XVision XAM300 User Manual

B/w entry phone/monitor
Hide thumbs Also See for XAM300:
Table of Contents

Advertisement

Quick Links

Download this manual
XAM300
Model:
B/W Entry Phone/
Monitor

Before you begin

•
Please unpack the box carefully and identify that all the parts are present.
•
Do not cut the cables, this will void the warranty.
•
Make sure you use only the recommended power supply. Damage caused to the unit by
incorrect voltage or wiring is not covered by the warranty.
Model:
XAM300
B/W Entry Phone/Monitor
CCTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XAM300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XAM300

Summary of Contents for XVision XAM300

  • Page 1: Before You Begin

    CCTV XAM300 Model: B/W Entry Phone/ Monitor Before you begin • Please unpack the box carefully and identify that all the parts are present. • Do not cut the cables, this will void the warranty. • Make sure you use only the recommended power supply. Damage caused to the unit by incorrect voltage or wiring is not covered by the warranty.

  • Page 2: Safety Precautions

    1. Safety Precautions 2. Product Description The XAM300 is an excellent value B/W Video Door Entry Phone/Monitor, designed for ease of use and maximum reliability. It can be used together with any compatible B/W Door Entry Panel from the Xvision Range and features a large B/W 4”...
  • Page 3 (Intercom Handset) units in the B/W Door Entry Range For use in multi apartment buildings where multiple monitor units can be connected to one entry panel Designed for Internal use and wall mounting 4. Contents Wall Mount Bracket XAM300- Phone/Monitor Mounting Securing Wall Plugs Screws Screw...

  • Page 4: Monitor Button

    5. Controls 6. Call Button 1. Handset Press to call the second monitor Used for two-way communication or intercom phone. with visitors. 7. Door Release Button 2. Speaker Used to unlock an electronic door Sounds a ‘chime’ tone when a locking system.

  • Page 5: Installation Notes

    6. Installation- Notes Use the following points to help you complete a trouble free installation: 1. Treat the unit with care Do not disassemble the unit as you may damage the internal components. Dropping the unit or banging it against another object may cause the unit to malfunction.

  • Page 6: Installation

    6. Installation 1. Choose a suitable location to mount the phone/monitor. The handset should be mounted 1.50 to 1.70m from floor level. 2. Fix the mounting plate to the wall, using the screws supplied (see Fixing Holes Guide). Drill a hole in the centre of the mounting plate large enough to feed the cables through.
  • Page 7 6. Installation (continued) 4. Attach the phone/monitor to the mounting plate by placing the handset over the four bracket hooks and sliding the unit down. 5. Insert the securing screw into the hole on the top of the mounting plate to secure the handset. 6.

  • Page 8: Operation

    7. Operation Turn power switch ON, use the slide switches to adjust volume and brightness. 1. When the visitor presses the ‘Call’ button on the door entry camera, the monitor will sound a ‘chime’ tone to announce that a visitor is at the door. View the visitor on the screen and communicate with the visitor using the handset.

  • Page 9: System & Wiring Diagrams

    8. System & Wiring Diagrams Basic: Multi Apartment Entry Camera/Single Video Door Entry Phone Monitor System Diagram Wiring Diagram...
  • Page 10 8. System & Wiring Diagrams (continued) Option 1: Multi Apartment Entry Camera/Single Video Door Entry Phone Monitor/Single Intercom Phone System Diagram Intercom Phone XAM300H Wiring Diagram XAM300H Intercom Phone...
  • Page 11 8. System & Wiring Diagrams (continued) Option 2: Multi Apartment Entry Camera/Two Video Door Entry Phone Monitors System Diagram XAM300 (Unit 2) XAM300 (Unit 1) Wiring Diagram XAM300 (Unit 2) XAM300 (Unit 1)
  • Page 12 8. System & Wiring Diagrams (continued) Option 3: Multi Apartment Entry Camera/Single Video Door Entry Phone Monitor/Single Visitor Memory Unit System Diagram XAM300M Wiring Diagram XAM300M...

  • Page 13: System Diagram

    8. System & Wiring Diagrams (continued) Option 4: Multi Apartment Entry Camera/Two Video Door Entry Phone Monitors/Single Visitor Memory Unit System Diagram XAM300 (Unit 1) XAM300M XAM300 (Unit 2) Wiring Diagram XAM300 XAM300M (Unit 1) XAM300 (Unit 2)
  • Page 14 8. System & Wiring Diagrams (continued) Option 5: Multi Apartment Entry Camera/Multiple Video Door Entry Phone Monitors/Visitor Memory Unit/Single Intercom Phone System Diagram XAM300 (Unit 5) Intercom Phone XAM300H XAM300 (Unit 1) XAM300M Wiring Diagram XAM300 (Unit 5) XAM300 (Unit 1)

  • Page 15: Specifications

    Specifications Model: XAM300 Screen Type: 4” B&W Operating Current: DC 650mA Operating Voltage: 110-240V AC Installation: 4 wire cabling Call Tone: Chime sound Communication Type: With handset communication Max. Wiring Distance: 50m (165 feet) (22AWG, 0.65mm 4 wires) Operating Temperature: -10°C to +55°C...
  • Page 16 CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
