- Page 1 8×8 HDMI over Single CAT5e/6/7 Matrix with PoE ID# 986 Operation Manual...
- Page 2 Introduction The HDBaseT™ 8 by 8 HDMI Matrix over CAT5e/6/7 supports the transmission of video (resolutions up to 1080p Full HD and 1920×1200@60Hz) and multi-channel digital audio from eight high definition sources to eight outputs over a single CAT5e/6/7 cable (up to 100m) for each output.
- Page 3 System Requirements HDMI equipped source devices, connect with HDMI cables or • DVI equipped source, connect with DVI to HDMI cables HDMI equipped displays (TVs or monitors) or HDMI equipped • AV receivers, connected with HDMI cables Industry standard CAT5e/6/7 cables •...
- Page 4 E~H need to be set to input 2, then the following sequence of button presses need to be performed: Press: OUT →A→B→C→D→IN→1→MENU, and then press: OUT→E→F→G→H→IN→2→MENU. Note: If the MENU button is not pressed the selection will not be changed Back Panel CONTROL: This port is the link for Telnet or Web GUI controls, connect...
- Page 5 that the remote being used is within the direct line-of-sight of the IR extender. It will send out the IR signal received to the selected IR OUT (A-H). CAT5e/6/7 OUT A~H: Connect the CAT outputs to the CAT input port of the receiver units with a single CAT5e/6/7 cable for HDMI Audio/ Video and IR control signal transmission.
- Page 6 Remote Control POWER: Press this button to switch the device 'ON' or set it to standby mode. Input selection 1~8. OUT: Output selection A~H. Note: When the IR remote is used in the Output Zone the user only needs to select the desired input (1~8) IR Cable PIN Assignments...
-
Page 7: Hdmi Matrix
RS-232 Pin Assignment HDMI MATRIX REMOTE CONTROL CONSOLE Assignment Assignment → ← Baud Rate: 19200 bps Data Bit: 8-bit Parity: None Stop Bit: 1-bit Flow Control: None RS-232 Telnet Commands COMMAND DESCRIPTION A1~A8 Switch Output A to 1~8 B1~B8 Switch Output B to 1~8 C1~C8 Switch Output C to 1~8 D1~D8... - Page 8 Power Off Power On I1~I8 Switch all the output to 1~8 Display the current matrix state and firmware version System Reset to H8 Setting EDID MODE. 1-STD 2-TV. Display all available commands QUIT Exit (Telnet only) Note: 1.Commands will not be executed unless followed by a carriage return.
- Page 9 Once in the command line interface (CLI) type "telnet", then the IP address of the unit and "23", then hit enter. Note: The IP address of the Matrix can be displayed on the device's LCM monitor by pressing the Menu button twice. This will bring us into the device which we wish to control.
- Page 10 Web GUI Control On a PC/Laptop that is connected to the same active network as the Matrix, open a web browser and type the device's IP address on the web address entry bar. The browser will display the device's status, control and User setting pages.
- Page 11 CAT5e/6/7 Cable Specification CABLE RANGE PIXEL VIDEO SUPPORTED TYPE CLOCK DATA VIDEO RATE RATE CAT5e/6/7 100m ≤225 MHz ≤5.3 Gbps Up to 1080p, 60 Hz, (HD Video) 36 bits, 3D (data rates lower than 5.3 Gbps or below 225 MHz TMDS clock). >225 MHz >...
- Page 12 Specifications Video Bandwidth 225 MHz/6.75 Gbps Input Ports 8×HDMI, 9×IR Extender, 1×RS-232, 1×RJ- 45 (Control), 1×Mini USB Type B (For firmware updated only) Output Ports 8×CAT5e/6/7, 9×IR Blaster IR Frequency 30~50 kHz Supported Resolutions HDTV: 480i~1080p@50/60 & 1080p@24 PC: VGA~WXGA HDMI Input Cable Length 15m (1080p@8-bit) 10m (1080p@12-bit)
