- Page 1 HDMI Quad 4x4 Video Wall Matrix Switch # 15197 Operation Manual...
- Page 2 Introduction The HDMI Quad 4x4 Video Wall Matrix Switch is designed to utilize 4 HDMI video sources, such as Blu Ray players, XBox, PS3 etc and to display any or all of the 4 video sources onto four HDMI input LCD, LED or Plasma monitors/TV's. Display the desired video signal on to the monitors in different formats using various switch modes, including 'Video Wall' mode.
-
Page 3: Operation Controls And Functions
Operation Controls and Functions The following sections describe the hardware components of the unit. Front Panel 1. POWER Press to power on the system, press again to turn the system to standby. 2. IR SENSOR 3. MENU/EXIT Press to enter MENU mode and press again to EXIT the menu or return to previous page. 4. - Page 4 RS-232 Protocol Press once to reset current setting values back to factory default value RS-232 IN RS-232 OUT Assignment Assignment Baud Rate: 9600 bps Data bit: 8-bit Parity: None Stop Bit: 1 Flow Control: None Specifications Video Bandwidth: 225Mhz / 6.75Gbps Input Ports: 4 x HDMI Output Ports:...
- Page 5 Connection Diagram...
