Page 1: Technical Data
TECHNICAL DATA & SERVICE MANUAL INDOOR UNIT: AW22AL AW28AL AW38AL AW42AL SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. AW22AL 387030005 AW28AL 387030006 AW38AL 387030007 AW42AL 387030094 0.8180.467.0 07/05... - Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. INDOOR UNITS MATCHING TABLE 4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams 5. CONTROL SYSTEM 5-1 Electronic control 5-2 Legend 5-3 PCB 5-4 General Functions 5-5 Cooling Mode... -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications AW22AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit... - Page 5 AW28AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit Timer ON/OFF 24 hours 3 and Auto...
- Page 6 AW38AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit Timer ON/OFF 24 hours 3 and Auto...
- Page 7 AW42AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit Timer ON/OFF 24 hours 3 and Auto...
-
Page 8: Major Component Specifications
1-2 Major Component Specifications AW22AL Controller PCB Part No. Controls Microprocessor Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 91 Q'ty ……. Dia. and lenght RPS7V…1... - Page 9 AW28AL Controller PCB Part No. Microprocessor Controls Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 91 Q'ty ……. Dia. and lenght RPS7U…1 Fan motor model…Q'ty 4…960 No.
- Page 10 AW38AL Controller PCB Part No. Microprocessor Controls Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 91 Q'ty ……. Dia. and lenght RPS14L…1 Fan motor model…Q'ty 4…1230 No.
- Page 11 AW42AL Controller PCB Part No. Microprocessor Controls Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 91 Q'ty ……. Dia. and lenght RPS15S…1 Fan motor model…Q'ty 4…1280 No.
-
Page 12: Other Component Specifications
1-3 Other Component Specifications AW22AL AW28AL AW38AL AW42AL NTC-THERMISTOR Thermistor ( Coil sensor ) ΚΩ 10 at 25 °C Resistance NTC-THERMISTOR Thermistor ( Room sensor ) ΚΩ Resistance 10 at 25 °C... -
Page 13: Dimensional Data
2. DIMENSIONAL DATA... -
Page 14: Indoor Units Matching Table
3. INDOOR UNIT MATCHING TABLE INDOOR UNITS OUTDOOR UNITS AW22AL AW28AL AW38AL AW42AL ☺ AE22AC ☺ AE28AC ☺ AE38AC ☺ AE42AC ☺ AE22ACL ☺ AE28ACL ☺ AE38ACL ☺ AE42ACL ☺ AE22AH ☺ AE28AH ☺ AE38AH ☺ AE42AH... -
Page 15: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams AW22AL AW28AL AW38AL... - Page 16 AW42AL...
- Page 52 Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.it...
