BIS Ultra EPA Installation And Operating Instructions Manual
  1. Manuals
  2. Brands
  3. BIS Manuals
  4. Indoor Fireplace
  5. Ultra EPA
  6. Installation and operating instructions manual

BIS Ultra EPA Installation And Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

• Hot! Do not touch! The glass
and surfaces of this appliance
will be hot during operation and
will retain heat for a while after
shutting
Severe burn may result.
• Carefully supervise children in
the same room as appliance.
• If small children are present in the home, it
is recommended that this appliance be used
with a fire screen kit.
Printed in Canada
TM
E P A
E P A
E P A
E P A
off
the
appliance.
Rev. 13 December 2009
Installation and Operating
This installation manual will help you
obtain
a safe, efficient, dependable
installation for your fireplace and chimney
system. Please read and understand these
installation instructions before beginning
your installation.
CAUTION: Do not attempt to modify or
alter the construction of the fireplace or its
components.
alteration of construction may void the
warranty, listings and approvals of this
system. In that case, Security Chimneys
International Ltd will not be responsible
for damages. Install the fireplace only as
described in these instructions.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
operated without a door or firescreen.
Consult your dealer to select the correct
door or firescreen model.
2125 Monterey St., Laval, Quebec, Canada, H7L 3T6
Instructions
Any
modification
The fireplace cannot be
Listed to standards:
ULC-S610, UL-127
Report # 192-5192
PIBISULTRAEPA
or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra EPA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIS Ultra EPA

Summary of Contents for BIS Ultra EPA

  • Page 1 Installation and Operating Instructions E P A E P A E P A E P A This installation manual will help you obtain a safe, efficient, dependable installation for your fireplace and chimney system. Please read and understand these installation instructions before beginning your installation.

  • Page 2: Table Of Contents

    SAFETY RULES ........................1 CERTIFICATION LABEL ....................2 THE FIREPLACE ........................3 ......................3 INTRODUCTION 3.1.1 Parts Required 3.1.2 Additional Equipment (optional) ................... 4 OPERATING THE BIS ULTRA™ Fuel 3.2.1 3.2.2 First Fires 3.2.3 Combustion Control 3.2.4 Accelerated Combustion 3.2.5 Medium Combustion 3.2.6...

  • Page 3: Safety Rules

    SAFETY RULES FOR OPERATING YOUR FIREPLACE MODEL BIS ULTRA™ An outside air kit must be installed on the fireplace model BIS ULTRA Warning: Warning: The fireplace must be operated with the doors fully opened or fully closed. If the doors are left partly opened, smoke may be drawn into the room. If the unit is operated with the doors fully opened, the optional fire screen must be used.

  • Page 4: Certification Label

    CERTIFICATION LABEL...

  • Page 5: The Fireplace

    Security Chimneys International components. • The BIS ULTRA fireplace is not intended for use with a gas log. Failure to follow these instructions will void the certification and the warranty of the fireplace and may result in an unsafe installation.

  • Page 6: Operating The Bis Ultra

    OPERATING THE BIS ULTRA™ 3.2.1 Fuel The BIS ULTRA fireplace is designed to work best when fuelled with seasoned cordwood. Hardwoods are preferred to softwoods since the energy content of wood is relative to its density. Hardwoods will result in a longer burning fire and less frequent refuelling.

  • Page 7: Accelerated Combustion

    Always set the damper so that flames are visible, that way you maintain a good clean combustion process. This method of burning should be used only after operating the BIS ULTRA fireplace with the air control opened to produce a hot fire for about an hour.

  • Page 8: Starting And Maintaining A Fire

    3.2.8 Refuelling For Best Performance The BIS fireplace will operate best if attention is given to operating the unit with the damper fully opened after refueling in order to bring the firebox and the chimney system up to their optimum operating temperature.
  • Page 9 When operating the BIS ULTRA™ fireplace, open a nearby window temporarily to check adequacy of the replacement air supply. 3. Fans operating (e.g.: range hood) These fans draw air out of the house and may actually cause a negative pressure in the house.

  • Page 10: Maintaining Your Bis Ultra

    MAINTAINING YOUR BIS ULTRA™ 3.3.1 Creosote When wood is burned slowly, it produces tar and other organic vapours which combine with expelled moisture to form a black deposit called creosote that accumulates on the flue lining. When ignited, this creosote makes an extremely hot fire. If the creosote accumulation is large, a creosote fire in the chimney can damage the chimney and overheat the surrounding wood framing.

  • Page 11: Doorframe Care

    3.3.4 Doorframe Care Use a glass cleaner and a soft cloth to polish the frame. Do not use abrasives such as steel wool or steel pads for they may scratch the doorframe finish. 3.3.5 Ashes Remove ashes only when the fire is out and the ashes are cold (24 to 48 hours after the fire is out).

  • Page 12: Door Adjustment

    Figure 4 3.3.9 Glass Care - Replacement The glass used for the BIS ULTRA fireplace is a high temperature ceramic glass. If the glass breaks, it must be replaced with a ceramic glass. Tempered glass or ordinary glass will not withstand the high temperatures of the BIS ULTRA fireplace. Replacement glass should be purchased from a Security Chimneys International dealer.

  • Page 13: Glass Care - Cleaning

    3.3.10 Glass Care - Cleaning The BIS ULTRA™ fireplace is designed to keep the glass clean under normal operating conditions. If the BIS ULTRA fireplace is operated continuously with the combustion air damper closed, the glass will tend to get dirty unless the fuel, firebox and glass are maintained at hot temperatures (see "Refuelling For Best Performance”).

  • Page 14: Fireplace Installation

    3. A minimum of 7’ (2134 mm) measured from the floor to the ceiling is required to install the BIS ULTRA fireplace. The appliance can be installed on a combustible floor or on a base, leaving at least 6’8" (2032 mm) from the base of the unit to the ceiling.

  • Page 15: Hearth Extension Requirements

    3.4.2 Hearth Extension Requirements The BIS ULTRA™ fireplace may be installed directly on a combustible floor, however the hearth extension in front of the fireplace must be made of non combustible material and incorporate ½" cement board on the floor (fig.5). The cement board must be covered with tile, marble, stone or other non-combustible material.

  • Page 16: Framing, Facing And Mantel

    3.4.3 Framing, Facing and Mantel The construction of the framing, facing, and mantel must be in accordance with the standards and the following illustrations (figures 7 to 11): 1. Frame the fireplace using 2" x 3" or heavier lumber. 2. WARNING: Combustible materials cannot be used in the space directly above the fireplace (except for framing on the front facing).

  • Page 17: Insulated Chase Construction

    INSULATED CHASE CONSTRUCTION Figure 11 Nailing flanges Four nailing flanges are provided to secure the fireplace on the floor (see figure beside). Bend the nailing flanges down so each flange is flush with the floor, then using nails or screws, secure the fireplace Nailing flange to the floor (2 places each side).

  • Page 18: Hot Air Ducting Installation

    (figure 12). Figure 12 Figure 13 HOT AIR DUCTING INSTALLATION Different hot air ducting systems can be installed with the BIS ULTRA™: Gravity kit Forced air kit (Not EPA approved) (p. 18) 3.5.1 Gravity Kit Double hot air outlet including : (See Figure 15) - 2 telescopic lengths 8"...
  • Page 19 Maximum length See figure 15 The height of the louver must be measured from the base of the BIS to the middle point of the louver. When installing the double outlet system, the hot air outlets can be installed in the same room as the fireplace, or one or both of the outlets can be installed in adjacent or upper rooms.
  • Page 20 A furnace duct is only single wall and not double wall as is required for the BIS ULTRA™ hot air exhaust 7. Use only Security Chimneys International grills and components as described in this manual.

  • Page 21: Central Forced Air Kit (Not Tested Under Epa Certification)

    3.5.2 Central Forced Air Kit (Not tested under EPA certification) The knock-outs provided on the back and on the sides of the BIS ULTRA allow the connection of insulated flexible pipe which enables you to heat adjacent rooms up to 50 feet from the fireplace.

  • Page 22: Outside Air Kit

    4. The air intake register should be installed where it is not likely to be blocked by snow or exposed to extreme wind and well away from automobile exhaust fumes, gas meters and other vents. 5. The duct and register may be installed above or below floor level. 3.6.1 Outside Air Installation Make a 4 ¼"...

  • Page 23: The Chimney

    International recommends ASHT+/HT6103+ or S2100+/HT6000+ chimneys. 2. The Security fireplace model BIS ULTRA™ is listed only with Security Chimneys International Ltd 6" dia. chimney systems. 3. A chimney venting a fireplace shall not vent any other appliance. 4. The minimum chimney height is 12 ft. (3.7 m). In altitude, add 18" (450 mm) to the chimney for every 2000 feet (600 m) above sea level.

  • Page 24: Chimney Installation Instructions

    CHIMNEY INSTALLATION INSTRUCTIONS Cut and frame the holes in the ceiling, floor and roof where the chimney will pass (see figure 22). Use a plumb bob to line up the centre of the holes. The sizes are indicated in table 1 for the floor and ceiling holes and table 2 (page 24) for the roof holes. CHIMNEY SQUARE HOLE SIZE MODEL...
  • Page 25 AC CHIMNEY INSTALLATION (AIR COOLED GALVALUME CHIMNEY) NOTE HE OUTSIDE AIR KIT IS MANDATORY FOR BOTH FIREPLACE AND CHIMNEY Figure 25...
  • Page 26 AC CHIMNEY Figure 26 Figure 27 Table 2 ROOF DOWN SLOPE HOLE SIZE ASHT+ S-2100+ Secure Temp Secure Temp SLOPE HT6103+ HT6000+ Nova Temp Nova Temp Roof Pitch 6" 6" 6" 12 3/8" (314 mm) 14 1/8" (359 mm) 15" (380 mm) 2/12 12 9/16"...

  • Page 27: Offset Chimney Installation

    OFFSET CHIMNEY INSTALLATON The minimum chimney height when using elbows is: Fireplace model BIS ULTRA™ S-2100+ HT6000+ Chimney model Secure Temp / Nova Temp ASHT+ HT6103+ Secure Temp / Nova Temp Vertical installation 12 ft (3.66 m) Two (2) elbows 15 ft.
  • Page 28 TOTAL HEIGHT DEVIATION ONE LENGTH BETWEEN ELBOWS TWO LENGTHS BETWEEN ELBOWS CHIMNEY DEVIATION ELBOW 6” & HEIGHT 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48” & 48” 4 5/16"...
  • Page 29 Figure 28 Figure 29...

  • Page 30: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD RSM+, RSMI30, RSMI45) When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled fire stop or wall radiation shield must be installed. Only one is required. Note: 45º angle for Canada only In cold climate locations, we recommend that you use the insulated wall radiation shield since it will maintain the home’s thermal barrier.

  • Page 31: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION UNIVERSAL ROOF SUPPORT This support has three possible uses: ASHT+ HT6103+ S2100+ 1. For Secure Temp / Nova Temp and Secure Temp / Nova HT6000+ Temp , it must be used on a roof to support the chimney. 2.

  • Page 32: Chimney Chase And Multiple Terminations

    CHIMNEY CHASE AND MULTIPLE TERMINATIONS For the purpose of this manual, a chimney chase is considered a part of the chimney system rather than part of a building. The termination must be placed a minimum of 18" (460 mm) above the chase. For installations where more than one chimney is located in the same chase or within the same area, we suggest that their terminations be separated by at least 16"...

  • Page 33: Installation Instructions For Masonry Application

    For connection at 45º angles, a special connector (BISUMA for the BIS Ultra™ fireplace or BISPMA for the BIS PANORAMA™ fireplace) must be used to connect the liner to the insulated chimney. For connection at 30º, use the BISUMA30 or BISPMA30 connectors.

  • Page 34: Parts And Components List

    PARTS AND COMPONENTS LIST AC Chimney Description Part No. Lengths 6" dia. 12" length AC6L12 18" length AC6L18 36" length AC6L36 48" length AC6L48 15º elbow AC6E15 30º elbow AC6E30 Rain cap AC6CPR Spark arrester band Starter section AC6SB Supports Offset support XSO+ Support section...

  • Page 35: Options

    OPTIONS (Fireplace) Description: Part No.: Complete double ducting system including: 2 elbows 90º, 2 telescopic lengths, 7B30ZK-1 2 grill supports and 2 black grills Black grill with support 7B30ZO Brass grill for 7B30ZK 7B30ZGB Elbow 90º, 8" dia. 7B26ZE90 Elbow 45º, 8" dia. 7B26ZE45 Telescopic length, 8"...

  • Page 36: Replacement Parts

    REPLACEMENT PARTS Rear baffle refractory PR-SR1965 Front baffle refractory PR-SR1968 Back refractory PR-SR1972 Right side refractory PR-SR1971D Left side refractory PR-SR1971G Bottom refractory PR-SR1973 Secondary air tube (rear) PR-SR1995 Secondary air tube (middle) PR-SR1994a Secondary air tube (middle) PR-SR1994b Secondary air tube (middle) PR-SR1994c Secondary air tube (front) PR-SR1979...
