• Hot! Do not touch! The glass
and surfaces of this appliance
will be hot during operation and
will retain heat for a while after
shutting off the appliance. Severe
burn may result.
• Carefully supervise children in
the same room as appliance.
• If small children are present in the home, it
is recommended that this appliance be used
with a fire screen kit.
Installation and Operating
Instructions
This installation manual will help you obtain a
safe, efficient, dependable installation for your
fireplace and chimney system. Please read and
understand
these
before beginning the installation or operating
the fireplace.
CAUTION:
Do not attempt to modify or
alter the construction of the fireplace or its
components. Any modification or alteration of
construction may void the warranty, listings
and approvals of this system. In that case,
Security Chimneys International Ltd will not
be responsible for damages. Install the fireplace
only as described in these instructions.
PLEASE RETAIN THIS MANUAL FOR
FUTURE REFERENCE
WARNING:
This fireplace cannot
operated without doors. Consult your dealer
to select the correct door model of your choice.
2125 rue Monterey, Laval, Québec, Canada, H7L 3T6
installation
instructions
Listed to standards:
ULC-S610, UL-127
Report # 3047213
be

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRADITION and is the answer not in the manual?

Questions and answers

Porchia
April 12, 2025

Watt is the particule emission

0

Subscribe to Our Youtube Channel

Related Manuals for BIS TRADITION

Summary of Contents for BIS TRADITION

  • Page 1 Installation and Operating Instructions This installation manual will help you obtain a safe, efficient, dependable installation for your fireplace and chimney system. Please read and understand these installation instructions before beginning the installation or operating the fireplace. CAUTION: Do not attempt to modify or alter the construction of the fireplace or its components.
  • Page 2 Printed in Canada Rev 5 April 2007 PIBISTRAD...
  • Page 3 25 YEAR LIMITED WARRANTY • Security Chimneys International Ltd. warrants to the owner of a Security Fireplace that the wood burning fireplace will be free from defects in material and workmanship, under normal use and service, for a period of twenty-five (25) years from the date of purchase.
  • Page 4 exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights that vary from state to state.
  • Page 5 Door, latch assembly, hinges, glass retainer, gaskets gaskets, chipped or cracked refractory. Facade assembly Although your BIS fireplace is very efficient, it should Facade, hardware not, in any case, replace the main heating system of the home in which it is installed. This fireplace is designed to...

  • Page 6: Table Of Contents

    SAFETY RULES ................... 1 CERTIFICATION LABEL ................2 THE FIREPLACE ..................3 INTRODUCTION ............................ 3 3.1.1 Parts Required 3.1.2 Additional Equipment (optional) OPERATING THE BIS TRADITION ....................4 3.2.1 Fuel 3.2.2 First Fires 3.2.3 Heat Output 3.2.4 Primary air and air boost controls 3.2.5...

  • Page 7: Safety Rules

    SAFETY RULES FOR OPERATING YOUR FIREPLACE MODEL BIS TRADITION Warning: The BIS Tradition must be installed with an outside air kit inlet, wich is included with the fireplace. Warning: The fireplace must be operated with the doors fully opened or fully closed. If the doors are left partly opened, smoke may be drawn into the room.

  • Page 8: Certification Label

    CERTIFICATION LABEL...

  • Page 9: The Fireplace

    Security Chimneys International components. • The BIS TRADITION is not intended for use with a gas log. Failure to follow these instructions will void the certification and the warranty of the fireplace and may result in an unsafe installation.

  • Page 10: Operating The Bis Tradition

    In spite of the large amount of heat that the BIS Tradition can deliver, it should not replace the main source of heat in your home. This fireplace will bring extra warmth and ambiance to your home by...

  • Page 11: Primary Air And Air Boost Controls

    3.2.4 Primary Air and Air Boost Controls There is no flue damper in the BIS TRADITION. As is common with air tight appliance, the combustion air control sets the flow of air entering the firebox. This allows for a more precise control of the fire.

  • Page 12: Accelerated Combustion

    Creosote may accumulate on the glass door. This method of burning should be used only after operating the BIS TRADITION with the air control opened to produce a hot fire for about an hour or at medium pace for at least 3 hours. Slow combustion can be used at...
  • Page 13 night in order to reduce the heat output and to prolong the burn. The loading time will be between 6-8 hours. At this combustion rate, the level of BTUs is at its lowest.

  • Page 14: Building A Fire

    3.2.10 Refuelling For Best Performance To reload the BIS Tradition at the end of a combustion cycle, when no flame is visible and there are only ashes left: A) Completely open the air control level and the T.D.A.B. (Time Delay Air Boost) level (see figure 1).

  • Page 15: Smoking - Causes And Troubleshooting

    B. Negative pressure in the house As the fire burns, air goes up the chimney. This air must be replaced through the outside air duct. When operating the BIS TRADITION, open a nearby window temporarily to check if there is adequate air supply replacement.
  • Page 16 Make sure that the blower is at the "off" position when you open the fireplace door for reloading.

  • Page 17: Maintaining Your Bis Tradition

    MAINTAINING YOUR BIS TRADITION 3.3.1 Creosote When wood is burned slowly without a flame, it produces tar and other organic vapours which combine with expelled moisture to form a black deposit called creosote which accumulates on the flue lining. When ignited, this creosote makes an extremely hot fire. If the creosote accumulation is large, a creosote fire in the chimney can damage the chimney and overheat the surrounding wood framing.

  • Page 18: Ashes

    To install the new refractory bricks, follow the above steps in reverse. 3.3.7 Door Installation The doors must be put in place only when the installation of the BIS TRADITION completed. All you have to do is fit the male part of the hinge, already on the door, to the female part, which is on the fireplace.

  • Page 19: Door Adjustment

    Do not operate the unit with cracked or broken glass. 3.3.10 Glass Care - Cleaning The BIS TRADITION is designed to keep the glass clean under normal operating conditions. If the BIS TRADITION is operated continuously with the combustion air controls closed, the glass will tend to get dirty unless the fuel, firebox and glass are maintained at hot temperatures (see section 3.2.10).

  • Page 20: Fireplace Installation

    The BIS TRADITION may be installed directly on the floor or on a raised base and a minimum of 6'8" measured from the base of the appliance to the ceiling is required.

  • Page 21: Hearth Extension Requirements

    3.4.2 Hearth Extension Requirements The BIS TRADITION may be installed directly on a combustible floor; however, the combustible floor in front of the fireplace must be covered with one inch (1 in.) of non- combustible support material (cement board, cement block or other) before applying the finish material (tile, marble, stone, etc.) (see figure 7).
  • Page 22 D. WARNING: The fireplace must not be in contact with any insulation or loose filling material. Cover the insulation with gyproc panels or any other rigid material around the fireplace. Figure 8 Figure 9 Figure 10 Figure 11...
  • Page 23 INSULATED CHASE CONSTRUCTION Figure 12...
  • Page 24 Facing Note: The facade must be removable once installed. The facade is designed to overlap any facing material installed on the front of the fireplace. If thicker material is installed, use the facade as a template and make sure it can be easily removed for servicing. 1.
  • Page 25 Figure 15 Figure 14 3.4.4 Fireplace Blower The fireplace comes equipped with a heat activated blower. It is located in the bottom of the fireplace, towards the back. It uses regular 120V and must be connected to the main electrical circuit by a qualified electrician.

  • Page 26: Hot Air Ducting Installation (Optional)

    Maximum length See figure 18 * The height of the louver must be measured from the base of the BIS to the middle point of the louver. WARNING: both pipes of the double hot air outlet must be installed. Any other...
  • Page 27 When installing the double outlet system, the hot air outlets can be installed in the same room as the fireplace, or one or both of the outlets can be installed in adjacent or upper rooms. Installing the ducts at different elevations will tend to exhaust more heat out of the higher outlet (figure 18).
  • Page 28 A furnace duct is only single wall and not double wall as is required for the BIS TRADITION hot air exhaust. 7. Use only Security Chimneys International grills and components as described in this manual.

  • Page 29: Central Forced Air Kit

    3.5.2 Central Forced Air Kit (Not tested under EPA certification) The knock-outs provided on the back and on the sides of the BIS TRADITION allow the connection of insulated flexible pipe which enables you to heat adjacent rooms up to 50 feet from the fireplace hot air outlet.

  • Page 30: Outside Air Kit

    OUTSIDE AIR It is mandatory to install an outside air connection to the BIS Tradition. The following components are required and are included with the fireplace: - Outside air kit - 4" adapter for fireplace connection The outside air assembly must be installed according to the following requirements : A) Duct length should be kept to a minimum.

  • Page 31: The Chimney

    Installations which are located on lower floors in the house, such as in a basement, in combination with an outside chimney, are especially prone to flow reversal. 2. The Security fireplace model BIS TRADITION is listed only with Security Chimneys S2100+ HT6000 International Ltd 7"...

  • Page 32: Chimney Installation Instructions

    CHIMNEY INSTALLATION INSTRUCTIONS 1. Cut and frame the holes in the ceiling, floor and roof where the chimney will pass (see figure 27). Use a plumb bob to line up the centre of the holes. The sizes are indicated in table 1 for the floor and ceiling holes and table 2 (page 28) for the roof holes.
  • Page 33 CHIMNEY INSTALLATION MODEL ACBI Note: Outside air kits must be installed for both fireplace and ACBI chimney. Figure 30...
  • Page 34 CHIMNEY MODEL ACBI Figure 31 Figure 32 Table 2 ROOF DOWN SLOPE HOLE SIZE S2100+ Secure Temp HT6000+ Nova Temp ACBI DEGREE OF Secure Temp SLOPE 7" 7" 15" (380 mm) 15" (380 mm) 2/12 15 3/8" (390 mm) 15 3/8" (390 mm) 4/12 16 1/8"...

  • Page 35: Offset Chimney Installation

    OFFSET CHIMNEY INSTALLATON The minimum chimney height when using elbows is: Fireplace Model BIS TRADITION S-2100+ HT6000+ Chimney Model Secure Temp / Nova Temp / Secure Temp / ACBI Vertical Installation 3.66 m (12’) Two (2) Elbows 4.57 m (15’) Four (4) Elbows 5.18 m (17’)
  • Page 36 TOTAL HEIGHT DEVIATION ONE LENGTH BETWEEN ELBOWS TWO LENGTHS BETWEEN ELBOWS CHIMNEY ELBOW DEVIATION 7” & HEIGHT 8” 12” 18” 24” 36” 48” 8” & 48” 12 & 48” 18 & 48” 24” & 48” 36” & 48” 48” & 48” 3 5/16"...
  • Page 37 Figure 33 Figure 34...

  • Page 38: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD (XRSMI30, XRSMI45, AC10RSMI30) When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled firestop or wall radiation shield must be installed. Only one is required. Note: 45º angle for Canada only In cold climate locations, we recommend that you use the insulated wall radiation shield since it will maintain the home’s thermal barrier.

  • Page 39: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION UNIVERSAL ROOF SUPPORT This support has three possible uses: S2100+ HT6000+ 1. For Secure Temp / Nova Temp / Secure Temp , it must be used on a roof to support the chimney. 2. It may be used on a floor, ceiling or roof above an offset to support the chimney above the offset.

  • Page 40: Chimney Chase And Multiple Terminations

    CHIMNEY CHASE AND MULTIPLE TERMINATIONS For the purpose of this manual, a chimney chase is considered a part of the chimney system rather than part of a building. The termination must be placed a minimum of 18" (460 mm) above the chase. For installations where more than one chimney is located in the same chase or within the same area, we suggest that their terminations be separated by at least 16"...

  • Page 41: Installation Instructions For Masonry Application

    The chimney must be relined with a stainless steel liner model Tubinox or Projet SS of the same diameter as the outlet of the fireplace. For connection at 45º angle, a special connector (BISTMA for the BIS TRADITION fireplace) must be used to connect the liner to the insulated chimney. For connection at 30º, use the BISTMA30 connectors.

  • Page 42: Parts And Components List

    PARTS AND COMPONENTS LIST ACBI Chimney Description Part No. Lengths 7" dia. 12" length ACBI7L12 18" length ACBI7L18 36" length ACBI7L36 48" length ACBI7L48 15º elbow ACBI7E15 30º elbow ACBI7E30 Starter section ACBI7SB Offset starter section 30 deg. ACBI7SB30 Rain cap ACBI7CPR Spark arrester screen Supports...

  • Page 43: Options

    OPTIONS Gravity kit: Part No.: Complete double ducting system including : 2 elbows 90º, 2 7B30ZK-1 telescopic lengths, 2 grill supports and 2 black grills Black grill with support 7B30ZO Brass grill for 7B30ZK-1 7B30ZGB Elbow 90º, 8" dia. 7B26ZE90 Elbow 45º, 8"...
  • Page 44 ctory brick Back refra PR-SR2415 Right side refractory bricks Back PR-SR2417, Front PR-SR2419 Left side refractory bricks Back PR-SR2416, Front PR-SR2418 Bottom refractory brick PR-SR2422 Baffles top of firebox PR-ISO2205 Top hearth insulation PR-ISO2521 Timer PR-SR2425 Secondary air tube (4) PR-SR2379 Log retainers (2) PR-B2CH...
