XVision XA001 Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XA001
Model:
Audio Door Entry System
with Single Phone

Before you begin

•
Please unpack the box carefully and identify that all the parts are present.
•
Do not cut the cables, this will void the warranty.
•
Make sure you use only the recommended power supply. Damage caused to the unit by
incorrect voltage or wiring is not covered by the warranty.
Model:
XA001/XA002
Audio Door Entry System with
Single/Two Phone(s)
XA002
Model:
Audio Door Entry System
with Two Phones
CCTV
XA200 System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XA001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XA001

Summary of Contents for XVision XA001

  • Page 1: Before You Begin

    CCTV XA200 System XA001 XA002 Model: Model: Audio Door Entry System Audio Door Entry System with Single Phone with Two Phones Before you begin • Please unpack the box carefully and identify that all the parts are present. • Do not cut the cables, this will void the warranty.

  • Page 2: Safety Precautions

    Easy to use, single button Phone unit(s) for Call and Door Release for remote opening of door/gate XA001 operates on 2+2 wiring (2 for power, audio and 2 for release), XA002 operates on 3+2 wiring (3 for power, audio and 2 for release).
  • Page 3 Phone unit requires Internal Wall mounting. Call unit can be mounted externally 4. Contents XA001 System: Wall Plugs Call unit Wall Plugs Mounting Mounting Fixing Screws Screws Screws Phone unit XA002 System - includes an additional Phone unit Wall Plugs...
  • Page 4 5. Controls PHONE UNIT CALL UNIT 1. Handset 6. Speaker Used for two-way communication Used to transmit sound from with callers. Phone unit. 2. Power indicator 7. Microphone Lights when power switch is in Used to speak into for two-way ‘ON’...

  • Page 5: Installation

    6. Installation A. Installation of the Phone unit(s) 1. Choose a suitable location to mount the phone(s). The handset should be mounted 1.50 to 1.70m from floor level. 2. Fix the mounting plate (detachable from unit) to the wall, using the screws supplied. Drill a hole in the centre of the mounting plate large enough to feed the cables through.
  • Page 6 6. Installation (continued) 5. Connect the handset cord to the connector on the bottom of the handset 6. Place the handset in the cradle to complete the installation. B. Installation of the Call unit 1. Ensure weatherproof cover is fitted to the Call unit. 2.

  • Page 7: Installation Notes

    6. Installation- Notes Use the following points to help you complete a trouble free installation: 1. Treat the unit with care Do not disassemble the unit as you may damage the internal components. Dropping the unit or banging it against another object may cause the unit to malfunction.

  • Page 8: Operation

    7. Operation Turn mains power switch ON, use the side switch to adjust chime sound on the Phone unit. 1. When the visitor presses the ‘Call’ button on the Call unit, the Phone unit will sound a ‘chime’ tone to announce that a visitor is at the door.
  • Page 9 8. XA001 System & Wiring Diagram XA001: Audio Door Entry Call unit / Single Phone unit System Diagram Wiring Diagram...
  • Page 10 9. XA002 System & Wiring Diagram XA002: Audio Door Entry Call unit / Two Phone units System Diagram Wiring Diagram...

  • Page 11: Specifications

    XA001/XA002 Operating Voltage: Phone Unit: 220-240V AC Call Unit: 9V DC, 20mA Installation: Call Unit: 2 wire cabling XA001 Phone Unit: 2 wire cabling XA002 Phone Units: 3 wire cabling Call Tone: Chime sound Communication Type: With handset communication Max. Wiring Distance: 150 metres (0.8mm copper wire)

  • Page 12: Technical Support

    CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
