I.
Specifications
Operating Voltage
Current Draw
Keypad 12 buttons (0~9,＊,＃)
LED Status Indication 3 LED indicators display (Red/Yellow/Green)
Relay Strike Time 01~99 seconds or Toggle Mode (00)
Relay Electric Current 3A/120VAC , 3A/24VDC
Memory Volume
EPROM
Ambient Humidity 0%~95% (Non-condensing)
Operating Temperature -20°C~+70°C
II. Status Indication
LED
Beep
III. Operation Instruction
Jumper Setting
4 or 5 digit setting
5 digit
4 digit
1. Default value: "1234" for 4 digits, "12345" for 5 digits
It's suggested to clear all stored codes prior to new setting.
2. Master Code reset to default value"12345":
a. Insert the jumper into 1-2 (5 beeps)
b. Master Code reset to default value
Copyright All Rights Reserved.
P-MU-DG15 Ver. I Publish:2010.08.12
DG-15 & DG-15LD
Digital Keypad
Operation Manual
DG-15
12 VDC
DG-15WP
DG-15LD 12~24 VDC
DG-15
Pull in: 50 mA Holding: 10mA /12VDC
DG-15WP
Pull in: 70 mA Holding: 40mA /12VDC
DG-15LD
Pull in: 100 mA Holding: 60mA /24VDC
1 contact for Request-To-Exit button
Input
1 contact for door reed switch
Output 2 relays (Dry contacts: N.O./N.C./Com.)
20+1 PINs (＊01~＊021)
Relay 1 is controlled by user ＊01~＊20
Relay 2 is controlled by user ＊21
Sign: Relay1(＊30); Relay2(＊31)
Non-volatile memory allows remaining all setting codes in the event
of total power failure.
Green On
Power on, Stand by
Red On
Relay 1 active
Yellow On
Relay 2 active
1 Beep
Valid key press
2 Beeps
Enter, exit setting mode
3 Beeps
Incorrect operation
5 Beeps
Master Code back to 12345 (Cleared settings)
Master Code reset to
default value"12345"
4or5
RESET
Reset
Normal
Page: 1/ 3
Advertisement
Table of Contents
Related Manuals for Gianni DG-15
Summary of Contents for Gianni DG-15
- Page 1 DG-15 & DG-15LD Digital Keypad Operation Manual Specifications DG-15 12 VDC DG-15WP Operating Voltage DG-15LD 12~24 VDC DG-15 Pull in: 50 mA Holding: 10mA /12VDC DG-15WP Current Draw Pull in: 70 mA Holding: 40mA /12VDC DG-15LD Pull in: 100 mA Holding: 60mA /24VDC Keypad 12 buttons (0~9,＊,＃)
- Page 2 c. Insert the jumper into 2-3 3. Clear all PINs: a. Reset Master Code to default value (5 beeps, clearing all PINs) b. Insert the jumper into 2-3 Enter Setting Mode Enter the master code twice (Default value: “1234” or “12345) to enter setting mode (2 beeps) Note: 1.
- Page 3 IV. Wiring Diagram For DC use only For AC/DC The door strike or relay must have a varistor or a diode across the door strike terminals to suppress the back EMF of the strike – failure to do so will damage the relay contacts and electronic components, or even burns the controller.
