Broan Elite RM60000 SERIES Installation Instructions Manual

Hide thumbs Also See for Elite RM60000 SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual and Installation Instructions, Instruction and Installation Manual

INSTALLATION INSTRUCTIONS

HB0026
RM60000 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!

READ AND SAVE THESE INSTRUCTIONS

INSTALLER: LEAVE THIS MANUAL TO HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGE 11.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Broan-NuTone Canada Inc., 1140 Tristar Drive, Mississauga, ON L5T 1H9 (1-888-882-7626)
REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register
V05527 rev. F

Advertisement

Table of Contents
loading

Related Manuals for Broan Elite RM60000 SERIES

Summary of Contents for Broan Elite RM60000 SERIES

  • Page 1: Installation Instructions

    Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453) NuTone Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687) Broan-NuTone Canada Inc., 1140 Tristar Drive, Mississauga, ON L5T 1H9 (1-888-882-7626) REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register V05527 rev. F...
  • Page 2 To reduce the risk of fire and electric shock, the Broan Elite RM60000 Series hood must be installed with Broan interior blower models RM325H or RM326H; Broan exterior blower models 331H, 332H, 335 or 336;...

  • Page 3: Table Of Contents

    BROAN-NUTONE ONE-YEAR LIMITED WARRANTY Broan-NuTone warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 4: Range Hood System

    RM60000 SERIES RANGE HOOD SYSTEM - INTERIOR BLOWERS Model 441 Model 647 Model 634 or 644 Model 437 (10’’ round wall cap) (7” round wall cap) (roof cap) (High capacity roof cap) Model 418 Model 415 (10” round adjustable elbow) (7”...
  • Page 5 RM60000 SERIES RANGE HOOD SYSTEM - IN-LINE AND EXTERIOR BLOWERS Model 441 Model 437 Model HLB9 (800 cfm) (10” round wall cap) (High capacity roof cap) Model 335 (1200 cfm) or HLB11 (1100 cfm) or 336 (1500 cfm) in-line blower exterior blower Model 331H (600 cfm) (includes two 8”...

  • Page 6: Select Blower Option And Install Ductwork

    1. SELECT BLOWER OPTION AND INSTALL DUCTWORK Either an interior or exterior blower or in-line blower may be used with this hood. The Broan Elite RM60000 Series must be installed with blower models RM325H, RM326H, HLB3, HLB6, HLB9, HLB11, 331H, 332H, 335 or 336 only.

  • Page 7: Measure Installation

    2. MEASURE INSTALLATION Dimensions for the most common installation are shown below. The minimum hood distance above cooktop must not be less than 24’’. A maximum of 30” above cooktop is highly recommended for best capture of cooking impurities. Distances over 30” are at the installer and users discretion. Standard 8 ft.

  • Page 8: Install Backsplash

    4. INSTALL BACKSPLASH (OPTIONAL) (Optional) RMP Series Backsplash must be installed before the hood shell because the hood shell covers the backsplash top mounting screws. In order to be able to install the backsplash, make sure you have at least 18’’ clearance between bottom of hood and range control panel or cooktop.

  • Page 9: Install The Rough - In Plate To The Hood

    9. INSTALL THE ROUGH-IN PLATE TO THE HOOD (ALL BLOWERS) Run power cable to installation location. Refer to the instructions included with the selected blower or rough-in kit (sold separately) for details on installing the rough-in plate. Install the rough-in plate so that the wiring box is located on the right side as you are facing the hood.

  • Page 10: Install Light Bulbs And Warming Lamps

    13. INSTALL LIGHT BULBS AND WARMING LAMPS Install (2) heat lamp bulbs. Use BR40 size, 250 W max., infrared bulbs only (sold separately). Install (3) halogen light bulbs. Use PAR20 size, 50 W (sold separately). 14. INSTALL FILTERS CAUTION Remove protective plastic film covering filters before installing them. It is recommended to install side filters first and finish with center one(s).

  • Page 11: Use And Care

    15. USE AND CARE 16. OPERATION Grease Filters Always turn ON your hood before you begin cooking in order to establish an air flow in the kitchen. Let the blower run The grease filters should be cleaned frequently. Use a for a few minutes to clear the air after you turn off the range.

  • Page 12: Service Parts

    17. SERVICE PARTS HL0031 PART QTY (HOOD WIDTH) NO. NUMBER DESCRIPTION 30’’ 36’’ 42’’ 48’’ 54’’ 60’’ 66’’ 72’’ V06750 ROAN LITE V02264 OCKET V02773 ONNECTOR V02772 EMALE ONNECTOR V03435 HERMOSTAT V03436 HERMOSTAT RACKET V02563 SPST S INGLE WITCH FOR ARMING AMPS V03502...
