Summary of Contents for Hills Voicenav

  • Page 2: Table Of Contents

    Table of contents Introduction Warranty Glossary of terms Drawing Legend Indicators, icons and lights Away arming Stay arming Disarming Multi area arming – away mode – all areas Multi area arming – away mode – single area Multi area disarming – all areas Intercom room calling Emergency keys Understanding the main menu structure...

  • Page 3: Introduction

    We trust that you will enjoy your VoiceNav, and we would like to thank you for choosing a Hills Security System. All users of your security system should read and follow the instructions and precautions in this manual before operating your security system.

  • Page 4: Glossary Of Terms

    An option that allows certain zones not to be secure when arming. A security system that is ready to be “force armed” will flash the corresponding area light green. Generally assigned to detection devices that cover the VoiceNav (eg; motion sensors, front door reed switches), allowing the user to arm the security system without the need to wait for those zones to be secure.

  • Page 5: Drawing

    Touch the corresponding number on the numeric section of the touch screen, then touch the [5]-[ENTER] enter key. [?]-[?]-[?]-[?] Enter the required code on the numeric section of the touch screen Exit the premises, or walk test the movement sensors Hills – VoiceNav V0.6 - 4 -...

  • Page 6: Indicators, Icons And Lights

    Area is armed in the “ AWAY ” mode. *If both the stay and away keys are off, this VoiceNav has multi area control and a pin number must be entered to gain area control. Green Area is disarmed.

  • Page 7: Away Arming

    If an armed zone is alarmed whilst your security system is in the stay mode, it will initiate a warning tone at your VoiceNav, your sirens will sound at the end of this warning.

  • Page 8: Multi Area Arming - Away Mode - All Areas

    / exit doors. When you are detected entering, your VoiceNav will repeat a warning message for the duration of the entry delay until a valid pin code is entered. Your sirens and communicator will activate at the end of the entry delay time if a valid pin code is not entered. Away and Stay modes can be configured with different entry delay times, ask your service provider for further details.

  • Page 9: Intercom Room Calling

    Activation Keys Three (3) emergency icons are av ailable via your VoiceNav to provide personal support in areas of: Medical, Police (duress) and Fire alarm. To activate these functions touch the required key for two seconds. You should only touch these keys in an emergency situation that requires a response by a central station.

  • Page 10: Understanding The Main Menu Structure

    With its inbuilt intuitive voice prompts aiding you through all menus, using your VoiceNav is enjoyable and easy. From the moment you touch the menu key, your VoiceNav immediately starts to instruct you on what to do next, simply select the option you wish to access and follow the voice prompts.

  • Page 11: To Control Zone Bypass - Bypassing Zones

    Control Zone Chim e – Menu 2 You can setup your VoiceNav so that it w ill “beep” when programmed zones are tripped or activated, this is called chime. Chime mode does not trigger any alarms, and is only used as a low level alert such as a customer entry door.

  • Page 12: System Event History - Alarm Memory

    8 – Recordings. Your VoiceNav will now announce all these events by name. System Test – Menu 4 Your security system is made up o f different components, brought together to produce a very powerful, yet easy to use security system.

  • Page 13: System Test - Siren, Communicator, Back Up Battery And Walk Test

    When in walk test mode your VoiceNav will emit the chime “beep” each time a zone is activated, and chirp the outside siren. Area Lights will also blink red after a detection device in that area has been activated.

  • Page 14: User Configuration - Configure A New Pin Code

    [4] - [EN Selects user 4. Deselects area 2 [MENU] Moves back to user configuration (step 3) [MENU] Exits back to main menu (“Touch [1] to control zone bypass…etc……etc……) [MENU] Touch menu to exit Hills – VoiceNav V0.6 - 13 -...

  • Page 15: User Configuration - Configure User Authority Levels

    If you attempt to enter a user pin code in your security system that is being used by another user, your VoiceNav will announce Pin code has failed followed by three fast beeps, simply select another pin code.

  • Page 16: Phone Number Configuration - Enter And Delete Phone Numbers

    Touch menu to exit Note: You can record names for up to 16 outputs, making it easier to identify individual outputs later on. You can record these names in menu 8, Voice message Recordings. Hills – VoiceNav V0.6 - 15 -...

  • Page 17: Voice Message Recording - Exit / Entry Message Recording

    Voice Message Recording – Menu 8 With the VoiceNav there is no more need to memorize who has what user code, or what zone number is that sensor in the lounge room. Menu 8 allows you to record names against users, zones, areas, rooms and outputs creating an extremely user friendly security system.

  • Page 18: Basic System Configuration - Resetting The Time And Date

    Moves back to step 4. area selection [MENU] Moves back to basic system configuration menu selection (step 2). [MENU] Exits back to main menu (“Touch [1] to control zone bypass…etc……etc……) [MENU] Touch menu to exit Hills – VoiceNav V0.6 - 17 -...

  • Page 19: Basic System Configuration - Resetting Latching Sensors (Smoke Detectors / Shock Sensors)

    This is a feature for experienced users. 2. Time Annunciation Turning this feature On, will make your VoiceNav annunciate the time and date during exit and entry delays. Turning this feature Off, disables this feature.

  • Page 20: Understanding The Mute Menu

    VoiceNavs and hold a conversation. From the mute menu you would set the following options. Note: When a VoiceNav is configured for intercom functionality, it is refer to as a room station. Hills – VoiceNav V0.6...
  • Page 21 Mute Menu Options Selection Table Voice annunciation Reserved Room privacy Reserved Automatic room answering Reserved Reserved Outdoor station room answering Note: Refer to area lights for selected options. Area light lit solid red indicates feature is selected Hills – VoiceNav V0.6 - 20 -...

  • Page 22: Word Library

    Wall Area Games Outside Warehouse Attic Garage Panic Water Automatic Pantry West Auxiliary Gate Partial Window Back Glass Perimeter Windows Basement Glass break Pool Wireless Bathroom Ground Rear Yard Bedroom Guest Reception Zone Hills – VoiceNav V0.6 - 21 -...

  • Page 23: Zone List

    Programmed Phone Number 1.………………………………………………..……………..…... Programmed Phone Number 2………………………………………………..……………..…..Programmed Phone Number 3.…………………………………………………………………... Zone List Service provider……………………………………………………Phone…………………………………………….. Monitoring station………………………………………….……... Phone…………………………………………….. System type.……………………… ……………………………...Date of installation…………………………….. Hills – VoiceNav V0.6 - 22 -...
