XVision XAM300 User Manual

Cctv b/w entry phone/ monitor
Hide thumbs Also See for XAM300:
Table of Contents

Advertisement

Quick Links

Download this manual
XAM300
Model:
B/W Entry Phone/
Monitor

Before you begin

•
Please unpack the box carefully and identify that all the parts are present.
•
Do not cut the cables, this will void the warranty.
•
Make sure you use only the recommended power supply. Damage caused to the unit by
incorrect voltage or wiring is not covered by the warranty.
Model:
XAM300
B/W Entry Phone/Monitor
CCTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XAM300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XAM300

Summary of Contents for XVision XAM300

  • Page 1: Before You Begin

    CCTV XAM300 Model: B/W Entry Phone/ Monitor Before you begin • Please unpack the box carefully and identify that all the parts are present. • Do not cut the cables, this will void the warranty. • Make sure you use only the recommended power supply. Damage caused to the unit by incorrect voltage or wiring is not covered by the warranty.

  • Page 2: Safety Precautions

    Thank you for purchasing this Xvision Video Door Entry Phone/Monitor. Before operating this product, please read this instruction manual carefully. 1. Safety Precautions 2. Product Description The XA300 is an excellent value B/W Video Door Entry Phone/Monitor, designed for ease of use and maximum reliability. It can be used together with any one of the B/W cameras in the B/W Door Entry Range and features a large B/W 4”...
  • Page 3 Compatible with XA300M (Visitor Memory) and XA300H (Intercom Handset) units in the B/W Door Entry Range Can be connected to up to 2 additional XAM300 units for multi room configurations Designed for internal use and wall mounting 4. Contents Wall Mount...
  • Page 4 5. Controls 6. Call Button Press to call the second monitor or intercom phone. 1. Handset Used for communication with 7. Door Release Button visitors. Used to unlock an electronic door locking system. 2. Speaker Sounds a ‘chime’ tome when a 8.

  • Page 5: Installation

    6. Installation 1. Choose a suitable location to mount the phone/monitor. The handset should be mounted 1.50 to 1.70m from floor level. 2. Fix the mounting plate to the wall, using the screws supplied (see Fixing Holes Guide). Drill a hole in the centre of the mounting plate large enough to feed the cables through.
  • Page 6 6. Installation (continued) 4. Attach the phone/monitor to the mounting plate by placing the handset over the four bracket hooks and sliding the unit down. 5. Insert the securing screw into the hole on the top of the mounting plate to secure the handset. 6.

  • Page 7: Installation Notes

    6. Installation- Notes Use the following points to help you complete a trouble free installation: 1. Treat the unit with care Do not disassemble the unit as you may damage the internal components. Dropping the unit or banging it against another object may cause the unit to malfunction.

  • Page 8: Operation

    7. Operation Turn power switch ON, use the slide switches to adjust volume and brightness. 1. When the visitor presses the ‘Call’ button on the door entry camera, the monitor will sound a ‘chime’ tone to announce that a visitor is at the door. View the visitor on the screen and communicate with the visitor using the handset.

  • Page 9: System & Wiring Diagrams

    8. System & Wiring Diagrams Basic: Multi Apartment Entry Camera/Single Monitor System Diagram Wiring Diagram...
  • Page 10 8. System & Wiring Diagrams (continued) Option 1: Multi Apartment Entry Camera/Single Monitor/Single Intercom Phone System Diagram Wiring Diagram...
  • Page 11 8. System & Wiring Diagrams (continued) Option 2: Multi Apartment Entry Camera/Two Monitors System Diagram Wiring Diagram...
  • Page 12 8. System & Wiring Diagrams (continued) Option 3: Multi Apartment Entry Camera/Single Monitor/Single Visitor Memory Unit System Diagram Wiring Diagram...
  • Page 13 8. System & Wiring Diagrams (continued) Option 4: Multi Apartment Entry Camera/Two Monitors/Single Visitor Memory Unit System Diagram Wiring Diagram...
  • Page 14 8. System & Wiring Diagrams (continued) Option 5: Multi Apartment Entry Camera/Multiple Monitors/Visitor Memory Unit/ Intercom Phone System Diagram Wiring Diagram...

  • Page 15: Specifications

    Specifications Model: XAM300 Screen Illumination: 4” B&W CRT Operating Current: DC 650mA Operating Voltage: 110-240V AC Installation: 4 wire cabling Call Tone: Chime sound Communication Type: With handset communication Max. Wiring Distance: 50m (165 feet) (22AWG, 0.65mm 4 wires Operating Temperature: -10°C to +55°C...
  • Page 16 CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
