LINN KLOUT
O W N E R S
M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Klout and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Linn Klout

Summary of Contents for Linn Klout

  • Page 1 LINN KLOUT O W N E R S M A N U A L...
  • Page 2 Year 2000 Compliant in such circumstances. Except to the extent implied by law and which by law cannot be excluded, Linn shall not be liable to any party for any costs, claims, losses (including indirect and consequential losses) or liabilities arising from the failure of Linn’s software to be Year 2000 Compliant if used in...
  • Page 3 IMPORTANT SAFETY INFORMATION Explanation of symbols used in this manual and on the product: This symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the enclosure of sufficient magnitude to cause electric shock. This symbol is intended to alert the user to the presence of importance maintenance and servicing information in the instruction and service manuals.
  • Page 4 This appliance is supplied with a non-rewireable mains plug for the intended country. Replacement mains leads can be obtained from your Linn retailer. Should you need to change the plug please dispose of it carefully. A plug with bared conductors is dangerous if engaged in a live socket.
  • Page 5 11. Grounding or Polarization. Do not defeat the precautions taken to ground or polarize the supply to the appliance. 12. Power Cord Protection. Route power cords so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, power sockets and at the point where they exit from the appliance.
  • Page 6 MAINS PLUG REPLACEMENT Should your mains plug need replacing and you are competent to do this proceed as follows. If you are in doubt contact your Linn retailer or a competent electrician. a) Disconnect the plug from the mains supply.
  • Page 7 The addition of any Linn component will improve the sound quality of your system. Linn has a policy of continuously improving its equipment allowing customers to retro-fit most product upgrades.
  • Page 9 The vertically mounted circuit boards transfer the heat from the power stages directly to the case. Sophisticated circuitry protects the KLOUT against overload, and allows it to be used safely into the most complex loudspeaker loads. As with all components in the hi-fi chain, the quality of your system source - turntable, tuner or CD player - is vital in ensuring that you get the best possible results from the KLOUT power amplifier.
  • Page 10 Unpack the KLOUT and retain the packing for future transportation. CAUTION Take care when handling the KLOUT. It weighs 11kg and should be lifted carefully to avoid damage to yourself and the product. Do not stack a KLOUT with other products which will obstruct the airflow, or which cannot support the weight.
  • Page 11 The KLOUT has one pair of RCA phono sockets per channel labelled LINE OUTPUT These phono sockets provide connection to the pre-amplifier and enable the signal to be chained from one KLOUT to another in multi-amplifier applications. WARNING The pre-amplifier and the power amplifier must be switched off before connecting or disconnecting any of the plugs on the rear panel.
  • Page 12 OUTPUT CONNECTIONS Connection of the KLOUT to the loudspeakers should be made with a good quality cable. We recommend the use of Linn K series speaker cable and Linn KNEKT speaker plugs.
  • Page 13 WARNING The KLOUT must be switched off and disconnected from the mains before checking the fuse. The KLOUT will be fitted with the correct fuse by your dealer. Before plugging into the mains, check that the voltage selected is correct for the country of use.
  • Page 14 See Maintenance for further information. If the red indicator is on, and the channel is not muted, this indicates a fault with the KLOUT. If this happens, return the KLOUT to your dealer for examination.
  • Page 15 Position the KLOUT to allow free movement of air around the heatsinks. Do not stack a KLOUT with other products which will obstruct the airflow, or which cannot support the weight.
  • Page 16 If the KLOUT has overheated, switch off and provide more ventilation to allow free movement of air around the heatsinks. If the KLOUT has shut down due to a short circuit, switch off and check the speaker cables and connections.
  • Page 17 To help us, please ask your Linn retailer about the Linn warranty scheme in operation in your country. In many countries registration of your purchase with Linn or its distributor will enable you to receive copies of the Linn Record Newsletter to keep you up to date with developments and products from Linn.
  • Page 18 SPECIFICATIONS DIMENSIONS Width - 320mm Depth - 326mm Height - 80mm (incl. feet) INPUT IMPEDANCE 5 Kilohms VOLTAGE GAIN 28.5 dB POWER OUTPUT 80 Watts per channel into 8 Ohms 160 Watts per channel into 4 Ohms POWER CONSUMPTION 840 VA maximum MAINS SUPPLY/FUSE 220V/240V T3.15 Amps antisurge...
  • Page 20 PACK 567...
