SPECIFICATIONS HR, HE MODELS K, EZ MODELS • • Design and specifications are subject to change Design and specifications are subject to change without notice without notice HA MODEL U MODEL • Design and specifications are subject to change without notice •...
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
IC, LA6541D IC, M61509FP mono. SW • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code...
WIRING-2 (MOTOR) TRANSISTOR ILLUSTRATION E C B E C B E C B 2SA1296 2SA933 2SA1318 H MOTOR C.B 2SC1815 2SC1740 DTC114TS DTC124XS (SLED MOTOR) BC E 2SB1370 2SC2714 (INSIDE LIMIT SW) DTC114TK DTC114YK DTC124XK DTC144TK (SPINDLE MOTOR)
Page 12
WIRING-3 (FRONT/HP/BATT1/BATT2) A170<HA> MODEL OTHER MODELS A110, A170 MODELS A110, A170 A110, A170 A110, A170 MODELS MODELS MODELS...
Page 16
ELECTRICAL ADJUSTMENT < TUNER SECTION > 7. FM Tracking Adjustment L003 L003 (BAR ANT) (BAR ANT) L004 ..............88.0MHz (HA, HE, HR, U MODELS) TC002 ..............108.0MHz TUNER C.B TUNER C.B 1. AM Freq. Range Adjustment L006 ............... 517kHz 8. FM IF Adjustment TC003 ..............
Page 17
IC DESCRIPTION IC, LA9241ML Pin No. Pin Name Description Pin No. Pin Name Description Pin to which external pickup photo diode is connected. RF signal is created by adding Pin from which TES signal is output to DSP. FIN2 with the FIN1 pin signal. FE signal is created by subtracting from the FIN1 pin signal. “High Frequency Level”...
Page 18
IC, LC78622ED Pin No. Pin Name Description Pin No. Pin Name Description DEFI Defect sense signal (DEF) input pin. (Connect to 0V when not used). XVDD — Crystal oscillator power supply pin. Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V. XOUT Pin to which external 16.9344 MHz crystal oscillator is connected.
Page 19
IC, LC865516A-5P16 Pin No. Pin Name Description Pin No. Pin Name Description SEG E SEG E control. — Not connected. SEG F SEG F control. SEG DP SEG DP control. SEG G SEG G control. SEG A SEG A control. —...
CD MECHANISM EXPLODED VIEW 1/1 CD MECHANISM PARTS LIST 1/1 SHAFT,SLIDE REF. NO PART NO. KANRI DESCRIPTION SF-P101NR 1 S2-121-A28-400 COVER GEAR 2 S2-511-A21-000 GEAR MIDDLE 3 S2-511-A21-100 GEAR,DRIVE A S1-PN2-03R-OSE SCR PAN PCS 2-3 B 87-261-073-410 SCR S-TPG FLT 2.6-6 ALL M8-ZZK-E90-070 DA11T3C CHASSIS...
