- Page 1 All manuals and user guides at all-guides.com TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: AER518SC AER518SCL AER522SC SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. AER518SC 387007114 AER518SCL 387007140 AER522SC 387007142 0.8180.267.0 05/2002...
- Page 2 All manuals and user guides at all-guides.com IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... -
Page 4: Operating Range
All manuals and user guides at all-guides.com 1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. (*)19°C D.B. (*) SCL MODEL : -15°C D.B. -
Page 5: Specifications
All manuals and user guides at all-guides.com 2. SPECIFICATIONS 2-1 Unit Specifications AER518SC 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance * AWR518CL 5,00 Capacity BTU/h 17063 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Electrical Rating 198 ~ 264 Available voltage range... - Page 6 All manuals and user guides at all-guides.com AER518SCL 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance * AWR518CL 5,00 Capacity BTU/h 17063 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Electrical Rating 198 ~ 264 Available voltage range 10,00 Running amperes...
- Page 7 All manuals and user guides at all-guides.com AER522SC 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance * AWR518CL 5,90 Capacity BTU/h 20134 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Electrical Rating 198 ~ 264 Available voltage range 13,00 Running amperes...
-
Page 8: Major Component Specifications
All manuals and user guides at all-guides.com 2-2 Major Component Specifications Outdoor Unit: AER518SC Compressor Rotary (Hermetic) Type Compressor model 80807045B C-2RN170H5W 1700 Nominal output FV68S…800 Compressor oil…Amount C-R: 1,353 Coil resistance (Ambient temp. 25°C) Ω C-S: 3,422 Internal protector Safety devices Type Overload relay... - Page 9 All manuals and user guides at all-guides.com Outdoor Unit: AER518SCL Compressor Rotary (Hermetic) Type Compressor model 80242335 C-RN190H5B 1900 Nominal output FV68S…2100 Compressor oil…Amount C-R: 0,921 Coil resistance (Ambient temp. 25°C) Ω Ω C-S: 2,843 Internal protector Safety devices Type Overload relay Automatic opening Operating Temp.
- Page 10 All manuals and user guides at all-guides.com Outdoor Unit: AER522SC Compressor Rotary (Hermetic) Type Compressor model 80244035 C-RN220H5A 2200 Nominal output FV68S…1350 Compressor oil…Amount C-R: 0,777 Coil resistance (Ambient temp. 25°C) Ω Ω C-S: 2,408 Internal protector External protector Safety devices Type OL-D24 Overload relay...
-
Page 11: Dimensional Data
All manuals and user guides at all-guides.com 3. DIMENSIONAL DATA AER518SC Outdoor Unit: AER518SCL Air intake 4 – ø12 holes Air discharge Wide tube service valve ø12.7 (1/2") Narrow tube service valve ø6.35 (1/4") Unit : mm... - Page 12 All manuals and user guides at all-guides.com AER522SC Outdoor Unit: Air intake Air discharge Wide tube service valve ø15.88 (5/8") Narrow tube service valve ø6.35 (1/4") 6 – ø3.1 holes Check port ø6.35 (1/4") Unit : mm...
-
Page 13: Refrigerant Flow Diagram
All manuals and user guides at all-guides.com 4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: AER518SC Indoor Unit: Outdoor Unit: AER518SCL... - Page 14 All manuals and user guides at all-guides.com Indoor Unit: Outdoor Unit: AER522SC...
-
Page 15: Performance Data
All manuals and user guides at all-guides.com 5. PERFORMANCE DATA 5-1 Performance charts AER518SC n Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,60 Indoor inlet air D.B. (°C) 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. - Page 16 All manuals and user guides at all-guides.com AER518SCL n Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) Indoor inlet air D.B. (°C) 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Overload prevention operates to protect the air conditioner when outdoor ambient temperature reaches extremely high values in heating mode.
- Page 17 All manuals and user guides at all-guides.com AER522SC n Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) Indoor inlet air D.B. (°C) 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Overload prevention operates to protect the air conditioner when outdoor ambient temperature reaches extremely high values in heating mode.
-
Page 18: Cooling Capacity
All manuals and user guides at all-guides.com 5-2 Cooling Capacity AER518SC OUTDOOR UNIT: AWR518CL INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 5,00 kW moisture removal 2,3 l/h COMP. POWER INPUT 2,044 kW max comp input 2,494 kW AIR FLOW RATE 760 m³/h EVAPORATOR CONDENSER... - Page 19 All manuals and user guides at all-guides.com AER518SCL OUTDOOR UNIT: AWR518CL INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 5,00 kW moisture removal 2,3 l/h COMP. POWER INPUT 2,043 kW max comp input 2,493 kW AIR FLOW RATE 760 m³/h EVAPORATOR CONDENSER ENT.TEMP.
- Page 20 All manuals and user guides at all-guides.com AER522SC OUTDOOR UNIT: AWR522CL INDOOR UNIT: 220 - 240V ~ 50Hz RATING CAPACITY 5,90 kW moisture removal 3,3 l/h COMP. POWER INPUT 2,551 kW max comp input 3,101 kW AIR FLOW RATE 830 m³/h EVAPORATOR CONDENSER ENT.TEMP.
-
Page 21: Electrical Data
All manuals and user guides at all-guides.com 6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: AER518SC COOLING Indoor Unit Complete Unit Outdoor unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,37 0,40 9,23 10,0 Power input... - Page 22 All manuals and user guides at all-guides.com OUTDOOR UNIT: AER518SCL COOLING Indoor Unit Complete Unit Outdoor unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,37 0,41 10,0 Power input 0,070 0,087 2,043 2,200 Full load conditions Running Amps.
- Page 23 All manuals and user guides at all-guides.com OUTDOOR UNIT: AER522SC COOLING Indoor Unit Complete Unit Outdoor unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,39 0,55 12,1 13,0 Power input 0,075 0,124 2,551 2,750 Full load conditions...
-
Page 24: Electric Wiring Diagram
All manuals and user guides at all-guides.com AER518SC 6-2 Electric Wiring Diagram OUTDOOR UNIT: AER518SCL OUTDOOR UNIT:... - Page 25 All manuals and user guides at all-guides.com AER522SC OUTDOOR UNIT:...
-
Page 26: System Wiring Diagram
All manuals and user guides at all-guides.com 6-3 System Wiring Diagram... - Page 27 All manuals and user guides at all-guides.com Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.it...
