- Page 1 HDMI 8x8 HDBaseT Matrix over CAT5e/6/7 with LAN Serving # 15204 Operation Manual...
- Page 2 Introduction The HDBaseT™ 8 by 8 HDMI Matrix over CAT5e/6/7 supports the transmission of video (resolutions up to 1080p Full HD and 1920x1200@60Hz), multi-channel digital audio and control via IR, RS-232 or Telnet and Web GUI from eight high definition sources to eight outputs over a single CAT5e/6/7 cable (up to 100m) for each output.
- Page 3 System Requirements • HDMI equipped source devices, connect with HDMI cables or DVI equipped source, connect with DVI to HDMI cables • HDMI equipped displays (TVs or monitors) or HDMI equipped AV receivers, connect with HDMI cables • Industry standard CAT5e/6/7 cables •...
- Page 4 Back Panel 1 LAN: Connect to an active network for LAN serving and Telnet and Web GUI control (refer to Sections Telnet Control and Web GUI Control).When the Matrix or any compatible LAN equipped receivers are connected to a network, this allows the network access (including internet access if available) to be shared between the Matrix and all connected receivers.
- Page 5 10 DC 24V MAIN POWER: Connect the 24 V DC power supply to the unit and plug the adaptor into an AC outlet. 11 PoE 24V: Connect the 24V PoE power supply to the unit and plug the adaptor to an AC outlet.
- Page 6 RS-232 Protocols #ID 15204 Remote Control Console Assignment Assignment ► ◄ Baud Rate: 19200bps Parity: None Stop Bit: 1 Data bit: 8 bits Flow Control: None RS-232 & Telnet Commands Command Description A1~A8 Switch Output A to 1~8 B1~B8 Switch Output B to 1~8...
- Page 7 version System Reset to A1, B2, C3 etc Setting EDID MODE. 1-STD 2-TV Display all the available commands Quit Exit (for telnet only) Note: All the commands will not be executed unless followed with a carriage return. All letters are not case-insensitive. Telnet Control Before attempting to use the Telnet control, ensure that both the Matrix (via the LAN/Control port) and the PC/Laptop or control system being used are...
- Page 8 Note: The IP address of the Matrix can be displayed on the device's LCM monitor by pressing the Menu button twice. Type 'HELP' to list the available commands (see below for reference). Type 'IPCONFIG' To show all IP configurations. To reset the IP, type 'RSTIP' and to use a set static IP, type 'SETIP'.
- Page 9 Web GUI Control On a PC/Laptop that is connected to the same active network as the Matrix, open a web browser and type device's IP address on the web address entry bar. The browser will display the device's status, control and User setting pages.
- Page 10 Specifications Video Bandwidth 225 MHz/6.75 Gbps Input Ports 8×HDMI, 9×IR Extender, 1×RS-232, \ 1×LAN, 1×Mini USB-B (updated only) Output Ports 8×CAT5e/6/7, 9×IR Blaster Power Supply 24V/6.25A DC (US/EU standards,CE/FCC/ UL certified) ESD Protection Human body model: ±8kV (air-gap discharge) ±4kV (contact discharge) Dimensions 438mm(W) x 255mm(D) x 92mm(H) Weight...
- Page 11 Connection Diagram...
