- Page 1 4×4 HDMI UHD &Audio Matrix with Fast Switching ID # 15366 Operation Manual...
- Page 2 Introduction The 4 by 4 HDMI matrix with audio which allows HDMI and audio signal to be routed to and displayed on connected HDMI displays and or audio output equipments simultaneously. Additional audio selection and extension allows users to utilise both vidoeo and audio more efficiency. With fast switching technology the device can greatly eliminate the time required by swapping or turning ON/OFF the connected displays.
- Page 3 Operating Functions and Controls Front Views 1. POWER: Press this button to turn ON the device and the LED will illuminated. IR Window: This IR Receiver receives the remote control signal from the package include remote control only. IN 1~4: Press these IN buttons to select an input from the input sources.
-
Page 4: Optical Out
MENU: Press to enter into the menu. 14. +/-: Press these buttons to move up/down under menu selection. PRESET: Press “PRESET”, the OLED menu will show Preset then select IN 1~4. Preset 5~8 selection, press IN 1/2/3/4 twice. Press “TAKE” to confirm the selection or press “CANCEL”... - Page 5 IR IN: Connect the IR Receiver included in the package for IR signal receive from the included remote control. DC 12V: Connect the adaptor with power cord included in the package and connect to AC wall outlet for power supply. OSD Menu Main Menu Sub Menu...
- Page 6 Exit Same EDID Same EDID EDID IN1 Select Input 1’s EDID EDID IN2 Same EDID Select Input 2’s EDID Same EDID Same EDID Same EDID EDID IN3 Select Input 3’s EDID EDID IN4 Same EDID Select Input 4’s EDID Same EDID Video Video 1 IN/OUT default No.1...
- Page 7 HDMI 8 No.8 A=H3, B=H2, C=H1, D=H4 Exit Audio OPTICAL 1 IN/OUT default No.1 A=O1, B=O2, Preset-- C=O3, D=O4 OPTICAL A=O4, B=O1, OPTICAL 2 No.2 C=O2, D=O3 OPTICAL 3 No.3 A=O3, B=O4, C=O1, D=O2 OPTICAL 4 No.4 A=O2, B=O3, C=O4, D=O1 OPTICAL 5 No.5 A=O4, B=O3,...
- Page 8 Exit Network Network status Link Status DHCP,Static or Not Linked Get IP Mask Get Netmask Gate Get Gateway System MAC Address Exit Source IN1 On/Off , IN1 , IN2 detect source Detection IN2 On/Off with/ without the signal & HDCP IN3 On/Off , IN3 , IN4 detect source IN4 On/Off...
- Page 9 Exit Factory Do Reset Do system Reset Reset Exit Exit Remote Control POWER: Press this button to switch the system ON/OFF. OUT A/D: Press these buttons onc a time along with an IN buttons to select an input source for an output display.
- Page 10 Press the IN buttons to select an input from the 4 input sources. MUTE: Press this button to mute or unmute the output audio sound. IR Cable Pin Assignment RS-232 Protocols ID 15366 Remote Control Assignment Assignment ► ◄ Baud Rate: 115200bps...
- Page 11 RS-232 and Telnet Commands Command Description Description of Parameter POWER OFF NONE POWER ON NONE IPCONFIG DISPLAY THE NONE CURRENT IPCONFIG SIPADDR SET ETHERNET IP XXX=0~255 XXX.XXX. ADDRESS XXX.XXX SNETMASK XXX. SET ETHERNET XXX=0~255 XXX.XXX.XXX NETMASK SGATEWAY XXX. SET ETHERNET XXX=0~255 XXX.XXX.XXX GATEWAY...
- Page 12 AUDIO SOURCE O1~O4, 0=MUTE AOB N SET OUTPUT B N=1-4/H1~H4, 5~8/ AUDIO SOURCE O1~O4, 0=MUTE SET OUTPUT C N=1-4/H1~H4, 5~8/ AOC N AUDIO SOURCE O1~O4, 0=MUTE AOD N SET OUTPUT D N=1-4/H1~H4, 5~8/ AUDIO SOURCE O1~O4, 0=MUTE AOI N SET OUTPUT D N=1-4/H1~H4, 5~8/ AUDIO SOURCE O1~O4, 0=MUTE...
- Page 13 TYPE EDIDMODE N SET EDID MODE N=(1)All (0)Appoint TYPE EDIDALL SHOW EDID MODE NONE SOURCE FOR ALL EDIDALL N SET EDID CONTENT N=0-9 FOR ALL EDIDIN SHOW ALL INPUT NONE EDID SOURCE EDIDIN N1 SHOW INPUT N1 N1=1-4 EDID SOURCE SET INPUT N1 EDID EDIDIN N1 N2 N1=1-4...
- Page 14 SHOW DESCRIPT NONE OF UNIT REBOOT SYSTEM REBOOT NONE HELP SHOW COMMAND NONE LIST SHOW DESCRIPT HELP N N : command name OF COMMAND Note: All the RS-232 command will be not executed unless followed with a carriage return. All commands are case-sensitive. Telnet Control To access the telnet control in Windows 7, click on ‘Start’...
- Page 15 Type HELP or ? to bring out all the commands. Note: All the commands will be not executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly Web GUI Control...
- Page 16 Click on OUTPUT A~D to select output display with INPUT 1~4 source selection, multi-outputs can select an input or an output with an input selection. Once the selection is made on both output and input successfully, the background color will return back to white. Click on to mute video output allowing only audio only on HDMI output.
- Page 17 EDID setting can be set individually for each input or one setting for inputs, click on “Appoint” or “All” first to select EDID mode. Click on input(s) and select from 1~9 to set the EDID...
- Page 18 Select IP Mode with STATIC IP or DHCP for using a static or floating Connection Diagram...
- Page 19 Specifications Frequency Bandwidth 300MHz/3Gbps Input Ports 4 x HDMI, 2 x S/PDIF, 2 x AUDIO-CAT 1 x USB (Service only) 1 x Control 1 x RS-232 1 x IR Output ports 4 x HDMI, 2 x AUDIO-CAT Resolution 480i~1080p@50/60, 1080p@24, 4K x 2K (3840x2160/4096x2160@24/50/60Hz Y420) Output Level...
- Page 20 DVI and HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x576p@50 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75 1280x720@50 1280x720@60 1280x720p@60 1280x768@60 1280x800@60 1280x1024@60 1360x768@60 1600x1200@60 1920x1080i@50 1920x1080i@60 1920x1080p@24 1920x1080p@25 1920x1080p@30 1920x1080p@50 1920x1080p@60 1920x1200@60(RB) 3840x2160@24/25/30 4096x2160@24_YUV420 HDMI input (Up to 192kHz) HDMI output LPCM 2CH...
