The screen

Status icons
Mode indication
Work profile
Rudder command
Icon Description
Black icon if one or more thrusters are installed and in use.
Shaded if the trusters are unavailable for steering
Active alarm message. Red icon for alarms, yellow for warnings
Control unit locked
Screen alive indication - white and black "balls" fade-swap color

The power key

•
Press and hold:
•
Single press:
•
Repeated presses:
¼ Note:
If the key is held after the display is turned off, a Power failure alarm will be
activated. Press any other key on the unit to silence the alarm.

Command transfer and unit lock

Take command
CMD
Turn unit on/off
Display light dialog
Toggle preset brightness
levels
Lock other units
Heading repeater
Mode info panel
Rudder bar
CMD
