XVision XA200S Quick Manual

Surface mount colour door entry system

Advertisement

Quick Links

XA200S Inst 1.2-Print
18/4/08
12:03 pm
TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your
local distributor.
LIMITED WARRANTY:
This product is supplied with a 1 Year warranty. The Warranty
excludes products that have been misused, (including accidental
damage) and damage caused by normal wear and tear. In the
unlikely event that you encounter a problem with this product, it
should be returned to the place of purchase.
8
Manufactured exclusively for:
Xvision (Europe) Group,
Head Office: London, U.K.
Email: info@x-vision.co.uk
Web: www.x-vision.co.uk
Page 1
CCTV
XA200S
Model:
Surface Mount Colour
Door Entry System
Before you begin
• Please unpack the box carefully and identify that all the parts are present.
• Do not cut the cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to
the unit by incorrect voltage or wiring is not covered by the warranty.
Model:
XA200S
Surface Mount Colour Door
Entry System
CCTV
