10x10 HDMI 6G HDBaseT Matrix
with 48v PoH - # 15425
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 15425 and is the answer not in the manual?

Questions and answers

Related Manuals for Converters.TV 15425

Summary of Contents for Converters.TV 15425

  • Page 1 10x10 HDMI 6G HDBaseT Matrix with 48v PoH - # 15425 Operation Manual...
  • Page 2 Introduction This 10×10 HDMI and HDBaseT Matrix supports routing and transmission of video (resolutions up to 4K@60Hz w/ HDMI 2.0 & HDCP 2.2) and audio (multi-channel digital/stereo analog) while providing flexible control via IR, RS-232, Telnet or WebGUI. As many as ten UltraHD sources may be routed to any of ten destinations, eight via single Cat.5e/6/7 cables (up to 100m at 1080p or up to 60m at 4K@30Hz) and two via HDMI 2.0 outputs.
  • Page 3 Features • HDMI 2.0, HDCP 1.4 and HDCP 2.2 compliant • Routes 10 HDMI sources to 10 displays using 8 HDBaseT outputs and 2 independent or mirrored HDMI outputs • HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, 48v PoH (Power over HDBaseT) and control (Bi-directional IR &...
  • Page 4 System Requirements • HDMI or DVI source equipment such as media players, video game consoles, set-top boxes, PCs or laptops. DVI equipped source devices must be connected via DVI to HDMI cables/adapters • HDMI receiving equipment such as HDTVs, monitors or audio amplifiers •...
  • Page 5 selected outputs. Finally, press “ENTER” to confirm your selection and execute the routing change. For example, if you wish to display input 1 on outputs A~D then the following sequence of button presses should be performed: → → → → A, B, C, D ENTER When directly entering Ethernet address information into the unit...
  • Page 6 Connect up to 10 source devices to the HDMI ports using appropriate quality HDMI cables. Input source devices include Blu-ray players, set-top boxes, game systems and so on. These inputs are DVI-D compliant (with the use of DVI to HDMI adapters or cables).

  • Page 7: Digital Audio

    ZONE AUDIO OUT A~H: Eight sets of stereo analog audio outputs. These audio ports are capable of independently outputting audio routed from any audio source within the matrix. Audio mixing, treble, bass, volume and audio delay adjustments can be set in the WebGUI (LPCM 2.0 or analog stereo sources only).
  • Page 8 firmware, please navigate via the front panel menu to 5-Firmware → → 2-Update YES to begin the firmware update. MAIN 24V & POH 24V: Plug one of the 24V power supplies (included in the package) into the port marked “MAIN 24V” to power the matrix unit. If you wish to connect PoH powered HDBaseT receivers to the matrix, please “...
  • Page 9 Press the “MENU/CANCEL” button to enter the OLED menu, or to back out from menu items. PRESET: Recall matrix presets. The presets are configured within the WebGUI. +/IN: Within the menu, this button moves you up within the menu tree. Otherwise, in routing mode, this button allows you to make your input source selection.
  • Page 10 HDMI Mirroring Output E Output F Factory Default Firmware Version Update Note: The model name and IP address will be displayed when the unit is powered on. The netmask and gateway information can be displayed by repeatedly pressing the “+” button on the front panel or remote control unit. IR Cable Pin Assignment...
  • Page 11 RS-232 Protocol Matrix Remote Controller Assignment Assignment ► ◄ Baud Rate: 115200bps Data Bits: 8 Parity: None Flow Control: None Stop Bits: 1 RS-232 and Telnet Commands Command Syntax The RS-232/Telnet command structure for this unit is both flexible and powerful, and allows for multiple parameters to be set across multiple ports simultaneously within a single command transmission.
  • Page 12 following syntax to set or change a single parameter for a single slot assigned to an HDBaseT or HDMI output port. ZoneAvPair HDBT_Out {Port} Slot {Slot} {Parameter [= Value]} Examples: ZoneAvPair HDBT_Out B Slot 5 VideoSrc = HDMI_In 2 ZoneAvPair HDMI_Out J Slot 3 Load •...
  • Page 13 HDBT_Out A+C+E VideoSrc=HDMI_In 2, AudioSrc=CoaxIn 2 & B+D Mute & F VideoSrc=HDMI_In 1, AudioSrc=HDMI_In 1 • Complex Multi-Slot/Parameter Command Format (ZoneAvPair) The ZoneAvPair command can also control multiple slots with multiple parameter groupings however the syntax is slightly different. Each command can only affect a single port at a time.
  • Page 14 Command Description Zone Audio output “A” plays OAR ZoneLineOut A AudioSrc=OAR_In A audio from the TV connected to “ HDBaseT output A” When using the mirroring function you can use any standard commands with the mirrored HDBaseT output and the mirroring HDMI output will follow the commands.
  • Page 15 Command Description Video switch command HDBT_Out A VideoSrc=HDMI_In 1 HDBT_Out A AudioSrc=HDMI_In 1 Audio switch command • Combined Audio and Video Routing Command Example It is also possible to switch audio and video simultaneous by using an advanced command structure. In this case the individual parameters of the “HDBT_Out”...
  • Page 16 CoaxIn n [n=1~2] AnalogIn n [n=1~4] OAR_In n [n=A~H] CAT_In n [n=1~2] MixerOut n [n=1~3] ZoneLineOut M Treble=XXX Set the treble value for a zone line output. M = A~H XXX = -12~+12 (units: dB) ZoneLineOut M Bass=XXX Set the bass value for a zone line output.
  • Page 17 OpticIn n [n = 1~2] CoaxIn n [n = 1~2] AnalogIn n [n = 1~4] OAR_In n [n = A~H] CAT_In n [n = 1~2] MixerOut n [n = 1~3] ExtLineOut M Treble=XXX Set the treble value for an extended line output. M = 1~4 XXX = -12~+12 (units: dB) ExtLineOut M Bass=XXX...
  • Page 18 Available XXX values: HDMI_In n [n = 1~10] OpticIn n [n = 1~2] CoaxIn n [n = 1~2] AnalogIn n [n = 1~4] OAR_In n [n = A~H] CAT_In n [n = 1~2] MixerOut n [n = 1~3] AudioCAT_Out M Status Display the status of an AudioCAT port.
  • Page 19 HDBT_Out n [n = A~H] HDMI_Out M Status Display the status & properties of an HDMI output including audio/video matrix. M = I~J Set the verbose name of an HDMI_Out M Name={NameString} HDMI output. Maximum 32 characters. M = I~J Note: Can only rename one port at a time.
  • Page 20 port at a time. Multi-port is not supported. Display the status of an HDMI HDMI_In M Status input. M = 1~10 Set the verbose name of an HDMI_In M Name={NameString} HDMI input. Maximum 32 characters. M = 1~10 Note: Can only rename one port at a time.
  • Page 21 Turn the power on. Enter deep stand-by mode. (Only RS-232 functionality is still active.) Report the current power status. Save the current A/V routing PRESET Save M as a preset. M = 1~8 PRESET Load M Load and activate a saved A/V preset.
  • Page 22 test pattern in. Available XXX values: Black Blue Green Cyan Magenta Yellow White FactoryDefault Reset all settings to their factory defaults. (Hidden command.) Display the MAC address. Display the firmware version Assign an audio source to ZoneAvPair HDBT_Out M Slot N a Zone A/V Pair slot on an AudioSrc=XXX HDBaseT output.
  • Page 23 OAR_In n [=A~H] CAT_In n [n=1~2] MixerOut n [n=1~3] ZoneAvPair HDMI_Out M Slot N Assign a video source to a VideoSrc=XXX Zone A/V Pair slot on an HDMI output. M = I~J N = 1~11 Available XXX values: HDMI_In n [n=1~10] Pattern Note: HDMI_In is not available for use with slot 11.
  • Page 24 for an IR Output jack (next to each HDMI input). M0 = 1~10 (supports multiple port selection by using “+”.) Note: Commands will not be executed unless followed by a carriage return. Commands are not case-sensitive. Telnet Control Before attempting to use Telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks.

  • Page 25: Webgui Control

    Note: Commands will not be executed unless followed by a carriage return. Commands are not case-sensitive. If the IP address is changed then the IP address required for Telnet access will also change accordingly. WebGUI Control • Install the Device Discovery Tool Please obtain the Device Discovery software from your authorized dealer and save it in a directory where you can easily find it.
  • Page 26 By clicking on one of the listed devices you will be presented with the network details of that particular device. If you choose, you can alter the static IP network settings for the device, or switch the unit into DHCP mode to automatically obtain proper network settings from a local DHCP server.
  • Page 27 The above function tabs will always display on left side of the WebGUI to aid with navigation. Video Switch This page provides video routing settings including HDCP and test pattern configuration. • Output and Input Routing...
  • Page 28 To begin assigning a new video route, please click the button of the HDBaseT output you wish to send video to (e.g. “HDBT_Out A”) and then “ click on the button of the preferred HDMI input port (e.g. HDMI_In 1”). If desired, you may select more than one output prior to selecting the input.
  • Page 29 • HDMI Output Setting The two HDMI outputs (port I & port J) allow support for the maximum HDMI timing up to 18Gbps (4096×2160@60Hz) and can be used for normal source routing (listed as “Independent” within the WebGUI) and mirroring (listed as “Mirror”...
  • Page 30 Timing: Test patterns can be generated with the following standard timings: 720p@50/60Hz, 1080p@50/60Hz, 4K@25/30Hz. Test pattern output does not use HDCP. Color: The test pattern can be changed to any one of a choice of eight colors.
  • Page 31 • Preset Setting This matrix can store up to eight video and audio routing presets. Presets can be utilized to store multiple different routing states in advance for rapid, hassle-free, recall. Store: Once you have the matrix set the way you like, you can click the “store” icon ( ) in the upper right corner of the window.
  • Page 32 Zone Audio This advanced matrix offers a complete audio routing function. The Zone Audio ports offer analog audio breakaway capability. The audio source, treble, bass, volume and audio delay adjustments can be set on this page. • Output and Input Routing Click the buttons from left to right to choose each output’s source.
  • Page 33 Extended Audio The Extended Audio ports offer additional analog audio breakaway capability. The audio source, treble, bass, volume and audio delay adjustments can be set on this page. • Output and Input Routing Click the buttons from left to right to choose each output’s source. Once the new source has been selected, the change will happen immediately.
  • Page 34 CAT Audio Connecting compatible Cat.5e/6 receivers allows the matrix to both send and receive audio over distances up to 300m. The audio source and mute settings of audio being sent from the matrix to a receiver can be set on this page. •...
  • Page 35 HDMI Audio The audio routed to the two HDMI outputs (ports: I & J) and their associated settings are adjusted on this page. • Output and Input Routing Click the buttons from left to right to choose each output’s source. Once the new source has been selected, the change will happen immediately.
  • Page 36 HDBaseT Audio The audio routed to the eight HDBaseT outputs (ports: A~H) and their associated settings are adjusted on this page. • Output and Input Routing Click the buttons from left to right to choose each output’s source. Once the new source has been selected, the change will happen immediately.
  • Page 37 Mixer Audio The Audio Mixer feature allows for any two audio sources to be mixed together. The matrix has three mixers in total and their settings can be adjusted on this page. • Output and Input Routing Click the buttons from left to right to choose each mixer’s A & B sources. Only 2 sources total may be selected for each mixer.
  • Page 38 Zone A/V Pairing The zone A/V pairing function allows the end user to control the matrix, using the supplied remote control, in a customized manner while in remote rooms (zones) containing an HDBaseT receiver and IR extender. Each zone can have a different set of video/audio sources assigned to the buttons on the remote control for easy switching.
  • Page 39 • Video and Audio Pairing Edit Please click the “edit” icon ( ) to edit the video and audio routing settings. Once you have completed your selections press “Save”. EDID Settings This matrix provides the option of six standard EDIDs, ten sink sourced EDIDs and four customer uploaded EDIDs that can be assigned to each input port individually.
  • Page 40 • Sink EDID Download To save an existing custom EDID to your local PC please press the “ Download” button next to the Customer EDID Settings item you would like to save. An EDID Download window will appear, allowing you to save the EDID file to your local PC.
  • Page 41 The unit comes with the following 6 default EDIDs: FHD/2CH: 1080p/60Hz(148M), 2.0 LPCM, 8-bit color. FHD/MCH: 1080p/60Hz(148M), 7.1 LPCM and bitstream, 8-bit color. 4K UHD/2CH: 3840×2160p/30Hz (297M), 2.0 LPCM, deep color (8/10/12-bit). 4K UHD/MCH: 3840×2160p/30Hz (297M), 7.1 LPCM and bitstream, Deep Color (8/10/12-bit).
  • Page 42 User Config The WebGUI and Telnet username/password are set on this page. Two management levels are available: “Administrator” and “General User”. The administrator username (“admin”) cannot be changed. The “Administrator” user has access to change all settings. The “ General User” is not permitted to access or change information on the EDID Settings or System Settings pages.
  • Page 43 to your local PC. The current system configuration will be saved as XML file. The system configuration can also be restored from a saved XML file by clicking the “Choose File” button to locate the saved XML file, then clicking the “Restore” button. Logout The “Logout”...

  • Page 44: Hdmi Resolution

    Silkscreen Color Black Operating Temperature 0 ̊ C - 40 ̊ C /32 ̊ F - 104 ̊ F − Storage Temperature 20 ̊ C - 60 ̊ C /−4 ̊ F - 140 ̊ F Relative Humidity 20 - 90% RH (No-condensing) Power Consumption 175W Supported...
  • Page 45 HDBaseT ports. Some TVs may not support YCbCr 4:2:0 color or 4K@60Hz and may display the signal incorrectly, or not at all. Please check your TV’s technical specs before attempting to display 4K@60Hz signals. 2. The use of “Premium High Speed HDMI” cables is highly recommended. Audio Specifications Analog Audio Analog Inputs...

  • Page 46: Compressed Audio

    Compressed Audio Bitstreams Standard Bitstream Formats High-Bandwidth Bitstream Formats Notes: Audio break away function supported in LPCM format only. The OAR, optical, coaxial, and Audio CAT functions only support LPCM. 8.3.4 Audio Adjustments ■ Volume: -100dB to 0dB and adjust 0.5dB per step (for both zone and extended audio).
