XVision XAM300H Instruction Manual

Intercom handset

Advertisement

Quick Links

TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your local
distributor.
LIMITED WARRANTY:
This product is supplied with a 1 Year warranty. The Warranty excludes
products that have been misused, (including accidental damage) and
damage caused by normal wear and tear. In the unlikely event that you
encounter a problem with this product, it should be returned to the
place of purchase.
Manufactured exclusively for:
Xvision (Europe) Group,
Head Office: London, U.K.
Email: info@x-vision.co.uk
Web: www.x-vision.co.uk
CCTV
Model:
Intercom Handset for
XAM300
Before you begin
Please unpack the box carefully and identify that all the parts are present.
Do not cut the cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the unit by
incorrect voltage or wiring is not covered by the warranty.
Model:
XAM300H
Intercom Handset for XAM300
XAM300H
CCTV
