  • Page 1         Contact Details    Please note that some of the contact details on  this PDF document may not be current.    Please use the following details if you need to  contact us:    Telephone: 0844 879 3588  Email: customer.services@gdcgroup.co.uk      The Help Centre section of this website also features a wide range  of information which may be of use to you and is available 24  hours a day. It includes:    • Operating and installation instructions downloads  • Request a repair  • Where to buy our products  • Literature downloads  • Heating requirement calculator    www.credaheating.co.uk/help‐centre  A division of GDC Group Ltd Registered No: 1313016 England VAT GB 287 1315 50004 Millbrook House Grange Drive Hedge End Southampton SO30 2DF EEE Producer Registration Number –...
  • Page 2: Specifications

    WARNING – THIS APPLIANCE MUST BE EARTHED. SPECIFICATIONS The Creda CSQ range is available in 1,2 and 3 lamp models with outputs of 1.5kW, 3.0kW and 4.5kW respectively. The 4.5KW model is supplied as a dual voltage unit and is suitable for use on 230V ~ 1PN and 400V ~ 3PN supplies.
  • Page 3 CSQ45 All dimensions in mm UNIVERSAL BRACKET MOUNTING ANGLE ADJUSTMENTS 4 FIXING HOLES WIRING DIAGRAMS G/Y = GREEN/YELLOW R = RED B = BLACK CSQ15 CSQ30 CSQ45 LINKS MUST BE FITTED LINKS MUST BE REMOVED HEATER WIRING AS OPPOSITE CABLE ALL MODELS 2.5MM...
  • Page 4 (Dimension ‘A’ on the appliance rating label.) Model No. Rating Min. Height Recommended Height (kW) CSQ15 CSQ30 2.5-3.5 CSQ45 Note: If more than one heater is to be installed, ensure that the lamps of adjacent heaters are more than 3.5 metres apart.
  • Page 5 The table below indicated throw and spread measured 1 metre above floor level which may be a more appropriate measurement for some applications. The following tables show the recommended mounting heights for three typical average intensity requirements: Average CSQ15 CSQ30 QXD45 Radiant Height Throw Spread...
  • Page 6 Leave instructions adjacent to the electricity meter. 6. MAINTENANCE Since the Creda Quartz Heater contains no moving parts little maintenance is required beyond cleaning the lamp replacement. It is however, essential that the heater is not operated with accumulation of dust or dirt on the lamp(s) or reflector(s) as this can cause a build up of heat and eventual damage.
  • Page 7 Please do not return a faulty product to us in the first instance as this may result in loss or damage and delay in providing you with a satisfactory service. Please retain your receipt as proof of purchase. TEL: 0845 604 2399 CREDA HEATING FAX: 01489 773064 MILLBROOK HOUSE WEBSITE: www.credaheating.co.uk GRANGE DRIVE Republic of Ireland Tel.
