this button for remote backup
NOTE
Only operator and admin are able to enter playback mode
39
