  • Page 1 4 x 4 HDMI UHD over CAT5e/6/7 Matrix with Control System - ID# 15365 Operation Manual...
  • Page 2 Introduction This 4K2K 4 by 4 HDMI over CAT5e/6/7 Matrix with fast switch and control system allows 4 HDMI signal sources to be routed to 4 HDBaseT™ outputs over a single CAT5e/6/7 cable up to 100m for each output. The Control System functions provide not only direct but also indirect control interfaces for all your connected devices.
  • Page 3 System Requirements Input source equipment such as Blu-ray/DVD/PS3 player or Set-Top- Box and output HDBaseT Receivers to TV/Display and or audio amplifier with connection cables. Control system input devices such as security door/windows, lights, curtain, or devices like players, sound systems, or any other controllable device with IR/RS-232 or net service link design with PC/smart phone to send commands to control the whole system Operating Functions...
  • Page 4 LOCK: Press to lock on all button functions on the front panel. Press for 3 seconds to relieve the lock function. MODE: Press this button to switch in between the TAKE mode/Real Time mode. OLED will show current selection on the top right side, press TAKE to confirm the switch.
  • Page 5 RELAY OUT 1~8: Connect with control device’s power ± line cable such as DC power supply to activate the control devices. COM 1/2: Connect with devices that obtain RS-232 input for control purpose. Using TELNET client to send command directly to control the device, set the connected port to 7501 with COM 1 and 7502 with COM2.
  • Page 6 Remote Control POWER: Press this button to switch the system ON/OFF. OUT A~D: Press these buttons once a time along with an IN buttons to select an input source for an output display. IN 1~4: Press the IN buttons to select an input from the 4 input sources.
  • Page 7 IR Cable PIN Assignment Note: Due to both IR Extender and IR Learner cables are with similar outlook, a part no. "CBL-IR10C3SA200A sticker has been placed to differentiate the difference on IR Learner. RS-232 Protocols Matrix Control Device Assignment Assignment ►...
  • Page 8 Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 RS-232 & Telnet Commands Command Description Paramenter Power Off (Standby) None Power On None Display The Current IP IPCONFIG None Configure SIPADDR X.X.X.X Set Ethernet IP X=0~255 Address SNETMASK...
  • Page 9 EDIDIN N1 Show Input N1 EDID N1=1~4 Source Set Input N1 EDID N1=1~4 EDIDIN N1 N2 Source N2=0~9* (ref. OLED EDID ALL) Show All Input HDCP HDCPIN None Status HDCPIN N1 Show Input N1 HDCP N1=1~4 Status HDCPIN N1 N2 Set Input N1 HDCP ON/ N1=1~4 N2=0 (OFF), 1 (ON)
  • Page 10 UART_ROUTE UART Route Setting Command Allow UART Commands UART_ROUTE all to send out to all HDBaseT output port Block UART Commands UART_ROUTE to send out to HDBaseT none output port UART_ROUTE Send UART Commands to the designated output HDBaseT port IR_SELECT IR Mask Addition/ Deletion command...
  • Page 11 (A~D) from_source/input port (1~4) from_mcu/IR OUT (1) from_notice/IR All (1) n=A~D/1~4 ex: IR_SELECT TO_MCU1 DEL FROM_ZONEA VALENS read a b c Read and display a= Local/Remote d e... Valens Information*** (HDBaseT TX/RX) b= HDBaseT output A~D c d e...=FwID, FwDate, FwType, HwType, LnkSts, Cable, BERs, AutoModeCap,...
  • Page 12 CMDTBL del n Delete Command n=1~128 n=1~8 CMDTBL name n Name Command n1=Up to 24 characters including space MACRO run n Execute Macro n=1~8 Command COMCONF N1 N2 N1=COM/Zone Set UART's N3 N4 N5 N6 N2=Port number Parameters N3=Baud rate (4800~115200) N4=Data bit (7~8) N5=Parity (none/odd/even)
  • Page 13 *EDID contents: 0=Output A 1=Output B 2=Output C 3=Output D 4=8bit/2D/PCM/720p 5=8bit/2D/PCM/AC3/720p 6=8bit/2D/PCM/1080p 7=8bit/2D/PCM/AC3/1080p 8=8bit/2D/PCM/4K2K@60 9=8bit/2D/PCM/AC3/4K2K@60 **IR Command Function Parameter Allow Allow Not Allow Not Allow from_source to_zone from_notice from _mcu from_zone to_source from_notice from _mcu from_zone from_source to_mcu from_zone from_source from_notice from _mcu to_notice...
  • Page 14 - FwDate: Firmware release date. - FwType: Reveal current firmware if for TX end chip or Rx end chip. - HwType: Reveal current chip hardware is Tx end or Rx end. - LnkSts: HDBaseT link status. - CableLen: Approximated cable length of current HDBaseT connection on specified port.
  • Page 15 EDID All Sink A Copy Output A~D 8/2D/PCM/1080 display EDID Sink B Sink C Sink D Standard EDID 8/2D/PCM/720P settings. 8/2D/PCM/AC3/72 Deep Color/2D3D/ Audio/Native 8/2D/PCM/1080P resolution. 8/2D/PCM/AC3/10 8/2D/PCM/4K2K 8/2D/PCM/AC3/4 Exit EDID IN1 Same as EDID All. Select Input 1~4 Same as EDID EDID.
  • Page 16 Mask. Setup Static Gate 192.168.5.254 Gateway Do Re-Link Re-Link After Setup Network, the System need to re-link. Exit Network Get IP Network Status Status DHCP, Static or Not Linked. Get Netmask Get Gateway System MAC Exit Source IN1 On/Off Detect IN1, IN2 Detection source IN2 On/Off...
  • Page 17 Firmware FW Version Display Model number & FW Version. Update FW Update. Exit Factory Reset Do Reset Do System Reset. Exit Exit Telnet Control Before attempting to use the Telnet control, please ensure that both the Matrix unit (via the ‘CONTROL’ port) and the PC/Laptop are connected to the active networks.
  • Page 18 This will bring us into the unit which we wish to control. Type 'HELP' to list the available commands. Note: All the commands will be not executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly.
  • Page 19 IP Searching Application Please contact sales@converters.tv for the software with file name CDPS V2.000 and save it in a directory where you may use it later. Connect the Control System with PC/Laptop through the Ethernet port through an active network system and open the CDPS V2.000 application.
  • Page 20: Routing Settings

    The browser will display the device’s Routing, HDBaseT Info & Settings, EDID, Macro, Command, Trigger, UART, Network and System Settings Configuration pages for users to control. Routing Settings Click on 'Routing Settings' to select an input for output and the selection will turn orange, naming inputs &...
  • Page 21 HDBaseT Settings Click on HDBaseT Settings to set both the CAT5e/6 output A~D and the connected Receivers A~D’s HDBaseT mode, behavior and can also update its firmware. EDID Settings Click on EDID Settings to select EDID Mode and Set EDID Input content.
  • Page 22 Click on Add button to insert commands. Command can be set to control the Control System/SysCMD, other devices connected within the same Telnet system/Internet area, RS-232 COM ports, IR and Relay devices connected through the Relay outputs of Control System with delay time.
  • Page 23 or internet area require to set its IP and Port number and it is strongly recommend to set the delay time >500ms in order to secure a successful command sending. Command set to control the Relay devices require to set the Port number. Click on Save Change to confirm the setting.
  • Page 24 Command Settings Click on 'Command Settings' to edit or delete commands up to 128 sets. Insert the command directly in the bottom column of Command Edit and name the command on the top column then click on Save Changes to store the command.
  • Page 25: Network Settings

    UART Settings Click on 'UART Settings' to set each COM port's Baud rate, Data bit, Parity and Stop bit. Figures out of the selection range can be set under RS-232 or Telnet. Network Settings Click on Network Settings to set the device’s IP Mode. Once the change is saved the system will reset the IP address on the device automatically and user will need to re-enter the IP address to continue the WebGUI function.
  • Page 26: Connection Diagram

    Click on System Settings to set power to On/Standby. Matrix Mode is to allow the device’s front panel I/O selection to be real time or must press the take button to execute the selection, Download Current Configuration is to save the current setting into your PC/Laptop and Restore Configuration is to bring up a saved setting from your PC/ Laptop.
  • Page 28 Specifications Video Bandwidth 300 MHz/3Gbps Input Ports 4×HDMI, 1×RS-232, 1×Control, 5x IR IN, 2×COM port (D-Sub 9-pin), 4×LAN, 8×Input (0~15V, 0~5/level low, 5~15/level high), 1×IR Learner, 1×USB (service) Output Ports 4×CAT5e/6, 8×Relay Output, 8×IR, 5×IR Supported Resolutions 480i~1080p@24/50/60, 4K2K@24/25/30, 4K2K@50/60 (YUV420) & VGA~WUXGA (RB) HDMI Cable Length 10M/1080p, 5M/4K2K...
  • Page 29 Resolution Input Output 640×480@60, 72, 75, 85 √ √ 720×400@85 √ √ 800×600@56, 60, 72, 75, 85 √ √ 1024×768@60, 70, 75, 85 √ √ 1152×864@75 √ √ 1280×720@60 √ √ 1280×768@60, 75, 85 √ √ 1280×800@60RB, 60 √ √ 1280×960@60 √...
