A.1
Jumper and Connector Tables
JP1
Part Number
Footprint
Description
Setting
(1-2)
(2-3)
JP2
Part Number
Footprint
Description
Setting
(1-2)
(2-3)
JP3
Part Number
Footprint
Description
Setting
(1-2)
(2-3)
JP4
PCM-3362 User Manual
CLEAR CMOS
1653003101
JH3X1V-2M
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb
Function
NORMAL (Default)
CLEAR CMOS
LVDS PANEL POWER Select
1653003101
JH3X1V-2M
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb
Function
5V for +VLVDS_PANEL POWER Select
3.3V for +VLVDS_PANEL POWER Select (Default)
COM3 RS422/RS485 Select
1653003101
JH3X1V-2M
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb
Function
RS485 (default)
RS422
PCI I/O Voltage Select
56
