• Hot! Do not touch! The glass
and surfaces of this appliance
will be hot during operation and
will retain heat for a while after
shutting
Severe burn may result.
• Carefully supervise children in
the same room as appliance.
• If small children are present in the home, it
is recommended that this appliance be used
with a Firescreen kit.
Printed in Canada
™
off
the
appliance.
Rev. 12 December 2009
Installation and Operating
This installation manual will help you
obtain a safe, efficient, dependable
installation
for
chimney system.
understand these installation instructions
before beginning your installation.
CAUTION: Do not attempt to modify or
alter the construction of the fireplace or
its components.
alteration of construction may void the
warranty, listings and approvals of this
system. In that case, Security Chimneys
International Ltd will not be responsible
for damages. Install the fireplace only as
described in these instructions.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
The fireplace cannot be
operated without a door. Consult your
dealer to select the correct door model of
your choice.
This fireplace is also certified for use in
mobile or manufactured homes
2125 Monterey St., Laval, Quebec, Canada, H7L 3T6
Instructions
your
fireplace
and
Please read and
Any modification or
Listed to standards:
ULC-S610 UL-127
Report # 3011202
PIBISULTIMA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultima and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIS Ultima

Summary of Contents for BIS Ultima

  • Page 1 Installation and Operating Instructions ™ This installation manual will help you obtain a safe, efficient, dependable installation your fireplace chimney system. Please read and understand these installation instructions before beginning your installation. CAUTION: Do not attempt to modify or alter the construction of the fireplace or its components.

  • Page 2: Table Of Contents

    Specifications for Mobile or Manufactured Home Installation CERTIFICATION LABEL ................2 THE FIREPLACE ....................3 INTRODUCTION ........................3 3.1.1 Parts Required 3.1.2 Additional Equipment (optional) OPERATING THE BIS ULTIMA™ ..................4 3.2.1 Fuel 3.2.2 First Fires 3.2.3 Building a Fire 3.2.4 Primary Air and Air Boost Controls 3.2.5...

  • Page 3: Safety Rules

    SAFETY RULES FOR OPERATING YOUR FIREPLACE MODEL BIS ULTIMA • Use only a Security Fireplace glass door, specifically designed for the model BIS ULTIMA fireplace. ™ • When cleaning the fireplace, the ashes should be placed in a metal container with a tight fitting lid.

  • Page 4: Certification Label

    CERTIFICATION LABEL...

  • Page 5: The Fireplace

    Security Chimneys International components. • The BIS ULTIMA is not intended for use with a gas log. Failure to follow these instructions will void the certification and the warranty of the fireplace and may result in an unsafe installation.

  • Page 6: Operating The Bis Ultima

    OPERATING THE BIS ULTIMA™ 3.2.1 Fuel The BIS ULTIMA fireplace is designed to work best when fuelled with seasoned cordwood. Hardwoods are preferred to softwoods since the energy content of wood is relative to its density. Hardwoods will result in a longer burning fire and less frequent refuelling. A moisture content of 15% to 20% (seasoned) is recommended.

  • Page 7: Primary Air And Air Boost Controls

    3.2.4 Primary Air and Air Boost Controls There is no flue damper in the BIS ULTIMA™ fireplace. As is common with air tight stoves, the combustion air control sets the flow of air entering the firebox. This allows for a more precise control of the fire.

  • Page 8: Medium Combustion

    Creosote may accumulate on the glass door. This method of burning should be used only after operating the BIS ULTIMA fireplace with the air control opened to produce a hot fire for about an hour or at medium pace for at least 3 hours. Slow combustion can be used at night in order to reduce the heat output and to prolong the burn.

  • Page 9: Smoking - Causes And Troubleshooting

    As the fire burns, air goes up the chimney. This air must be replaced through leakage into the house or through the outside air duct. When operating the BIS ULTIMA™ fireplace, open a nearby window temporarily to check if there is adequate air supply replacement.

  • Page 10: Maintaining Your Bis Ultima

    G. Do not allow the wood to smoulder or burn without flame, since this will produce excessive creosote in the unit. MAINTAINING YOUR BIS ULTIMA ™ 3.3.1 Creosote When wood is burned slowly without a flame, it produces tar and other organic vapors which combine with expelled moisture to form a black deposit called creosote which accumulates on the flue lining.

  • Page 11: Top Baffle Removal Prior To Cleaning The Chimney

    3.3.3 Top Baffle Removal Prior to Cleaning the Chimney Before starting to clean your chimney, we recommend that you remove the top baffle to avoid creosote dust collection at the top of the baffle. Follow these steps to set the top baffle out of the way: 1.

  • Page 12: Door Installation

    Figure 2 3.3.8 Door Installation The door must be installed only when the installation of the BIS ULTIMA™ fireplace is completed. All you have to do is fit the male part of the hinge, already on the door, to the female part, which is on the fireplace.

  • Page 13: Glass Care - Replacement

    Figure 4 3.3.10 Glass Care - Replacement The glass used for the BIS ULTIMA™ fireplace is a high temperature ceramic glass (1400° F). If the glass breaks, it must be replaced with an identical ceramic glass. Tempered glass or ordinary glass will not withstand the high temperatures of the BIS ULTIMA fireplace.

  • Page 14: Fireplace Installation

    36" X 24 ½". Note the floor construction and consult your local building code to determine if additional support is needed. C. The BIS ULTIMA fireplace may be installed directly on the floor or on a raised base (for proper guidelines, refer to "Hearth Extension Requirements") and a minimum of 6'8"...

  • Page 15: Hearth Extension Requirements

    3.4.2 Hearth Extension Requirements The BIS ULTIMA™ fireplace may be installed directly on a combustible floor; however, the combustible floor in front of the fireplace must be covered with a non-combustible material (tile, marble, stone, etc.). The supplied safety metal strip must be positioned as follows : One half under the front of the fireplace and the other half must extend on the floor over which the hearth extension will be built (figure 5b).
  • Page 16 C. Frame the fireplace with vertical studs at the sides of the fireplace running from floor to ceiling (see figure 8). If combustible facing is to be used, position the studs back, from the front edge of the fireplace, a space the thickness of the facing material so that the facing can be installed flush with the fireplace facing.

  • Page 17: Insulated Chase Construction

    INSULATED CHASE CONSTRUCTION Figure 11 Nailing Flanges Four nailing flanges are provided to secure the fireplace on the floor (see figure beside). Bend the nailing flanges down so each flange is flush with the floor, then using nails or screws, secure the fireplace to the floor (2 Nailing flange places each side).
  • Page 18 Facing 1. Combustible material must be installed flush with the fireplace. It may not project in front of and on the fireplace (i.e. the steel façade of the fireplace) (figure 12). 2. Non-combustible materials such as brick, stone or ceramic tile may project in front of and onto the fireplace facing (figure 13).

  • Page 19: Hot Air Ducting Installation

    The safety rules for hot air ducting gravity kit installations are the following: Minimum height 68" (1727 mm) Maximum length See figure 16 The height of the louver must be measured from the base of the BIS to the middle point of the louver.
  • Page 20 When installing the double outlet system, the hot air outlets can be installed in the same room as the fireplace, or one or both of the outlets can be installed in adjacent or upper rooms. Installing the ducts at different elevations will tend to exhaust more heat out of the higher outlet (figure 16).
  • Page 21 A furnace duct is only single wall and not double wall as is required for the BIS ULTIMA™ fireplace hot air exhaust. 7. Use only Security Chimneys International grills and components as described in this manual.

  • Page 22: Central Forced Air Kit

    3.5.2 Central Forced Air Kit (Not tested under EPA certification) The knock-outs provided on the back and on the sides of the BIS ULTIMA™ fireplace allow the connection of insulated flexible pipe which enables you to heat adjacent rooms up to 50 feet from the fireplace.

  • Page 23: Outside Air Kit

    OUTSIDE AIR KIT (Optional) During operation, the fireplace requires fresh air for combustion and draws air out of the house. It may starve other fuel burning appliances such as gas or oil furnaces. As well, exhaust fans may compete for air, causing negative pressure in the house, resulting in smoke entering the house from the fireplace.

  • Page 24: The Chimney

    For optimum performance of your fireplace, Security Chimneys International recommends the use of an ASHT+/HT6103+ or S2100+/HT6000+ chimneys. 2. The Security fireplace model BIS ULTIMA™ fireplace is listed only with Security Chimneys International Ltd 6" diameter chimney systems. 3. A chimney venting a fireplace shall not vent any other appliance.

  • Page 25: Chimney Installation Instructions

    CHIMNEY INSTALLATION INSTRUCTIONS 1. Cut and frame the holes in the ceiling, floor and roof where the chimney will pass (see figure 25). Use a plumb bob to line up the center of the holes. The sizes are indicated in table 1 for the floor and ceiling holes and table 2 (page 24) for the roof holes.
  • Page 26 Figure 27 Figure 27a AC CHIMNEY INSTALLATION (AIR COOLED GALVALUME CHIMNEY) Mandatory chimney outside air intake Outside air kit NOTE : outside air kits are mandatory for AC chimney and recommended for the fireplace. Figure 28...
  • Page 27 AC CHIMNEY Figure 29 Figure 30 Table 2 ROOF DOWN SLOPE HOLE SIZE SLOPE ASHT+ / HT6103+ S-2100+ / HT6000+ Roof Pitch 6" 6" 6" 12 3/8" (314 mm) 14 1/8" (359 mm) 15" (380 mm) 2/12 12 9/16" (319 mm) 14 3/8"...

  • Page 28: Offset Chimney Installation

    OFFSET CHIMNEY INSTALLATON The minimum chimney height when using elbows is: Fireplace model BIS ULTIMA Chimney model ASHT+ / HT6103+ / S-2100+ / HT6000+ / AC Vertical installation 12 ft. (3.66 m) Two (2) elbows 15 ft. (4.57 m) Four (4) elbows 17 ft.
  • Page 29 TOTAL HEIGHT DEVIATION ONE LENGTH BETWEEN ELBOWS TWO LENGTHS BETWEEN ELBOWS CHIMNEY DEVIATION ELBOW 6” & HEIGHT 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48” & 48” 4 5/16"...
  • Page 30 Figure 31 Figure 32...

  • Page 31: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD (RSM+, RSMI30, RSMI45) When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled firestop or wall radiation shield must be installed. Only one is required. Note: 45º angle for Canada only In cold climate locations, we recommend that you use the insulated wall radiation shield since it will maintain the home’s thermal barrier.

  • Page 32: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION Universal Roof Support This support has three possible uses: 1. For ASHT+ / HT6103+ and S-2100+ / HT6000+, it must be used on a roof to support the chimney. 2. It may be used on a floor, ceiling or roof above an offset to support the chimney above the offset.

  • Page 33: Chimney Adaptor (S-2100+ / Ht6000+)

    Figure 34 CHIMNEY ADAPTOR (S-2100+ / HT6000+) The fireplace is normally supplied with a chimney adaptor suitable for the ASHT+ / HT6103+ chimney. If you want to install a S-2100+ / HT6000+ chimney, an adaptor is available (6UCA) (figure 35). A separate starter section will also be required if AC chimney is installed.

  • Page 34: Installation Instructions For Masonry Application

    For connection at 45º angle, a special connector (BISUMA for the BIS Ultra fireplaces or BISPMA for the BIS Panorama fireplace) must be used to connect the liner to the insulated chimney. For connection at 30º, use the BISUMA30 or BISPMA30 connectors.

  • Page 35: Parts And Components List

    PARTS AND COMPONENTS LIST (AC Chimney) Description Part No. Lengths 6" dia. 12" length AC 6L12 18" length AC 6L18 36" length AC 6L36 48" length AC 6L48 15º elbow AC 6E15 30º elbow AC 6E30 Rain cap AC 6CPR Spark arrester screen Supports Offset support...

  • Page 36: Options

    OPTIONS Part No.: Gravity kit: Complete double ducting system including: 2 elbows 90º, 2 7B30ZK-1 telescopic lengths, 2 grill supports and 2 black grills Black grill with support 7B30ZO Brass grill for 7B30ZK 7B30ZGB Elbow 90º, 8" dia. 7B26ZE90 Elbow 45º, 8" dia. 7B26ZE45 Telescopic length, 8"...

  • Page 37: Replacement Parts

    REPLACEMENT PARTS Baffle refractory (2 pieces) PR-ISO2205 Back refractory PR-SR2203 Right side refractory PR-SR2204D Left side refractory PR-SR2204G Bottom refractory PR-SR2201 Front refractory, right side PR-SR2202D Front refractory, left side PR-SR2202G Secondary air tube PR-SR2271 Secondary air tube lock PR-SR2214 Cast-iron log supports (2) PR-SR2245 Louver...
