XVision XAM104-116 Manual

B/w multi apartment entry camera with 4, 8,10, 12 or 16 call buttons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XAM104-116
Model:
B/W Multi Apartment Entry Camera
with 4, 8,10, 12 or 16 Call Buttons

Before you begin

•
Please unpack the box carefully and identify that all the parts are present.
•
Do not cut the cables, this will void the warranty.
•
Make sure you use only the recommended power supply. Damage caused to the unit by
incorrect voltage or wiring is not covered by the warranty.
Model:
XAM104-116
B/W Multi Apartment Entry Camera
with 4, 8,10, 12 or 16 Call Buttons
CCTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XAM104-116 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XAM104-116

Summary of Contents for XVision XAM104-116

  • Page 1: Before You Begin

    CCTV XAM104-116 Model: B/W Multi Apartment Entry Camera with 4, 8,10, 12 or 16 Call Buttons Before you begin • Please unpack the box carefully and identify that all the parts are present. • Do not cut the cables, this will void the warranty.

  • Page 2: Safety Precautions

    Thank you for purchasing this Xvision Video Door Entry Phone/Monitor. Before operating this product, please read this instruction manual carefully. 1. Safety Precautions 2. Product Description The XAM104, 108, 110, 112 & 116 are an excellent value range of B/W Multi Apartment Cameras with multiple call buttons, designed for ease of use and maximum reliability.
  • Page 3 4 Wire Technology allows the video output to be wired to a CCTV monitor or system Power is supplied by the Video Door Entry Monitor making installation simple Compatible with Xvision Door Entry Monitors. One monitor required per call button Suitable for Internal or External use 4. Contents...
  • Page 4 5. Controls & Parts XAM104 Front Back 1. CMOS Camera 6. Camera Angle Adjust 2. Speaker 7. Release connection wire 3. Microphone 8. External Power (optional) 4. Apartment Call Buttons 9. Wiring Terminal Block 5. Apartment Door Number 10. Fixing hole...
  • Page 5 XAM108 Front Back 1. CMOS Camera 6. Camera Angle Adjust 2. Speaker 7. Release connection wire 3. Microphone 8. External Power (optional) 4. Apartment Call Buttons 9. Wiring Terminal Block 5. Apartment Door Number 10. Fixing hole...
  • Page 6 XAM110 Front Back 1. CMOS Camera 6. Camera Angle Adjust 2. Speaker 7. Release connection wire 3. Microphone 8. External Power (optional) 4. Apartment Call Buttons 9. Wiring Terminal Block 5. Apartment Door Number 10. Fixing hole...
  • Page 7 XAM112 Front Back 1. CMOS Camera 6. Camera Angle Adjust 2. Speaker 7. Release connection wire 3. Microphone 8. External Power (optional) 4. Apartment Call Buttons 9. Wiring Terminal Block 5. Apartment Door Number 10. Fixing hole...
  • Page 8 XAM116 Front Back 1. CMOS Camera 6. Camera Angle Adjust 2. Speaker 7. Release connection wire 3. Microphone 8. External Power (optional) 4. Apartment Call Buttons 9. Wiring Terminal Block 5. Apartment Door Number 10. Fixing hole...

  • Page 9: Installation

    6. Installation 1. Choose a suitable location to mount the Multi Apartment Entry Camera. The handset should be mounted 1.50 to 1.70m from floor level. 2. Fix the mounting bracket to the wall. 3. Attach the unit to the mounting bracket. 4.

  • Page 10: Installation Notes

    6. Installation- Notes Use the following points to help you complete a trouble free installation: 1. Do not position the door entry camera in sunlight or where it may be affected by rain The unit is suitable for external use, however it should be mounted in an area where it is sheltered from rain and snow.

  • Page 11: System & Wiring Diagrams

    7. System & Wiring Diagrams 3 Monitors to one Call Button Connection R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video) Intercom Audio Phone to Video Door Monitor Connection R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video) Note: If you are adding Intercom Phones to your system you will not need to use the white wire.

  • Page 12: Wiring Diagram

    XAM104 Wiring Diagram R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video) XAM108 Wiring Diagram R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video)
  • Page 13 XAM110 Wiring Diagram R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video) XAM112 Wiring Diagram R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video)
  • Page 14 XAM116 Wiring Diagram R: Red (Audio) B: Blue (GND) Y: Yellow (Power) W: White (Video)

  • Page 15: Specifications

    Specifications Model: XAM104/108/110/112/116 Camera Type: Image Sensor: 1/3 CMOS Nightvision: Installation: 4 wire cabling Communication Type: Hands Free Max. Wiring Distance: 50m (165 feet) (22AWG, 0.65mm 4 wires) Operating Temperature: -5°C to +60°C...
  • Page 16 CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
