O P E R A T O R ' S M A N U A L
!
Operating this ATV if you are under
the age of 16 increases your chance
UNDER
16
of severe injury or death.
NEVER operate this ATV if you are
under 16.
WARNING
700 Diesel
www.arcticcat.com
Do not remove this Operator's Manual from this ATV
according to the guidelines and agreement with the U.S.
Consumer Product Safety Commission.
Read this manual carefully.
It contains important safety
information.
