Table Of Contents - Argoclima oscar junior Technical Data & Service Manual

1. SPECIFICATIONS
1-1 Unit Specifications
1-2 Major Component Specifications
2. DIMENSIONAL DATA
2-1 Unit Dimensions
3. ELECTRICAL DATA
3-1 Electric Wiring Diagram
4. REFRIGERANT FLOW DATA
4-1 Refrigerant Flow Diagram
5. FUNCTION
5-1 Room Temperature Control
5-2 Heat Exchanger Frosting Prevention
5-3 Dry Operation (Dehumidification)
6. PERFORMANCE DATA
6-1 Performance Chart
7. TROUBLESHOOTING
7-1 The unit does not work
7-2 Electrical circuit interrupted after "ON" button is pressed
7-3 Electrical circuit interrupted 3 minutes after "ON" button is pressed
7-4 Fan motor does not work while "ON" button is pressed
7-5 Fan works at one speed only
7-6 Poor cooling
7-7 Fan motor works normally but the compressor does not operate
2
Page
3
3
4
6
6
7
7
8
8
9
9
9
10
11
11
12
12
12
13
13
14
14
15
